Braeburn 7300 User manual

Wi-Fi Setup Guide

Model 7300, 7305

Universal Programmable

Smart Wi-Fi Thermostat

Leave this Setup Guide

with thermostat.

7300-105-02

Wire and Install Thermostat

• Properlywireandcongurethermostat.

 RefertotheInstallerGuide.

• RefertotheUserManualforprogramming

 andmaintenance.

NOTE:Thermostat must have 24 VAC with

common “C” wire to use Wi-Fi.

Helpfulvideoscanbefoundat

www.bluelinksmartconnect.com/wi.

Before beginning setup you will need to:

•Know your Wi-Fi network name and password

• Haveavalide-mailaddress

• GettheFREEapp

Apple®Devices:

DownloadtheBlueLink Smart Connect®application

fromtheApple®App Store

AndroidTM Devices:

DownloadtheBlueLinkSmart Connect® application

fromtheGoogle Play Store

Desktop Computer:

Goto www.bluelinksmartconnect.com and create an account.

NOTE: For Registration, your desktop PC must have a

wireless connection.

2Set-Up for Connection

3.1 Open the BlueLink Smart Connect App.

Select REGISTER and enter a valid

e-mail address.

3.2 Enter the thermostat serial number. You can

locate this number on the back of the thermostat

or on the enclosed thermostat registration card.

NOTE:

If you removed the thermostat to locate the

serial number, make sure to reconnect it before

selecting ENTER.

3.3

Complete the remaining registration screens.

Once you reach the Create Account screen,

select REGISTER.

4.1 Enter your network name (SSID) and password,

select ENTER.

NOTE:

The network name and password are

case sensitive ﬁelds.

The application will now instruct you to put the

thermostat into Wi-Fi connect mode.

4Enter Network Information

Enable Wi-Fi on Thermostat

5.1 On the thermostat, press and hold the

HOLD and RETURN buttons for

3 seconds.

5.2 The display will alternate the words WIFI

and SCAN and the symbol will ash.

NOTE: If you are already connected to a Wi-Fi network, you will see the network name

(

SSID)

displayed 4 characters at a time with a solid symbol. If needed, clear Wi-Fi

settings and return to step 5.1 (See Changing Your Wi-Fi Settings).

If you are not connected to 24 VAC, the thermostat

will display NO POWR (No Power).

6.1 Return to the application and select OK.

The word WAIT will appear in the

thermostat display.

6.2

The application will prompt you to go

to your smartphone, tablet or computer

Wi-Fi settings and select the bluelink_wiﬁ

network. See samples shown

NOTE: Do not exit the application. Minimize it so

that you can return to the same screen after

selecting the bluelink_wiﬁ network. This is

usually done by pressing the home button on your

smart phone or tablet.

Connect to Thermostat

Android

Sample Apple

Sample

Complete Setup

7.1 After selecting the bluelink_wiﬁ network,

use the home key to return to the application

and select OK.

7.2 Once a connection is made, Connection

Successful will appear in the application

screen. At thermostat, your network name

followed by the MAC address will appear.

7.3 At thermostat, press RETURN to exit Wi-Fi

setup mode.

NOTE: After setup is complete, make sure to

return your phone or tablet to the original wireless

network.

BACK NEXT

Changing Your Wi-Fi Settings

First Clear Your Thermostat Wi-Fi Settings

1. Press and hold the RETURN button for 1 second.

2. The display will change showing the rst User Option.

3. Press NEXT until you see the word WIFI in the display.

4. Press the button until CL WIFI appears.

Press RETURN to exit and clear all Wi-Fi settings.

Then Update Your App Settings

1. Open the app and select Update Account.

2. Enter your account password.

3. Select Wi-Fi Settings.

4. Select the thermostat you wish to change.

5. Choose WI-FI Network or WI-FI Password and

select Enter.

6. Update the information and select Enter.

NOTE: To complete setup, follow the instructions in

the app and refer to sections 5 - 7.

Braeburn Systems LLC

2215 Cornell Avenue • Montgomery, IL 60538

www.braeburnonline.com

844-BLU-LINK (844-258-5465) (U.S.)

630-844-1968 (Outside the U.S.)

7300-105-02

Record Network Information for Future Reference

Network Name (SSID)

Network Password

Thermostat Serial Number #

You may need this information later or if calling for support.

Visit www.bluelinksmartconnect.com for helpful videos.

Apple and the Apple logo are trademarks of Apple Inc.,

registered in the U.S. and other countries. App Store

is a service mark of Apple Inc. All other trademarks

are the property of their respective owners.
