YEAR-ROUND COMFOR T

Comfort Control at Your Fingertips.

YEAR-ROUND COMFOR T

NON-PROGRAMMABLE

THERMOSTAT

HOMEOWNER’S GUIDE

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 1

- ii -

CONGRATULATIONS

- i -

INTELLIGENT, EASY TO USE

Congratulations on your purchase of a new Bryant

thermostat. Your new thermostat combines computer-

like intelligence with extremely simple operation in an

elegant package. Designed to maximize performance,

your Bryant thermostat provides reliable, accurate tem-

perature control while blending into any home’s decor. As

you read on, you’ll quickly see how easy it is to set up

and operate your new thermostat and enjoy the comfort

of your home.

COMFORT AT YOUR COMMAND

Bryant has met the needs of homeowners nationwide

with their non-programmable thermostat. Controlling your

heating and cooling system at the touch of a button, this

powerful device helps deliver comfort year round.

MAKING LIFE EASIER

Take a few minutes to review the features and functions

listed at the right. Bryant gives you control over your

comfort with simple instructions, responsive push buttons

and an easy-to-read backlit display. Once set, this

thermostat reliably monitors indoor temperature and

responsively meets your comfort demands.

FAN Button

chooses

between CON-

TINUOUS FAN

and AUTO FAN

operation.

Up and Down

Buttons increase or

decrease the desired

temperature setting.

MODE Button

selects between OFF,

HEAT, COOL, AUTO, and

OFF operation. Heat

pump thermostat models

also include an EMER-

GENCY HEAT mode.

Outdoor

Temperature

Displayis an

optional feature

that shows the

outdoor temper-

ature on the

LCD readout.

LOW BATTERY

Indicator will

light when

batteries (if

installed) need

to be replaced.

SERVICE FILTER

Indicator lets you

know it is time to

clean or replace your

system’s air filter.

Room Temperature

Displayshows current

room temperature.

COOL ON Indicator is

displayed when the

cooling equipment is

operating.

HEAT ON Indicator

is displayed when the

heating equipment is

operating.

RESET FILTER

Button restarts

the timer that

calculates the

next air filter

change or

cleaning.

AUXILIARY HEAT

Indicator is dis-

played when a

heat pump sys-

tem is operating

with auxiliary heat

air filter.

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 2

- iii -

TABLE OF CONTENTS

- 1 -

S E T TING AND OPERATING THE THERMOSTAT . . . . . . . . . . . . 2

Se tting your indoor tempera t u r e set point s . . . . . . . . . . . . . . 2

Se tting the fan opera t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Se tting the mode opera t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Checking the outdoor t e m p e ra t u r e. . . . . . . . . . . . . . . . . . . . . . 4

Se rvice filter fe a t u re . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

B a tt e rychange ou t . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

AU T O CHANGEOV E R . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . 6

W H AT IF . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . 7

The AU X I L I A RY HEAT i n d i ca t o r is di s p l a y e d . . . . . . . . . . . . . . 7

The SERVICE FILT E R i n d i cator is di s p l a y e d . . . . . . . . . . . . . . 7

You have a power ou t a g e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

You have a system error message. . . . . . . . . . . . . . . . . . . . . . . 7

The ba tteries are low . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

COMMON TERMS AND WHERE TO FIND THEM . . . . . . . . . . . 9

WA R R A N T Y . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 1 2

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 4

TABLE OF CONTENTS

- 3 -

TABLE OF CONTENTS SETTING & OPERATING THE THERMOSTAT

S e tting fan operat i o n

1P ress the FAN bu tton to switch betwe e n

ON and AU TO fan se tt i n g s .

FAN on indi cator will be di s p l a y e d

on LC D . When the ON mode is

selected, the fan runs cont i n u o u s l y

for improved air circ u lation.

When the AU TO mode is se l e c t e d ,

the fan runs only as needed to

m a i ntain your desired indoor tem-

p e r a t u re. FAN on indi cator is not

di s p l a yed on LC D .

S e tting mode operat i o n

1P r ess the MODE bu tt o n .

2On the LCD re a d o u t , the wo rds OFF,

H E AT, COOL, and AU TO will rotate as the

MODE bu tton is pre s se d .

If you have a heat pu m p , the LC D

re a d o ut will show OFF, HEAT,

C O O L , AU T O, and EMERG E N C Y

H E AT (EHEAT ) .

N OT E: In AU T O mode, your system will

heat OR cool as needed to reach you r

COOL

FAN

H E A T COOL A U T O

OFF

COOL

SETTING & OPERATING THE THERMOSTAT

S e tting your indoor te m p e r at u r e set points

1P r ess the UP or DOWN bu tt o n .

The LCD re a d o ut will be illuminated and

the heating or cooling tempera t u rese t

p o i n t will be di s p l a y ed, but will not

c h a n g e . Next to the tempera t u r e

di s p l a y, HEAT or COOL indi ca t e s

which tempera t u re set point is

being di s p l a y e d .

2Co nt i n ue to press the UP or DOWN bu t -

tons until your desired heating or cooling

t e m p e r a t u re set point isdi s p l a ye d .

3P ress the MODE bu tton to select the

second tempera t u re se tting (either

H E AT or COOL).

4P ress the UP or DOWN bu ttons until you r

second desired tempera t u r e set point is

di s p l a y e d .

N OT E: Your COOL se tting must be at least

2˚ h i gher than your HEAT se tting. You r

thermostat will automatically change you r

p rev i o usly set tempera t u r e to maint a i n

that 2˚ di f fe re n c e .

SET TEMP

COOL

- 2 -

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 2

TABLE OF CONTENTS

- 5 -

TABLE OF CONTENTS

- 4 -

SETTING & OPERATING THE THERMOSTAT

B a tte ry change ou t

If the installation re q u i r es the usage of ba tteries, the

ba tteries will re q u i re re p l a c e m e n t eve ry 12 mont h s .

1Open door on thermostat.

2S l ide ba tt e ry compa rt m e n t door to the right.

3Re m ove two AA alk a l ine ba tt e r i e s .

4Fo l l ow polarity markings (+ / –) on the thermo-

s t a t .

5I n s t a l l two new AA alk a l ine ba tteries and re p l a c e

ba tt e ry door.

N OT E: If installation is hard - w i r ed, batteries are

not re qu i r ed or will not need re p l a c e m e n t.

SETTING & OPERATING THE THERMOSTAT

d e s i r ed tempera t u r e. AU TO mode may be

di sab l e d .

Checking the ou tdoor te m p e r at u r e

1P ress the UP and DOWN bu ttons

s i m ult a n e o usly for 20 seconds then

re l e a se.

2The outdoor tempera t u re will show on the

LCD re a d o u t .

N OT E: If 2 dashes (- - ) ap p e a r, your

thermostat does not include the

outdoor tempera t u re function or

the function is not working pro p e r l y.

Check with your dealer if you are

u n s u r e.

S e rvice filter fe a t u r e

Your thermostat reminds you when it’s

time to change or clean your filter by

displaying the SERVICE FILTER

i n di ca t o r.

1P ress the RES ET FILTER bu tton after you

h a v e changed or cleaned your filter to

re s t a rt the timer.

OD TEMP

SERVICE FILTER

COOL

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 4

TABLE OF CONTENTS

- 6 - - 7 -

WHAT IF…

The AU X I L I A R Y HEAT indicator is displaye d …

The AUX HEAT indi cator appears on the heat pu m p

ve rsion of the thermostat only. It is di s p l a yed when

your system is operating on au x i li a r y heat.

N OT E: This indicator does not re f l e c t a pro b l e m

with your sy s t e m .

The SERV I C E F I LTER indicator is displaye d …

The SERVICE FILTER indi cator tells you when to

clean or replace your air filt e r. Press the RES ET

F I LTER bu tton after cleaning or replacing the filt e r

to turn off the indi cator and re set the sys t e m .

N OT E: This indicator does not re f l e c t a pro b l e m

with your sy s t e m .

You have a power ou tag e…

An internal power sou rce maintains the desire d

t e m p e ra t u re se t tings indefinitely.

You have a sy stem error messag e …

The tempera t u rese n sor fa i lu r e indi cator sends

a -- re a d ing to the LCD di s p l a y. This means you r

t h e r m o s t a t ’s tempera t u re se n sor is no longer able to

TABLE OF CONTENTSAUTO CHANGEOVER

Your thermostat provides complete, automatic

control over heating and cooling with auto

changeover. Auto changeover means your system

will automatically heat or cool as needed to main-

tain your temperature set points.

Auto changeover makes life easier because you

no longer have to manually switch the thermostat

between heating or cooling operation. Just set

your heating and cooling set points and let the

system do the rest!

NOTE: If auto changeover is not necessary in your

area of the country, your installer may disable the

AUTO mode feature.

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 6

TABLE OF CONTENTS

- 9 -

COMMON TERMS & WHERE TO FIND THEM

Au x i l i a ryHeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 7

Most heat pump systems re q u i re a sup p l e m e n t a l

heating sou r c e , ca l led au x i l i a ryheat, to maintain you r

c o m fo rt when outdoor tempera t u r es fa l l . . . . . . . . . . . .

s i g n i f i c a n t l y. Your thermostat lets you know when

your home is being warmed with sup p l e m e ntal heat.

N OT E: For addi t i o n a l energy savings opport u n i t i e s ,

ask your dealer ab out locking out auxili a ry heat at a

se l e c ted outdoor tempera t u re.

S e rvice Fi lte r . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 4

Your sys t e m’s air filter will re q u i r e re g ular cleaning to

re d uce the di rt and dust in the system and you r

indoor air. The SERVICE FILTER indi c ator lets you

k n o w when it’s time to clean the filt e r.

Fa n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 3

Your sys t e m’s fan can run cont i n u ously or only as

ca lled for during heating or cooling. Co n t i nu o u s

o p e ration helps with air circ u lation and cleaning.

Automatic operation provides energy savings. Pre s s

the FAN bu tton to make your choice.

TABLE OF CONTENTS

- 8 -

WHAT IF…

m e a su r e tempera t u res. You will need to contact you r

dealer to re p air the pro b l e m .

An E2 re a ding on the LCD display means there is

not enou gh vo ltage for the system to opera t e .

Co n tact your dealer for further info r m a t i o n .

A flashing E3 (a lternating with room tempera t u re)

i n d i cates the outdoor air tempera t u re se n sor is

a b s e n t or not working properly (and is needed fo r

p roper opera t i o n) .

If the outdoor air tempera t u rese n sor is abse nt, the

outdoor tempera t u re re a ding will be “--”.

The batteries are low…

If the ba tteries are low, the display will indi cate a low

ba t t e ry signal on the thermostat. Replace the ba t-

teries with two AA alk a line ba tt e r i e s .

N OT E: If the pro d u c t is hard -w i r ed by the install e r,

the batteries will never have to be re p l a c e d .

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 8

TABLE OF CONTENTS

- 11 -

TABLE OF CONTENTS

- 10 -

COMMON TERMS & WHERE TO FIND THEM

S e t Po i nts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 2

The heating and cooling tempera t u re set points you

wish the system to maintain and have ent e red int o

the thermostat. The actual room tempera t u r e will

au t o m a t i c a l ly be di s p l a y ed, but you can check the

d e s i r ed tempera t u r e by pressing either the UP or

D OWN bu tton. While the SET TEMP indi cator is li t ,

p r ess the MODE bu tton to display the desired tem-

p e r a t u re set points for the other mode.

Te m p e r a t u re Sensor . . . . . . . . . . . . . . . . . . . . . . . .Pg. 7

The tempera t u re se n s or measu r es the curre n t indoor

or outdoor tempera t u r es which are di s p l a y ed on the

t h e r m o s t a t .

Up and Down Bu tto n s . . . . . . . . . . . . . . . . . . . . . . .Pg. 1

Th e s ebu ttons are used to set your desired . . . . . . . . .

t e m p e r a t u re set point s .

COMMON TERMS & WHERE TO FIND THEM

M o d e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 3

Mode re f e r s to the type of operation your system is

set up to perform. Mode se t tings include: OFF, HEAT,

C O O L, and AU TO. Heat pump systems also inclu d e

E M E R G E N CY HEAT (EHEAT ) .

Ou t door Te m p e r a t u r e . . . . . . . . . . . . . . . . . . . . . . .Pg. 4

Your thermostat not only re gi s t e r s the indoor temper-

a t u r e, but it may also be equipped to re g ister and

display the outdoor tempera t u re as we ll. Press the UP

and DOWN bu ttons simult a n e o usly to read the ou t-

door tempera t u r e di s p l a y.

Power Ou t ag e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 7

Complete loss of electricity. Your thermostat has an

i n ternal power sou r ce that will all o w it to maint a i n

your desired tempera t u r e se t tings indefinitely. Th i s

function does not re q u i r eba tt e r i e s .

Re s e t Fi lte r . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg. 4

The re s et filter function turns off the SERVICE . . . . . . .

F I LTER indi cator and re s t a rts the system. Press the

R E S ET FILTER bu tton after you ’ ve cleaned and

replaced the sys t e m’s air filt e r.

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 10

This thermostat includes a five - year limited wa r ra n ty.

For detailed wa r ra n ty information, please re f er to the

A l l Pro duct Limited Wa r r a nty Ca rd included in you r

i n formation pa c ke t.

This thermostat is also eli gible for manu fa c t u r e r’s

e xtended system wa r r a nties. Ask your dealer fo r

details on extended wa r r a nties for longer-term

p r o t e c t i o n .

TABLE OF CONTENTSWARRANTY

Before purchasing this appliance, please read the important

energy cost and efficiency information available from your dealer.

Manufacturer reserves the right to discontinue, or change, at any time,

specifications or designs without notice and without incurring obligations.

OM17-58 13TS-TA64

7310 West Morris Street, Indianapolis, IN 46231

Visit our website at www.bryant.com

BY Legacy Tstat HO Guide 7/28/04 12:46 PM Page 12

Table of contents

Other Bryant Thermostat manuals

Bryant

Bryant NON-PROGRAMMABLE THERMOSTAT User manual

Bryant

Bryant ecobee3 lite Pro Setup guide

Bryant

Bryant LEGACY T2-PAC User manual

Bryant

Bryant Preferredt Series User manual

Bryant

Bryant LEGACY LINE-RNC T1-PAC User manual

Bryant

Bryant T6-PRH-A li User manual

Bryant

Bryant IIT2-WHS-02 User manual

Bryant

Bryant ZONE PERFECT PLUS Guide

Bryant

Bryant PREFERRED T6-NRH User manual

Bryant

Bryant LEGACY T2-PAC User manual

Bryant

Bryant TSTAT Instructions and recipes

Bryant

Bryant P474-0401RF Guide

Bryant

Bryant TSTATBBPQ501 Guide

Bryant

Bryant T6-NRH01-B User manual

Bryant

Bryant Evolution Connex Control User manual

Bryant

Bryant Housewise Preferred T6-WEM01-A User manual

Bryant

Bryant THERMIDISTAT CONTROL TSTAT User manual

Bryant

Bryant TSTATBBPS101 Guide

Bryant

Bryant PREFERREDT A07044 User manual

Bryant

Bryant P/N TSTATBBP220-01 Guide

Bryant

Bryant 53DFS250-SL-BRY User manual

Bryant

Bryant TSTATBBN2W01 Guide

Bryant

Bryant Legacy Series User manual

Bryant

Bryant TSTATBBPSP2-WC Dimensions and installation guide

Popular Thermostat manuals by other brands

EWELLY

EWELLY EW-181 manual

Prolon

Prolon T1100 Hardware guide

Computherm

Computherm Q20 operating instructions

Heatmiser

Heatmiser neoStat user manual

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA user manual

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat user manual

Saswell

Saswell SAS920XWHB-7-S-RF User manual and warranty card

Aircalo

Aircalo TFP1-ET85P2 operating manual

Honeywell

Honeywell CM721 user manual

Carrier

Carrier DEBONAIR 33CS Installation and operating instructions

Lennox

Lennox iHarmony Zone Thermostat Installation and setup guide

Gemtech

Gemtech GT7000 Operation

Rollei

Rollei Smartes 45000 manual

Sinope

Sinope TH1300RF user guide

Honeywell

Honeywell RLV4305 owner's guide

Honeywell

Honeywell Prestige 2.0 THX9421 manual

NuTone

NuTone NTBZ48 Installation & operation guide

Stelpro

Stelpro MAESTRO ASMT402AD user guide
