Calculated Industries ConstructionMaster HeavyCalc 4320 User manual
This equipment has been certified to comply
with the limits for a Class B computing device,
pursuant to Subpart J of Part 15 of FCC rules.
Software copyrighted and licensed to
Calculated Industries, Inc. by
Construction Master Technologies, LLC, 2004.
Pocket Reference Guide copyrighted by
Calculated Industries, Inc. © 2004.
HeavyCalc™ is a trademark, and
Construction Master® and Calculated Industries® are
registered trademarks of Calculated Industries, Inc.
ALL RIGHTS RESERVED
CALCULATED INDUSTRIES®
4840 Hytech Drive
Carson City, NV 89706 U.S.A.
1-800-854-8075 Fax: 1-775-885-4949
www.calculated.com
Designed in the USA
Printed in China
4320PRG-E-A
6/04
Pocket Reference Guide
➡
➡
Insert This
Direction
f
C
ONSTRUCTION
M
ASTER
®
H
EAVY
C
ALC
™
ADVANCED FEET-INCH-FRACTION CALCULATOR
Model 4320
POCKET REFERENCE GUIDE — 1
Designed for today’s excavation and heavy
construction professional, the
Construction
Master®HeavyCalc
adds even more power
to the
Construction Master
line-up. As with
earlier models, this calculator is so simple
to use, even the novice will find it easy to
solve hundreds of dimension-related prob-
lems in Feet, Inches, Fractions and Cubic
Yards!
• Solve Dimensional Math with Ease
• Instant Dimensional Conversions
• Imperial/Metric Conversions
• Weight/Volume Conversions
• Calculate Square and Rectangular Areas
• Find Cubic Volumes
• Determine % Grade and Slope
• Solve Cut and Fill
• Find Bank, Loose and Compact Volumes
• Instant Square-Up (Diagonal) Solutions
• Constant Add Feature
• Calculating Averages
• Material Estimations
• Paperless Tape
HEAVYCALC™
4320PRG-E-A 6/16/04 7:53 AM Page 1
POCKET REFERENCE GUIDE — 2
GETTING STARTED...............................3
Key Definitions.....................................3
Fractional Settings.............................11
Entering Dimensions .........................12
Conversions.......................................13
Basic Math Operations......................15
Percentage Calculations....................17
Memory Operation.............................18
Paperless Tape..................................20
USING THE HEAVYCALC ....................22
Linear Division...................................22
Linear Addition...................................22
Area Calculations ..............................23
Volume Calculations..........................24
Right Triangle Problems....................29
Basic Cut/Fill Solutions......................34
Shrink and Swell Solutions —
Material Volume
.............................38
APPENDIX ............................................42
Accuracy/Errors.................................42
Battery and Auto Shut-Off .................44
Full Reset/All Clear............................44
Default Settings.................................44
Area Formulas...................................45
Surface Area and Volume Formulas..46
REPAIR AND RETURN.........................47
Warranty, Repair and Return
Information.......................................47
WARRANTY..........................................48
TABLE OF CONTENTS
4320PRG-E-A 6/16/04 7:53 AM Page 2
POCKET REFERENCE GUIDE — 3
KEY DEFINITIONS
Basic Function Keys
+ – x Arithmetic operation keys.
÷ =
%
Percent Key
— Four-func-
tion (+, –, x, ÷) percent key.
0– 9Keys used for entering
and •numbers.
O
Off Key
— Turns all power
off, clearing all non-perma-
nent registers.
o
On/Clear Key
— Turns on
power. Pressing once clears
the display. Pressing twice
clears all temporary values.
Ç
Convert Key
— Used with
the dimensional keys to
convert between dimen-
sions or with other keys to
access special functions.
c
Constant Key
— This key
stores a value permanently.
Used as a constant in
repeated calculations.
GETTING STARTED
4320PRG-E-A 6/16/04 7:53 AM Page 3
POCKET REFERENCE GUIDE — 4
Ç c
Square Root
— Used to
find the Square Root of a
non-dimensional or area
value.
µ
Memory Add Key
— Adds
the displayed number to the
value stored within the
semi-permanent Memory.
Ç µ
Memory Minus
—
Subtracts the displayed
value from Memory.
®
Recall Key
— Recalls val-
ues stored in any register.
® µ displays the value
in Memory.
® ®
Memory Display/Clear
—
Displays the value in Memory
and clears the register.
Ç ®
Memory Clear
— Clears
the Memory without chang-
ing the current display.
Dimension Keys
y
Yards Key
— This is an
entry and conversion key.
The entry can be a whole
number or a decimal num-
ber. Used with the Çkey
converts any other dis-
played dimensioned num-
ber to Yards.
4320PRG-E-A 6/16/04 7:53 AM Page 4
POCKET REFERENCE GUIDE — 5
f
Feet Key
— Enters or con-
verts to
Feet
as whole or
Decimal numbers. Also
used with the iand /
keys for entering Feet-Inch
values (e.g., 6 f 9 i
1 / 2). Repeated press-
es during conversions tog-
gle between Decimal Feet
and Feet-Inch-Fractions.
i
Inch Key
— Enters or con-
verts to
Inches
. Entry can
be whole or Decimal num-
bers. Also used with the /
key for entering Fractional
Inch values (e.g., 9 i 1
/ 2). Repeated presses
during conversions toggle
between Fractional and
Decimal Inches.
/
Fraction Bar Key
— Used
to enter
Fractions
. Fractions
can be entered as proper
(1/2, 1/8, 1/16) or improper
(3/2, 9/8). If the denomina-
tor (bottom) is not entered,
the calculator's fractional
accuracy setting is automat-
ically used.
4320PRG-E-A 6/16/04 7:53 AM Page 5
POCKET REFERENCE GUIDE — 6
C
Cubic Key
— This key is
used with a dimension key
(Feet, Inches, Yards,
Meters, etc.) to identify a
value as being a volume.
Example:
5 C y
S
Square Key
— This key is
used with a dimension key
(Feet, Inches, Yards,
Meters, etc.) to identify a
value as being an area.
Example:
1 0 S f
m
Meter Key
— Enters or
converts to
Meters.
M
Millimeter Key
— Enters or
converts to
Millimeters.
w
Weight Key
— Enters or
converts (a volume value) to
Tons, Pounds
or
Kilograms
.
Repeated presses will cycle
through these units.
Ç %
Weight/Volume
— Enters
or converts the
Weight
per Volume
setting as
Tons/Yard3, Lbs/Yd3
or
kg/m3
. Repeated presses
will cycle through these
settings.
4320PRG-E-A 6/16/04 7:53 AM Page 6
POCKET REFERENCE GUIDE — 7
Area/Volume Keys
l
Length Key
— Enters the
value for Length in dimen-
sion problems (e.g., for cal-
culating Area or Volume).
Note: this key is also used to
enter the length for “Square-
Ups.”
Ç l
Square-Up
— Calculates
the Diagonal, or “Square-
Up,” based on entered
Length and Width.
W
Width Key
— Enters the
value for Width in dimension
problems (e.g., calculating
Area or Volume).
Note: this key is also used to
enter the width for “Square-Ups.”
Ç W
Percent Grade
— Used to
enter and/or solve Percent
Grade. Calculates Percent
Grade using entered values
for Width and Depth or
Slope.
d
Depth Key
— Enters the
value for Depth in dimen-
sion problems. Calculates
Depth from entered values
of Width and Percent
Grade or Slope.
4320PRG-E-A 6/16/04 7:53 AM Page 7
POCKET REFERENCE GUIDE — 8
Ç d
Slope
— Used to enter
Slope as a ratio of Run per
Unit Rise (e.g., 4:1), or in
Decimal Degrees (e.g.,
10°). Also calculates Slope
using entered value for
Width and Depth or Percent
Grade.
v
Volume Key
— Computes
the Volume (Length x Width
x Depth) in Cubic Yards
based on entered Length,
Width and Height values. A
second press will display
the area (in Square Feet)
based on entered Length
and Width. Successive
presses will toggle the dis-
play between the calculated
Area and Volume.
Ç v
Area
—Computes the area
in Square Feet based on
entered Length and Width.
Excavation/Volume Keys
FUsed to enter or calculate
the cut or fill amount. Based
on entries of proposed and
existing benchmarks. A fill
is displayed as a positive
value; a cut as a negative
value.
4320PRG-E-A 6/16/04 7:53 AM Page 8
POCKET REFERENCE GUIDE — 9
e
Existing Key
— Used to
enter or calculate an exist-
ing benchmark, Grade or
value.
p
Proposed Key
— Used to
enter or calculate a pro-
posed benchmark, Grade
or value.
b
Bank Volume Key
—
Enters or calculates the vol-
ume for bank fill material.
Bank fill is material in an
untouched, pristine state.
ç
Compacted Volume Key
— Enters or calculates the
volume for compacted fill
material. Compacted fill is
material that has been
compacted.
Ç ç
% Shrink
— Enters or
recalls percent shrink factor
for converting between bank
and compacted fill volumes.
L
Loose Volume Key
—
Enters or calculates the vol-
ume for loose fill material.
Loose fill is material that
has been disturbed or
excavated.
Ç L
% Swell
— Enters or recalls
the percent swell factor used
for converting between
bank and loose volumes.
4320PRG-E-A 6/16/04 7:53 AM Page 9
