Canon Digital IXUS 900 TI User manual
The Components Guide
Preparations
Shooting
Playback/Erasing
Menus and Settings
Camera User Guide
Please Read This First
This guide explains how to prepare the camera and use its basic features.
ENGLISH
Basic
CEL-SF9PA210
Downloading Images
to a Computer
Printing
Cov-Basic.fm Page 1 Monday, July 24, 2006 1:10 PM
The following guides are available. Refer to them as necessary according
to the flowchart below.
Flowchart and Reference Guides
System Map
Basic Camera User
Guide (This Guide)
• Read this first.
Advanced Camera
User Guide
Direct Print User
Guide
Basic Camera User
Guide (This Guide)
Software Starter
Guide
For information on included items
and items sold separately
The Components Guide
Preparations
• Charging the battery
• Installing the battery and memory card
• Setting the date, time and language
Shooting
Playback/Erasing
Menus and Settings
Handling precautions, references
to the various shooting and
playback functions
Printing
• Installing the software
• Downloading images to a computer
• Using the software
In this guide, the Basic Camera User Guide is called the Basic Guide, and
the Advanced Camera User Guide is called the Advanced Guide. Also,
"battery" refers to the battery pack.
Viewing the PDF Manuals
Adobe Reader or Adobe Acrobat Reader must be installed to view the
PDF Manuals. If this software is not installed in your computer, access
the following web site and download the software.
http://www.adobe.com/products/acrobat/readstep2.html
1
Front View
Wrist Strap Mount
Microphone (Advanced Guide pp. 42, 86)
AF-assist Beam (Advanced Guide p. 24)
Red-Eye Reduction Lamp (Advanced Guide p. 33)
Self-Timer Lamp (p. 16)
Viewfinder Window (Advanced Guide p. 18)
Flash (p. 14)
Lens
* When carrying the camera by the strap, be careful not to swing the camera or catch
it on other items.
The Components Guide
Attaching the Wrist Strap*
The Components Guide
2
Back View
LCD Monitor (Advanced Guide pp. 12, 15)
Viewfinder (Advanced Guide p. 18)
DIGITAL Terminal (p. 27)
A/V OUT (Audio/Video output) Terminal (Advanced Guide p. 103)
Terminal Cover
Tripod Socket
Memory Card Slot/Battery Cover Lock Release Switch (p. 7)
DC Coupler Terminal Cover (Advanced Guide p. 125)
Memory Card Slot/Battery Cover (p. 7)
The interface cable and AV cable cannot be connected
simultaneously.
3
Controls
Speaker
Indicators (p. 5)
Power Lamp
ON/OFF Button (p. 10)
Zoom Lever (p. 14, Advanced Guide p. 73)
Shooting: (Wide Angle)/ (Telephoto)
Playback: (Index)/ (Magnify)
Shutter Button (p. 10)
Mode Dial (pp. 10, 11)
(Print/Share) Button (pp. 22, 30)
DISP. (Display) Button (Advanced Guide p. 12)
FUNC./SET (Function/Set) Button (p. 20, Advanced Guide p. 22)
Touch Control Dial (pp. 4, 18)
MENU Button (p. 21, Advanced Guide p. 23)
(Macro)/ (Infinity)/ Button (p. 15)
(ISO Speed)/ (Jump)/ Button (Advanced Guide pp. 65, 76)
(Flash)/ Button (p. 14)
(Single Image Erase)/ (Continuous)/ (Self-timer)
/ Button (pp. 16, 19, Advanced Guide p. 37)
The Components Guide
4
Touch Control Dial
Placing a finger on the touch control dial displays the playback mode
and shooting mode touch icons on the LCD monitor. You can confirm
the functions assigned to each button.
• Unavailable buttons are grayed out.
• Place a finger on the touch control dial over a function you want to
set, and the icon will enlarge on the LCD monitor.
• You can easily select images using the touch control dial during play-
back (p. 18).
• You can easily select time zones for the world clock using the touch
control dial (Advanced Guide p. 20).
• You can set the touch icons to On/Off in the (Set up) menu
(Advanced Guide p. 26).
Sample of shooting mode
Touch Icons
5
Indicators
The camera indicators light or flash under the following
circumstances.
Right Indicator
Green: Ready to shoot
Blinking Green: Image recording/reading/erasing/transferring
(when connected to a computer)
Orange: Ready to shoot (flash on)
Blinking Orange: Ready to shoot (camera shake warning)
Left Indicator
Yellow: Macro mode/infinity mode/AF lock mode
Blinking Yellow: Focusing difficulty (camera beeps once)
Never do the following while an indicator is flashing green.
These actions may corrupt image data.
• Shake or jolt the camera
• Shut off the power, or open the memory card slot/battery
cover
The Components Guide
6
1.
Charging the Battery.
Charge the battery before use under the following circumstances.
• When using the battery for the first time.
• When the "Change the battery pack" message displays.
1. Insert the battery into the battery charger.
2. Plug the battery charger (CB-2LX) into a power outlet, or
attach the power cord to the battery charger (CB-2LXE) and
plug it into a power outlet.
• Battery charger model names and types vary by region.
The charge indicator will light orange while the battery is
charging. It will change to green when the charge is complete.
Charging takes approximately 2 hours 5 minutes.
Preparations
To protect the battery and prolong its life, do not charge it
for longer than 24 hours continuously.
ÎSee the Advanced Guide: Battery Handling(p. 121).
Charge Indicator
For CB-2LX For CB-2LXE
Align these symbols
7
2.
Installing the Battery.
1. Slide the lock release switch in the direction of the arrow
( ), and open the memory card slot/battery cover ( ).
2. Push the battery lock in the direction of the arrow ( ) and
insert the battery until it locks.
To remove the battery, push the battery lock in the direction of
the arrow ( ) and hold it while pulling the battery out.
3.
Inserting the Memory Card.
1. Insert the memory card until it clicks into place.
2. Close the memory card slot/battery cover.
Ensure that the memory card is correctly oriented before
inserting it in the camera. Inserting it backward may cause
the camera to fail to recognize the memory card or to
malfunction.
Î
See the Advanced Guide: Handling theMemory Card (p. 123).
ÎSee the Advanced Guide: Formatting Memory Cards (p. 29).
Battery Lock
Back
Back
Preparations
8
To Remove the Memory Card
Use a finger to push the memory card in until you hear a click, then
release it.
You can use SD memory cards, SDHC memory cards and MultiMediaCards
with this camera.
These cards are collectively called memory cards in this guide.
