CABASSE ANTIGUA IW - User manual

ANTIGUA IW

ANTIGUA IW

Thanks to its ultra thin grille, with magnetic link fastening, which hides the new 17T20 IW woofer and DOM36 midrange

tweeter, from the MT range of loudspeakers, the new Antigua IW combines discrete aesthetics and elegance with the

Cabasse fidelity to live sound.

Easy installation, easy matching to any amplifier, thanks to high efficiency and impedance, the Antigua IW is the high-

performance solution for domestic and professional installs, for stereo sound or for surround effects. Perfection in

sound and integration.

ANTIGUA IW

Cabasse SA - 210, rue René Descartes - BP 10 - 29280 Plouzané - France

Tel +33 (0)2 98 05 88 88 - Fax +33 (0)2 98 05 88 99

www.cabasse.com

Use in wall / in ceiling

Ways 2

Drivers

1 x DOM36 tweeter

Kaladex® membrane

1 x 17T20 IW midrange-woofer

P2C diaphragm

Cross-over point 1,800 Hz

Frequency response 53 Hz - 22,400 Hz

Sensitivity 1 W / 1 m 88 dB

Nominal impedance 8 ohms

Minimum Impedance 6.8 ohms

Power handling 40 W

Peak power 320 W

Dimensions (H x W x D) 32 x 23 x 8.8 cm - 12.6 x 9.1 x 3.5 in

Weight 2.2 kg - 4.9 lbs

Standard finish white (paintable grille)

ANTIGUA IW

232 mm (9.1in) 83,50 mm (3.3in)

88,40 mm (3.5in)

318 mm (12.5in)
