Canon Pixma G1110 Series User manual
Para Começar
Leia Informações Importantes e Sobre
Segurança (adendo) primeiro.
Guía de inicio
Lea primero Información de seguridad
e información importante (apéndice).
Getting Started
Read Safety and Important Information
(addendum) rst.
1
2
Instalando a impressora .................................................página 1
Conectando a um computador .......................................página 4
Como segurar
a impressora
Filmes explicativos
Instalación de la impresora.............................................página 1
Conexión con el ordenador ............................................página 4
Cómo sujetar
la impresora
Películas explicativas
Installing the Printer...........................................................page 1
Connecting with Computer ................................................page 4
How to Hold Printer Explanatory Movies
1
ENGLISH
1. Checking Included Items
□ Power cord
□ Safety and Important Information
□ Getting Started (this manual)
□ Setup CD-ROM for Windows PC
□ Cartridge □ Ink bottle
2. Removing Packing
Materials
1 Remove the packing materials (such as orange
tape) from outside the printer.
2 aOpen the top cover.
bRemove the orange tape and the protective
material and discard them.
a
b
3. Installing the Cartridge
1 Open the cartridge locking cover.
2 Take out each cartridge from the package and
remove the label.
3 Remove the protective tape.
Do not touch.
4 Insert the C (color) cartridge on the left and the B
(black) cartridge on the right.
Do not bump it against the
surrounding parts.
5 Close the cartridge locking cover and push it
down.
6 Press down both joint buttons completely.
2
4. Turning on Printer
1 Close the top cover.
2 Connect the power cord.
Back
Do not connect any cables except the power cord
yet.
3 Press the ON button.
Lit
If the Alarm lamp is ashing, refer to "When a lamp
is ashing" on page 3 to resolve the error.
Flashing
5. Pouring Ink
This product requires careful handling of ink. Ink may
splatter when the ink tanks are lled with ink. If ink gets
on your clothes or belongings, it may not come o.
1 Open the top cover.
2 Open the ink tank cover.
3 Grab and remove the tank cap of the ink tank.
4 Hold the ink bottle upright and remove the bottle
cap.
5 Insert the nozzle of the ink bottle into the inlet and
stand the ink bottle upside down.
3
ENGLISH
6 Pour all ink into the ink tank.
Conrm that the ink has been lled to the upper
limit line (A).
(A)
7 Replace the tank cap securely.
8 Close the ink tank cover.
9 Repeat steps 2 to 8 to pour all ink into the
corresponding ink tanks on the right according to
the label.
Conrm that the ink has been lled to the upper
limit line (A).
(A)
10
Close the top cover.
6. Preparing the Ink System
1 Press the RESUME/CANCEL button, and then
conrm that the ON lamp has changed from lit to
ashing.
Ink preparation takes about 5 to 6 minutes.
Proceed to the next page.
The Alarm lamp is ashing
Count the number of ashes to determine the cause
of the problem.
• 4 times
The cartridges are not installed correctly.
" 3. Installing the Cartridge" on page 1
• 5 times
No cartridges are installed.
" 3. Installing the Cartridge" on page 1
• 9 times
The protective materials are not removed.
" 2. Removing Packing Materials" on page 1
The ON lamp is ashing
Preparing the ink system. This may take about 5 to 6
minutes. Proceed to the next page.
The ON lamp and Alarm lamp ash alternately 8
times
Ink is not prepared normally.
Press the ON button to restart the printer, and then
redo the procedure from "5. Pouring Ink" on page 2.
For all other cases, refer to the Online Manual.
When a lamp is ashing
4
7. Connecting to Computer
Windows
You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.
1 Start the setup le for either method or method .
Downloading from the Internet
aOpen a web browser ( etc.) on your computer.
bInput the following URL and access the Canon
website.
cSelect Set Up.
dInput the model name of your printer and click OK.
You can select a model name from the list.
eClick Setup.
The procedures for Windows are shown below. If
you are using a computer with an OS other than
Windows, do the setup according to the on-screen
instructions.
fClick Download and download the setup le.
gExecute the downloaded le.
Proceed to step on the next page to
continue.
Using Setup CD-ROM (Windows Only)
■When using Windows 10 or Windows 8.1:
aLoad the Setup CD-ROM in your computer.
bWhen the following message appears on the
right side of your computer screen, click it.
When This Message Does Not Appear (or Has Disappeared)
1. Click File Explorer on the taskbar.
or
2. Click This PC on the left side of the opened window.
3. Double-click the CD-ROM icon on the right side of the
window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
4. Proceed to step d.
5
ENGLISH
cIf the following screen appears, click Run Msetup4.exe.
dIf the User Account Control dialog box appears, click Yes.
Proceed to step to continue.
■When using Windows 7:
aLoad the Setup CD-ROM in your computer.
b When the AutoPlay screen appears, click Run
Msetup4.exe.
c If the User Account Control dialog box
appears, click Continue.
When AutoPlay Screen Does Not Appear
1. Click Computer from the start menu.
2. Double-click the CD-ROM icon on the right side of the
opened window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
Proceed to step to continue.
2 Click Start Setup.If the following screen appears, click Exit.
Follow the on-screen
instructions to proceed
with the setup.
The setup is complete when the printer's ON lamp stops ashing and stays lit. You can
print from your computer.
6
Loading Paper
1 Open the paper support.
2 Slide the right paper guide to the end.
3 aLoad paper with the print side facing up.
bSlide the right paper guide to align it with the
side of the paper stack.
b
a
4 aPull out the paper output tray.
bOpen the output tray extension.
a
b
Transporting Your Printer
Check that both joint buttons are pressed down
completely to avoid ink leaks.
Pack the printer in a plastic bag in case ink leaks.
• Pack the printer in a sturdy box so that it is placed
with its bottom facing down, using sucient protective
material to ensure safe transport.
• Do not tilt the printer. Ink may leak.
• Please handle with care and ensure the box remains
at and NOT turned upside down or on its side, as the
printer may be damaged and ink in the printer may
leak.
• When a shipping agent is handling transport of the
printer, have its box marked "THIS SIDE UP" to keep
the printer with its bottom facing down. Mark also with
"FRAGILE" or "HANDLE WITH CARE".
When relocating the printer, make sure of the following. Refer to the Online Manual for details.
1
ESPAÑOL
1. Comprobación de los elementos
suministrados
□ Cable de alimentación
□ Información de seguridad e información importante
□ Guía de inicio (este manual)
□ CD-ROM de instalación para Windows PC
□ Cartucho □ Frasco de tinta
2. Retirar los materiales
de protección
1 Retire los materiales de empaquetado (como
la cinta naranja) del exterior de la impresora.
2 aAbra la cubierta superior.
bRetire la cinta naranja y el material
de protección y deséchelos.
a
b
3. Instalar el cartucho
1 Abra la tapa de bloqueo del cartucho.
2
Saque cada cartucho del paquete y retire la etiqueta.
3 Retire la cinta protectora.
No tocar.
4 Inserte el cartucho C (color) en la parte izquierda
y el cartucho B (negro) en la parte derecha.
No golpear contra los
objetos de alrededor.
5 Cierre la tapa de bloqueo del cartucho y presione
hacia abajo.
6 Presione hacia abajo ambos botones de unión
completamente.
2
4. Encender la impresora
1 Cierre la cubierta superior.
2 Conecte el cable de alimentación.
Atrás
No conecte ningún cable excepto el de
alimentación.
3 Pulse el botón ACTIVADO (ON).
Encendida
Si la luz de Alarma (Alarm) parpadea, consulte
"Si la luz parpadea" en la página 3 para resolver
el error.
Parpadeando
5. Verter la tinta
Este producto un tratamiento cuidadoso de la tinta,
ya que puede salpicar cuando se rellenan de tinta los
depósitos de tinta. Es posible que las manchas de tinta
no salgan de la ropa u otras pertenencias.
1 Abra la cubierta superior.
2 Abra la cubierta del depósito de tinta.
3 Agarre y retire la tapa del depósito del depósito
de tinta.
4 Sujete el frasco de tinta hacia arriba y retire
la tapa del frasco.
5 Inserte el inyector del frasco de tinta en la entrada
y coloque el frasco de tinta boca abajo.
