Canon EOS 70D User manual

This basic manual covers only the most basic operations.

For other features and more details, see the

Camera Instruction Manual pdf le in the CD-ROM.

* The EOS 70D (N) does not have the Wi-Fi functions explained in this manual.

Basic Instruction Manual

EOS 70D (W)

EOS 70D (N)

COPY

The EOS 70D (W/N) is a high-performance, digital single-lens reflex

camera featuring a fine-detail CMOS sensor with approx. 20.2 effective

megapixels, DIGIC 5+, high-precision and high-speed 19-point AF (all

cross-type focusing), approx. 7.0 fps continuous shooting, Live View

shooting, Full High-Definition (Full HD) movie shooting, and Wi-Fi

function*.

The camera is highly responsive to any shooting situation at any time,

provides many features for demanding shots, and expands shooting

possibilities with various system accessories.

* The EOS 70D (N) does not have the Wi-Fi function.

Refer to This Manual while Using the Camera to Further

Familiarize Yourself with the Camera

With a digital camera, you can immediately view the image you have

captured. While reading this manual, take a few test shots and see how

they come out. You can then better understand the camera.

To avoid botched pictures and accidents, first read the “Safety

Warnings” (p.159-161) and “Handling Precautions” (p.14, 15).

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images or copyrighted music and images with music in the memory

card for anything other than private enjoyment. Also be aware that

certain public performances, exhibitions, etc., may prohibit photography

even for private enjoyment.

Introduction

COPY

The camera can use the following cards regardless of capacity:

• SD memory cards

• SDHC memory cards*

• SDXC memory cards*

* UHS-I cards supported.

When shooting movies, use a large-capacity card with a fast reading/

writing speed as shown in the table.

If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card

with a slow reading speed, the movie may not play back properly.

If you want to shoot still photos while shooting a movie, you will need

an even faster card.

To check the card’s reading/writing speed, refer to the card

manufacturer’s Web site.

Compatible Cards

Cards that Can Record Movies

Compression Method (p.137) Card

IPB 6 MB/sec. or faster

ALL-I (I-only) 20 MB/sec. or faster

In this manual, “card” refers to SD memory cards, SDHC memory

cards, and SDXC memory cards.

*The camera does not come with a card for recording images/

movies. Please purchase it separately.

COPY

Before starting, check that all the following items have been included

with your camera. If anything is missing, contact your dealer.

* Battery Charger LC-E6 or LC-E6E is provided. (The LC-E6E comes with a

power cord.)

The Instruction Manuals and CD-ROMs provided are listed on the next page.

If you purchased a Lens Kit, check that the lenses are included.

Depending on the Lens Kit type, a lens instruction manual may also be

included.

Be careful not to lose any of the above items.

Item Check List

Battery Pack

LP-E6

(with protective cover)

Battery Charger

LC-E6/LC-E6E*

Interface Cable

Camera

(with body cap)

Wide Strap

EW-EOS70D

COPY

The instruction manual consists of booklets and electronic manuals

(PDF files on the CD-ROM). Basic operations are explained in the

booklets. For detailed instructions on all functions and operations,

see the detailed version manuals on the CD-ROM.

* Not provided with the EOS 70D (N).

Camera Instruction Manual CD-ROM

Contains the following manuals in PDF:

• Camera Instruction Manual (Detailed version)

• Wi-Fi Function Instruction Manual (Detailed version)

• Quick Reference Guide

Instructions for viewing the Camera Instruction Manual

CD-ROM are on page 150.

Software CD-ROM (EOS DIGITAL Solution Disk)

Contains various software. For outlines and installation

procedure of the software, see pages 154-156.

Software Instruction Manual CD-ROM

Contains software manuals in PDF. Instructions for viewing

the Software Instruction Manual CD-ROM are on page

157

Instruction Manual and CD-ROMs

Camera Basic

Instruction Manual

(this booklet)

Quick Reference Guide

Wi-Fi Function

Instruction Manual*

(Basic)

Wi-Fi Cautions*

The Basic Instruction Manual explains the basic procedures and features.

For detailed instructions, see the Camera Instruction Manual CD-ROM.

COPY

Quick Start Guide

1Insert the battery (p.26).

To charge the battery, see page 24.

2Insert a card (p.27).

With the card’s label facing

toward the back of the

camera, insert it into the

card slot.

3Attach the lens (p.36).

Align the lens’ white or red mount

index with the camera’s mount

index of the same color.

4Set the lens focus mode switch

to <f> (p.36).

5Set the power switch to <1>,

then set the Mode Dial to <A>

(Scene Intelligent Auto) (p.66).

Turn the Mode Dial while holding down

the lock release button at the center.

All the necessary camera settings

will be set automatically.

White index Red index

COPY

Quick Start Guide

6Flip out the LCD monitor (p.30).

When the LCD monitor displays the

date/time/zone setting screens, see

page 33.

7Focus the subject (p.41).

Look through the viewfinder and

aim the viewfinder center over the

subject.

Press the shutter button halfway.

The camera will focus the subject.

If necessary, the built-in flash will be

raised.

8Take the picture (p.41).

Press the shutter button completely

to take the picture.

9Review the picture (p.56).

The captured image will be

displayed for 2 sec. on the LCD

monitor.

To display the image again, press

the <x> button (p.140).

To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.119).

To view the images captured so far, see “Image Playback” (p.140).

To delete an image, see “Erasing Images” (p.147).

COPY

Icons in this Manual

<6> : Indicates the Main Dial.

<5> : Indicates the Quick Control Dial.

<9> <V> <U> : Indicates the Multi-controller and the push

direction.

<0> : Indicates the Setting button.

0, 9, 7, 8: Indicates that the corresponding function

remains active for 4 sec., 6 sec., 10 sec., or 16

sec. respectively after you let go of the button.

* In this manual, the icons and markings indicating the camera’s buttons, dials,

and settings correspond to the icons and markings on the camera and on the

LCD monitor.

3: Indicates a function that can be changed by pressing the

<M> button and changing the setting.

M: When shown on the upper right of a page, it indicates that

the function is available only in the Creative Zone modes

(p.20).

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Problem-solving advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is set to <1> and the <R> switch is set down (Multi function

lock released) (p.31, 44).

It is assumed that all the menu settings and Custom Functions are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-135mm f/3.5-5.6 IS STM lens as an example.

Conventions Used in this Manual

COPY

For first-time DSLR users, Chapters 1 and 2 explain the camera’s

basic operations and shooting procedures.

Chapters

Introduction 2

Getting Started 23

Basic Shooting 65

Setting the AF and Drive Modes 87

Image Settings 97

Advanced Operations 109

Shooting with the LCD Monitor

(Live View Shooting)

119

Shooting Movies 133

Image Playback 139

Viewing the CD-ROM Instruction Manuals /

Downloading Images to Your Computer 149

COPY

Introduction 2

Compatible Cards............................................................................. 3

Item Check List................................................................................. 4

Instruction Manual and CD-ROMs ................................................... 5

Quick Start Guide............................................................................. 6

Conventions Used in this Manual..................................................... 8

Chapters........................................................................................... 9

Handling Precautions ..................................................................... 14

Nomenclature................................................................................. 16

Getting Started 23

Charging the Battery ...................................................................... 24

Installing and Removing the Battery............................................... 26

Installing and Removing the Card .................................................. 27

Using the LCD Monitor................................................................... 30

Turning on the Power..................................................................... 31

Setting the Date, Time, and Zone .................................................. 33

Selecting the Interface Language................................................... 35

Attaching and Detaching a Lens .................................................... 36

Lens Image Stabilizer..................................................................... 39

Basic Operation.............................................................................. 40

QQuick Control for Shooting Functions....................................... 46

3Menu Operations.................................................................. 48

dUsing the Touch Screen............................................................. 50

Before You Start............................................................................. 53

Displaying the Grid......................................................................... 58

QDisplaying the Electronic Level............................................... 59

Feature Guide and Help................................................................. 63

Contents
