Braeburn 6100 Assembly instructions

Installer Guide

Programmable Touchscreen Thermostats

Speciﬁcations

Installation and Wiring

Quick Reference

Installer Settings

System Testing

To prevent damage to the thermostat, never use a sharp instrument

to press the touchscreen keys. Always press keys with your ﬁngers.

Attention

• Possible electric shock or damage to equipment can occur.

• Disconnect power before beginning installation.

Caution

This thermostat requires 24 Volt AC Power or 2 properly installed “AA” Alkaline

batteries for

proper operation. When connecting 24 Volt AC Power the batteries may

be installed as a backup.

For use only as described in this manual. Any other use will void warranty.

6100

Single Stage Heat / Cool Conventional

or Heat Pump

6300

Up to 4 Heat / 2 Cool Heat Pump

Up to 3 Heat / 2 Cool Conventional

6400

Up to 4 Heat / 2 Cool Heat Pump

Up to 3 Heat / 2 Cool Conventional

with Humidity Control

Warning

For installation by experienced service technicians only.

Touchscreen

This thermostat is compatible with:

  • Singlestageheat/coolconventionalandheatpumpsystems

  • Conventionalsystemsupto3stagesofheatingand2stagesofcooling(6300/6400only)

  • Heatpumpsystemsupto4stagesofheatingand2stagesofcooling(6300/6400only)

  • 250–750millivoltheatingonlysystems

Electrical and control speciﬁcations:

  • ElectricalRating:24VoltAC

  • 1ampmaximumloadperterminal

  • ACPower:18–30VoltsAC

  • DCPower:3.0VoltDC(2“AA”AlkalineBatteriesIncluded)

  • ControlRange:45°–90°F(7°–32°C)

  • TemperatureAccuracy:+/-1°F(+/-.5°C)

  • OutdoorTemperatureDisplayRange:-40°-120°F(-40°-49°C)

Humidiﬁcation Speciﬁcations (6400 Only)

  • HumidicationControlRange:10%-50%RH

  • DehumidicationControlRange:40%-80%RH

Terminations

  • 6100:G,Rc,Rh,W,O/B,Y,C,S1,S2

  • 6300:A,G,Rc,Rh,W1/E/AUX1,W2/AUX2,W3/O/B,Y1,Y2,C,L,S1,S2

  • 6400:H,A/D,G,Rc,Rh,W1/E/AUX1,W2/AUX2,W3/O/B,Y1,Y2,C,L,S1,S2

Thermostat Location

Installthethermostatapproximately5feet(1.5m)abovetheoorinanareathathasagoodamountofair

circulationandmaintainsanaverageroomtemperature.

Avoidinstallationinlocationswherethethermostatcanbeaffectedbydrafts,deadairspots,hotorcoldair

ducts,sunlight,appliances,concealedpipes,chimneysandoutsidewalls.

Installer Guide 2

Warning

Disconnect power before beginning installation.

Installation and Wiring

Speciﬁcations

3 Installer Guide

Install your new Braeburn thermostat in 4 basic steps:

1 Installthesub-base

2 ProvidePower

3 Connectyourwires

4 Attachthethermostattothesub-base

Install the Sub-Base:

•Removethesub-basefromthebodyofthethermostat.

•Mountthesub-baseasshownbelow:

UP UP

Provide Power

• For24VoltACpower,youmustconnectthecommonsideofthetransformertotheCterminalonthe

 thermostatsub-base.Indualtransformerinstallations,thetransformercommonmustcomefromthe

 coolingtransformer.

•Forbatterypower,insertthe2supplied“AA”typealkalinebatteriesintothebattercompartmentlocatedinthe

 rearhousingofthethermostat.MakesuretopositionthePositive(+)andNegative(-)sidesofthebatteries

 correctlywiththe+/-symbolsinthebatterycompartment.

Drill 3/16” pilot holes in your

desired location. Use supplied

anchors for drywall or plaster.

24VAC Power Terminal (C) Batteries Installed as Shown

Installer Guide 4

Wiring Terminations for model 6100

Terminal Function Description

 G Output FanControl

 Rc Input 24VoltACCoolingTransformer

   (DualTransformerSystemsOnly)

 Rh Input PowerConnection(24VoltACHeating

   TransformerorMillivoltPowerSource)

 W Output 1stStageConventionalHeat

 OorB Output ReversingValve(CoolActiveorHeatActive)

 Y Output 1stStageCompressor

 C Input 24VoltACTransformerCommon

 S1 Input OptionalRemoteSensor(IndoororOutdoor)

 S2 Input OptionalRemoteSensor(IndoororOutdoor)

Wiring Terminations for models 6300 and 6400

Terminal Function Description

 H Output Humidier(6400Only)

 A/D* Output (A)EconomizerControl,(D)Dehumidier

  G Output FanControl

  Rc Input 24VoltACCoolingTransformer

    (DualTransformerSystemsOnly)

  Rh Input PowerConnection(24VoltACHeating  

    TransformerorMillivoltPowerSource)

 W1/E/ Output (W1)1stStageConventionalHeat,

 AUX1  (E)EmergencyHeat,    

(AUX1)1stStageAuxiliaryHeat

 W2/AUX2 Output (W2)2ndStageConventionalHeat,  

    (AUX2)2ndStageAuxHeat

 W3/OorB Output (W3)3rdStageConventionalHeat,  

    (O)CoolActiveReversingValve   

    (B)HeatActiveReversingValve

  Y1 Output 1stStageCompressor

  Y2 Output 2ndStageCompressor

  C Input 24VoltACTransformerCommon

  L Input SystemMalfunctionIndicator

  S1 Input OptionalRemoteSensor(IndoororOutdoor)

  S2 Input OptionalRemoteSensor(IndoororOutdoor)

*ThisterminalappearsasAonthe6300andA/Donthe6400.

Connecting Your Wires

5 Installer Guide

Heat Only or Millivolt

Set System Type to 11CONV

Rh PowerConnection

W1 HeatRelay(appearsasWonthe6100)

1 HEAT / 1 COOL Single or Dual Transformer

Set System Type to 11CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelay(appearsasWonthe6100)

Y1 CompressorRelay(appearsasY onthe6100)

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

Conventional Systems

Typical Wiring Conﬁgurations

NOTE: The “System Type” option will be conﬁgured in the Installer Settings section. The 6100 is a single stage

thermostat and not intended for multi stage equipment.

NOTES - Conventional Systems

[1]Optional24VoltACcommonconnection.

[2]Removefactoryinstalledjumperfordual

 transformersystems.

[3]Indualtransformersystems,transformer

 commonmustcomefromcoolingtransformer.

[4]ConnectY2onlyifasecondcoolingcompressor

 isbeingused.

3 HEAT / 2 COOL Single or Dual Transformer

Set System Type to 32CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelayStage1

W2 HeatRelayStage2

W3 HeatRelayStage3

Y1 CompressorRelayStage1

Y2 CompressorRelayStage2 [note 4]

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

2 HEAT / 2 COOL Single or Dual transformer

Set System Type to 22CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelayStage1

W2 HeatRelayStage2

Y1 CompressorRelayStage1

Y2 CompressorRelayStage2 [note 4]

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

Installer Guide 6

Heat Pump Systems

Typical Wiring Conﬁgurations

NOTE: The “System Type” option will be conﬁgured in the Installer Settings section. The 6100 is a single stage

thermostat and not intended for multi stage equipment.

1 HEAT / 1 COOL - No Auxiliary Heat

Set System Type to 11HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B

ChangeoverValve [note 2]

Y1 CompressorRelay(appearsasYonthe6100)

G FanRelay

C 24VoltACTransformerCommon [note 1]

3 HEAT / 2 COOL – Including Auxiliary Heat

Set System Type to 32HP

Rh 24VoltACPower

ConnectedtoRhwithsuppliedJumperWire

O/B ChangeoverValve [note 2]

Compressor1Relay(1ststageheating/cooling)

Compressor2Relay(2ndstageheating/cooling)

AUX1/E

AuxiliaryHeatRelay(3rdstageheating)

/Emergency

Heat[note 5]

E EmergencyHeatRelay [note 5]

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

2 HEAT / 1 COOL - Including Auxiliary Heat

Set System Type to 22HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B

ChangeoverValve[note 2]

Y1 CompressorRelay(1ststageheating/cooling)

AuxiliaryHeatRelay(2ndstageheating)[note 3]

E EmergencyHeatRelay[note 3]

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

2 HEAT / 2 COOL - No Auxiliary Heat

Set System Type to 32HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B

ChangeoverValve[note 2]

Compressor1Relay(1ststageheating/cooling)

Compressor2Relay(2ndstageheating/cooling)

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

4 HEAT / 2 COOL - Including Auxiliary Heat

Set System Type to 42HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B ChangeoverValve[note 2]

Compressor1Relay(1ststageheating/cooling)

Compressor2Relay(2ndstageheating/cooling)

AUX1/E

 AuxiliaryHeatRelay1(3rdstageheating)

 /EmergencyHeat[note 5]

AUX2

AuxiliaryHeatRelay2Relay(4thstageheating)

E EmergencyHeatRelay[note 5]

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

NOTES - Heat Pump Systems

[1] Optional24VoltACcommonconnection.

[2] O(coolactive)orB(heatactive)isselectedinthe

 InstallerSettingsmenu.

[3] InstallaeldsuppliedjumperbetweentheW2/AUX2

 andW1/E/AUX1terminalsifthereisnoseparate

 emergencyheatrelayinstalled.

[4] IftheLterminalisused,the24VoltACcommon

 mustbeconnected(Cterminal).

[5] Ifaseparateemergencyheatrelayisinstalled,the

 W1/E/AUX1terminalshouldhaveboththeauxiliary

 heat1relayandemergencyheatrelayconnected.

7 Installer Guide

All System Types

Additional Wiring Options

NOTE: Additional options are conﬁgured in the Installer Settings section.

S1 IndoororOutdoorRemoteSensor[note 1]

S2 IndoororOutdoorRemoteSensor[note 1]

A/D* EconomizerControl(6300,6400only)/

 DehumidierOutput(6400only)[note 2]

H HumidierOutput(6400only)[note 3]

*ThisterminalappearsasAonthe6300andA/Donthe6400.

NOTES - Additional Wiring Options

[1]TheseterminalscanbeusedtoconnectaBraeburn®indoororoutdoorremotesensor.

[2]Thisterminalcanbeusedeitherforoutsideaircontrol(6300and6400)ortoconnecttoanexternal

 dehumidier(6400only).

[3]Thisterminalcanbeusedtoconnectanexternalhumidier(6400only).

Attaching the thermostat to the sub-base

1) Lineupthethermostatbodywiththesub-base.

2) Carefullypushthethermostatbodyagainstthe

 sub-baseuntilitsnapsinplace.

NOTE: This thermostat ships conﬁgured as a 1H/1C conventional

thermostat. Conﬁrm installer settings. See page 10.

UP UP

W1/E

/AUX1

W2/

AUX2

W3/

O/B

1/E

AUX

RESET

3) InsertQuickReferenceCardintoslot

 ontopofthermostat.

Installer Guide 8

RESET

Room Temperature...................... Displaysthecurrentroomtemperature

Lock Mode Indicator ................... Indicatesifthethermostatislocked

Set Temperature.......................... Displaysthecurrentsetpointtemperature

Humidity Indicator (6400 only).... Indicateswhenthereisacallforhumidity

Fan Indicator................................ Indicateswhenthesystemfanisrunning

Service Indicators ...................... Displaysvariousservice/maintenanceinformation

Time of Day ................................. Displaysthecurrenttimeofday

Program Event Indicator.............. Displaystheprogramevent

Day of the Week........................... Displaysthecurrentdayoftheweek

System Status Indicator ............. Displaysinformationaboutthestatusofthesystem

Hold Mode Indicator ................... IndicatesifthethermostatisinHOLDmode

Low Battery Indicator.................. Indicateswhenthebatteriesneedtobereplaced

Quick Reference Instructions...... Storedinslotlocatedattopofthermostat

SpeedBar®.................................. Increasesordecreasessettings(time,temperature,etc.)

Reset Button ............................... Resetscurrenttime,programandusersettings

Installer Clear Button .................. Locatedonbackofthermostatbody–clearsallsettings

Battery Compartment ................. Locatedinthebackofthermostat

Quick Reference

Instructions

Thermostat Display

Thermostat

9 Installer Guide

Thermostat TouchPadsTM

NOTE: Thermostat TouchPads are located on the left, right and bottom portions of the display screen. They are

the “touch sensitive” segments used to adjust your thermostat. Depending on the equipment installed, all touch

pads may not show.

SYSTEM SelectsAUTO(Heat/Cool),COOL,OFFHEATorEMER(EmergencyHeat)

FAN SelectsAUTO,ON,CIRC(Circulation)andPROG(Program)fanmodes

PROG Selectsprogrammingmodeorpressfor3secondstoselectSpeedSetTMmode

HOLD Enters/ExitstheHOLDmode(programbypass)

DAY/TIME Setsthecurrenttimeanddayoftheweek

BACK Movesbackinsettingandprogrammingmodes

NEXT Movesforwardinsettingandprogrammingmodes

RETURN Returnstonormalmodefromprogramorsettingsmodes

OUTDOOR DisplaystheoutdoortemperatureifaBraeburn

outdoorsensorisinstalled

HUMIDITY Displaysoradjustthecurrenthumiditylevel(6400only)

CONFIG EnterstheUserandInstallersettingsmodes

CLEAN Entersabriefscreencleaningmode

RESET

TheInstallerSettingsmustbeproperlyconguredinorderforthisthermostattooperatecorrectly.TheInstaller

Settingsaremenudriven.Theportionofthesesettingsthatdonotapplytoyoursetupwillbeskipped.These

settingsareindicatedbelowwithcomments.Moredetailoneachsettingfollowsthistable.

Installer Guide 10

1. TouchandholddowntheSYSTEMandCONFIGTouchPads™for3seconds.

2. Releasebothbuttonsandtherstinstallersettingwillbedisplayed.

3. ChangesettingsasrequiredusingtheUPorDOWNportionoftheSpeedBar®.

4. TouchNEXTorBACKtomovetothenextorprevioussetting,touchRETURNtoexit.

NOTE: Shaded areas below do not apply to the 6100.

No. Installer Setting Factory Setting Comments

(Notes follow this table) Default Options (More information follows this table)

1  Residentialor RES RES SelectforResidentialprole

  orCommercialProle    COMM SelectforCommercialprole

2  ProgrammingMode 7 PROG 7 PROG Selectfor7dayprogrammingmode

[note 1] 52 PROG Selectfor5-2dayprogrammingmode

NO PROG Selectfornon-programmablemode

3  ClockFormat 12 HR 12 HR Selectfor12hourclock

24 HR Selectfor24hourclock

4  TemperatureScale F DEG F DEG SelectforFahrenheitdisplay

C DEG SelectforCelsiusdisplay

5  AutoChangeover oF AUTO oF AUTO DisablesAutoChangeovermode

ON AUTO EnablesAutoChangeovermode

11CONV Selectfor1H/1CConventionalsystem

22CONV Selectfor2H/2CConventionalsystem

32CONV Selectfor3H/2CConventionalsystem

6  SystemType 11CONV 11HP Selectfor1H/1CHeatPumpsystem

22HP Selectfor2H/2CHeatPumpsystem

32HP Selectfor3H/2CHeatPumpsystem

42HP Selectfor4H/2CHeatPumpsystem

7  1stStageDifferential 0.5 DIF1 0.5, 1.0or Selecta1ststagetemperaturedifferentialof.5°,

2.0 DIF1 1°or2°F(.25°,.5°or2°C)

8  2ndStageDifferential 2.0 DIF2 1.0, 2.0, 3.0, Selecta2ndstagetemperaturedifferentialof1°,

[note 2] 4.0, 5.0or 2°,3°,4°,5°or6°F(.5°,1°,1.5°,2°,2.5°or3°C)

6.0 DIF2

9  3rdStageDifferential 2.0 DIF3 1.0, 2.0, 3.0, Selecta3rdstagetemperaturedifferentialof1°,2°,

[note 2] 4.0, 5.0or 3°,4°,5°or6°F(.5°,1°,1.5°,2°,2.5°or3°C)

6.0 DIF3

10 4thStageDifferential 2.0 DIF4 1.0, 2.0, 3.0,

Selecta4thstagetemperaturedifferentialof1˚,

[note 2] 4.0, 5.0or 2°,3°,4°,5°or6°F(.5°,1°,1.5°,2°,2.5°or3°C)

6.0 DIF4

Installer Settings

Other manuals for 6100

This manual suits for next models

Table of contents

Other Braeburn Thermostat manuals

Braeburn

Braeburn 2220 User manual

Braeburn

Braeburn Premier 5000 User manual

Braeburn

Braeburn 5200 User manual

Braeburn

Braeburn 2020 Operating and maintenance manual

Braeburn

Braeburn 7500 User manual

Braeburn

Braeburn 3000 User manual

Braeburn

Braeburn Builder 1000NC User manual

Braeburn

Braeburn 2020NC Instructions for use

Braeburn

Braeburn 3220 User manual

Braeburn

Braeburn Builder 1200NC Operating and maintenance manual

Braeburn

Braeburn 1100 Builder Series User manual

Braeburn

Braeburn Premier 5100 User manual

Braeburn

Braeburn 2100 User manual

Braeburn

Braeburn Economy Series User guide

Braeburn

Braeburn 4030 User manual

Braeburn

Braeburn 7300 User manual

Braeburn

Braeburn Premier 5300 User manual

Braeburn

Braeburn 3200 User manual

Braeburn

Braeburn 3020 Operating and maintenance manual

Braeburn

Braeburn 3000 User manual

Braeburn

Braeburn Premier 5000 User manual

Braeburn

Braeburn 5970 User manual

Braeburn

Braeburn Economy 2030 User guide

Braeburn

Braeburn Premier 5300 User manual

Popular Thermostat manuals by other brands

EWELLY

EWELLY EW-181 manual

Prolon

Prolon T1100 Hardware guide

Computherm

Computherm Q20 operating instructions

Heatmiser

Heatmiser neoStat user manual

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA user manual

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat user manual

Saswell

Saswell SAS920XWHB-7-S-RF User manual and warranty card

Aircalo

Aircalo TFP1-ET85P2 operating manual

Honeywell

Honeywell CM721 user manual

Carrier

Carrier DEBONAIR 33CS Installation and operating instructions

Lennox

Lennox iHarmony Zone Thermostat Installation and setup guide

Gemtech

Gemtech GT7000 Operation

Rollei

Rollei Smartes 45000 manual

Sinope

Sinope TH1300RF user guide

Honeywell

Honeywell RLV4305 owner's guide

Honeywell

Honeywell Prestige 2.0 THX9421 manual

NuTone

NuTone NTBZ48 Installation & operation guide

Stelpro

Stelpro MAESTRO ASMT402AD user guide
