Canon PIXMA MP270 User manual

Make sure to read this manual before using the machine. Please keep it in hand for future reference.

Getting Started

Read Me First

series

Photo All-In-One

series

Model Number: K10339 (MP250)

Internet Explorer is a trademark or registered trademark of Microsoft Corporation in the

U.S. and/or other countries.

•

Microsoft is a registered trademark of Microsoft Corporation.•

Windows is a trademark or registered trademark of Microsoft Corporation in the U.S.

and/or other countries.

•

Windows Vista is a trademark or registered trademark of Microsoft Corporation in the

U.S. and/or other countries.

•

Symbols Used in This Document■

Instructions as notes for operation or additional

explanations.

Instructions including important information. Be sure to

read these indications.

Descriptions for operations that take some time to

complete.

Model Number: K10339 (MP270)

This manual describes about MP270 and MP250.

The illustrations and screens are based on MP270. The instructions are

the same unless otherwise specied.

You may not be able to purchase some models in certain regions.

About This Manual■

MP270 MP250

Indicates operations in Windows.

Indicates operations in Macintosh.

Macintosh and Mac are trademarks of Apple Inc., registered in the U.S. and other

countries.

•

After Installing the Machine

Install the Software

Install the FINE Cartridges

Turn the Power On

Remove the Protective Material

Loading Paper

Preparation

Contents

2 3 4 5 61

1Preparation

Before turning on the machine, remove all orange tapes and protective sheets from

the inside and outside of the machine.

power cordFINE Cartridges

Color Black

A USB cable (A-B type) is necessary to connect the machine with your computer.•

Manuals•

Setup CD-ROM (containing the drivers, applications and on-screen manuals)•

Warranty•

Check the Included Items■

Choosing a Location□

Do not install the machine where an object may fall on it. The

object may fall inside the machine, resulting in malfunction.

•

Do not place any object on top of the machine. It may fall into

the machine when opening covers, resulting in malfunction.

•

The FINE

Cartridges and

power code are

placed inside of the

Paper Output Tray

(A).

Open the Paper

Output Tray with your

hands, and take out

the FINE Cartridges

and power code.

13 4 5 62

1234

2Remove the Protective Material

Open the Paper Output

Tray (A).

Lift the Scanning Unit (Cover) (B) and

x it with the Scanning Unit Support (C).

Lift the Scanning Unit (Cover) slightly and fold

the Scanning Unit Support, then gently close the

Scanning Unit (Cover).

Pull the orange protective tape

(D) and remove the protective

material (E).

1 2 4 5 63

Turn the Power On

Plug the power cord into the left side of the machine,

then connect the other end to the wall outlet.

Turn on the machine (B).

Do NOT connect the USB cable at this stage.•

Make sure that the Document Cover (A) is closed.•

Make sure that the POWER lamp (B) lights

green.

MP270

MP250

MP270

MP250

1 2 3 5 64

4Install the FINE Cartridges

Be sure to use the supplied FINE Cartridges.•

Lift the Scanning Unit (Cover) (A) and x it with the Scanning Unit Support (D).

Handle the FINE Cartridges carefully. Do not

drop or apply excessive pressure to them.

•

If the Scanning Unit (Cover) is left open for more than 10 minutes, the FINE Cartridge Holder moves to the right. In this

case, close and reopen the Scanning Unit (Cover).

•

The FINE Cartridge Holder (F) moves to the installation position.

If the FINE Cartridge Holder does not move, make sure that the machine is turned on.•

Close the Document Cover (E) and lift it with the Scanning Unit (Cover).

Open the Ink Cartridge Locking Cover on the right side.

Pinch (G) rmly and pull up the cover.

Remove the Black FINE Cartridge

from its package.

Be careful not to stain your hands or surrounding work area with ink on the removed protective tape.•

Pull the orange protective tape (H) in the direction of

the arrow and remove it gently.

Do not touch the electrical contacts (I) or print head nozzles (J) on a FINE Cartridge. The machine may not print

properly if you touch them.

•

1 2 3 5 64

Push down of the Ink Cartridge Locking Cover until you hear a click to

close it completely.

View the Ink Cartridge Locking Cover straight on and check that it is locked

correctly (not at an angle).

Place the Black FINE Cartridge into the right slot .

Do not knock the FINE Cartridge against the sides of the holder.•

Install the Black FINE Cartridge into the right slot, and the Color FINE Cartridge into the left

slot.

•

Install in a well-lit environment.•

7 8

1 2 3 5 64

Insert the Color FINE Cartridge into the left FINE

Cartridge Holder in the same way as .

Wait until "1" appears on the LED (K) (about 1-2 minutes) and go to the next step.•

Once you have installed the FINE Cartridges, do not remove them unnecessarily.•

Lift the Scanning Unit (Cover) slightly and fold the Scanning Unit Support, then gently close the

Scanning Unit (Cover).

If the Alarm lamp (L) lights orange, make sure that the FINE Cartridges are correctly installed.•
