Cambridge Audio Min 10 User manual

IBMR (Balanced Mode Radiator) full range driver

combining bending wave technology for higher

frequencies, with pistonic driver movement for lower

frequencies

IIncredibly wide dispersion from the BMR driver virtually

eliminates any ‘sweet spot’ problem

IBMR technology offers wide frequency response

from a single driver, allowing for optimum integration

with a subwoofer

IAcoustically damped thermo polymer and extruded

aluminium cabinet construction ensuring a rigid speaker

cabinet to disperse colouration

IScratch resistant high gloss lacquer available in black

or white finishes

IOptional table top or floor stands available

Minx Satellites Specifications

www.cambridge-audio.com

Sensitivity (SPL) 85dB (2.83 Vrms input)

Frequency response 140Hz-20kHz

Impedance 8 Ohms compatible

Power Handling 15-50 W Recommended

Drivers 1x 2.25” BMR

Dimensions (H x W x D) 78 x78 x 85mm

(3.1 x 3.1 x 3.3”)

Weight 0.43kg (0.95lbs)

Finishes High gloss black

High gloss white

Sensitivity (SPL) 87dB (2.83 Vrms input)

Frequency response 130Hz-20kHz

Impedance 8 Ohms compatible

Power Handling 15-75 W Recommended

Drivers 2x 2.25” BMR

Dimensions (H x W x D) 154 x78 x 85mm

(6.0 x 3.1 x 3.3”)

Weight 0.75kg (1.65lbs)

Finishes High gloss black

High gloss white

Min10 specifications Min20 specifications

Min10 Min20

www.cambridge-audio.com

IPowerful DSP design delivering awesome performance

from the smallest footprint possible

IPowerful 200W, 300W and 500W digital amplifiers

IOne piece aerospace grade aluminium cones move air

with incredible efficiency

IDSP design allows far smaller cabinet construction than

comparative subwoofers

ISupplied with removable grilles

IFull rear panel control of gain, phase and crossover

frequency allowing optimum integration and room

positioning

IDriver plus ABR (Auxillary Bass Radiator)

configuration. ABRs replace bass ports to eliminate

air noise at high levels

IScratch resistant high gloss lacquer available in

black or white finishes

IFuture wireless option

Minx Subwoofer Specifications

Power Output 200W

Frequency Response 39Hz (-6dB) – 200Hz

Crossover Active – variable 50Hz-200Hz

Mains voltage 100V/110-120V/220-240V

Drivers 1 x 6.5" subwoofer

2 x 6.5" passive radiator

Dimensions 219 x 210 x 222mm

(H x W x D) (8.6 x 8.3 x 8.7")

Weight 5.0Kg (11.0lbs)

Finishes High gloss black

High gloss white

Power Output 300W

Frequency Response 33Hz (-6dB) – 200Hz

Crossover Active – variable 50Hz-200Hz

Mains voltage 100V/110-120V/220-240V

Drivers 1 x 8" subwoofer

1 x 8" passive radiator

Dimensions 311 x 266 x 278mm

(H x W x D) (12.4 x 10.5 x 11.0")

Weight 7.5Kg (16.5lbs)

Finishes High gloss black

High gloss white

Power Output 500W

Frequency Response 23Hz (-6dB) – 200Hz

Crossover Active – variable 50Hz-200Hz

Mains voltage 100V/110-120V/220-240V

Drivers 1 x 10" subwoofer

1 x 10" passive radiator

Dimensions 365 x 320 x 350mm

(H x W x D) (14.3 x 12.6 x 13.8")

Weight 11.7Kg (25.8lbs)

Finishes High gloss black

High gloss white

X200 specifications X300 specifications X500 specifications

X200 X300 X500

35.5

30.5

25.5

20.5

15.5

10.5

Inches

14"

13"

12"

11"

10"
