Braeburn 2220 User manual

This thermostat requires 24 Volt AC Power or two (2) properly installed

“AA” Alkaline batteries for proper operation. When connecting 24 Volt

AC Power the batteries may be installed as a backup.

For use only as described in this manual. Any other use

will void warranty.

2020

Single Stage Heat / Cool

Conventional and Heat Pump

Speciﬁcations

About Your Thermostat

Installation

System Testing

Setting User Options

Setting Your Program Schedule

Operating Your Thermostat

Additional Operation Features

Thermostat Maintenance

Warning

Turn off power to the heating or cooling

equipment before installation.

Attention

For installation by experienced service

technicians only.

2220

Up to 2 Heat / 2 Cool Conventional

Up to 2 Heat / 1 Cool Heat Pump

Read all instructions before proceeding.

This thermostat is compatible with:

  •Singlestageheat/coolconventionalandheatpumpsystems

  •Conventionalsystemsupto2heat/2cool(2220only)

  •

Singlecompressorheatpumpsystemswithanauxiliaryheatstage(2220only)

  •250–750millivoltheatonlysystems

Electrical and control speciﬁcations:

  •ElectricalRating:24VoltAC

  •1ampmaximumloadperterminal

  •ACPower:18–30VoltsAC

  •DCPower:3.0VoltDC(2“AA”AlkalineBatteriesIncluded)

  •ControlRange:45°–90°F(7°–32°C)

  •TemperatureAccuracy:+/-1°F(+/-.5°C)

Terminations

  •2020–Rc,Rh,O,B,Y1,W1,G,C

  •2220–Rc,Rh,O,B,Y1,Y2,E/W1,G,W2,C

Speciﬁcations

2020W-100-06

Model number is located on back of thermostat

Programmable

Thermostats

Detailed

User Guide

Setting Your Program Schedule

Operating Your Thermostat

Additional Operation Features

Thermostat Maintenance

For installation by experienced service

technicians only.

About Your Thermostat

Room Temperature...........Displaysthecurrentroomtemperature

Day of Week......................Displaysthecurrentdayofweek

Program Event Indicator. . Indicatesthecurrentprogramevent

Time of Day.......................Displaysthecurrenttimeofday

Low Battery Indicator......

Indicateswhenbatteriesneedtobereplaced

Fan Indicator....................Indicateswhenthesystemfanisrunning

Hold Mode Indicator.........DisplaysifinHOLDmode

System Status Indicator...Displaysinformationaboutsystemstatus

Set Temperature...............Displaysthecurrentsetpointtemperature

Service Filter Indicator.....Displaysservice/maintenancereminders

Reset Button..........

Resetsthermostatbacktofactorydefaults

System Switch.......

Selectssystempreference

PROG Button..........Selectsprogrammingmode

HOLD Button..........Enters/ExitstheHOLDmode(programbypass)

RETURN Button......Returnstonormalfromprogramorsettingmodes

DAY/TIME Button...Usedtosetthetimeanddayofweek

Quick Reference

Instructions........... Storedinslotattopofthermostat

Arrow Buttons....... Usedtoincreaseordecreasesettings

Fan Switch.............Selectsthesystemfanmode

Battery Compartment....Locatedinbackofthethermostat

13 14 15 16

Install your new Braeburn thermostat in 5 basic steps:

1 InstalltheSub-Base

2 ProvidePower

3 ConnectYourWires

4 SetInstallerSwitches

5 AttachThermostattoSub-Base

Install the Sub-Base:

•Removethesub-basefromthebodyofthethermostat.

•Mountthesub-baseasshownbelow:

NOTE: After sub-base installation, you may insert the quick reference card

into the slot on the top of the base.

Installation

Warning

Disconnect power before beginning installation.

Thermostat Location

Installthethermostatapproximately5feet(1.5m)abovetheoorinan

areathathasagoodamountofaircirculationandmaintainsanaverage

roomtemperature.

Avoidinstallationinlocationswherethethermostatcanbeaffectedby

drafts,deadairspots,hotorcoldairducts,sunlight,appliances,concealed

pipes,chimneysandoutsidewalls.

Drill 3/16” pilot holes in

your desired location.

Use supplied anchors for

drywall or plaster.

UP UP

Terminal Function Description

 Rc   Input 24VoltACCoolingTransformer

       (DualTransformerSystemsOnly)

 Rh   Input PowerConnection(24VoltACHeating

       TransformerorMillivoltPowerSource)

 O   Output ReversingValve(CoolActive)

 B   Output ReversingValve(HeatActive)

 Y1   Output CompressorRelay

 G   Output FanControl

 W1   Output ConventionalHeatRelay

 C   Input 24VoltACTransformerCommon

Connect Your Wires

Wiring Terminations

Terminal Function Description

W1/E   Output (W1)1stStageConventionalHeat

       (E)EmergencyHeatRelay

Y2   Output

2ndStageConventionalCoolingCompressor

 W2   Output 2ndStageHeat/AuxiliaryHeat

Additional Terminations (2220 only)

Provide Power

•For 24 Volt AC power,youmustconnectthecommonsideofthetrans-

 formertotheCterminalonthethermostatsub-base.

•For primary or back-up power,insertthe2supplied“AA”typealkaline

 batteriesintothebatterycompartmentlocatedintherearhousingofthe

 thermostat.MakesuretopositionthePositive(+)andNegative(-)sides

 ofthebatteriescorrectlywiththe+/-symbolsinthebatterycompartment.

24VAC Power

Terminal (C)

1 HEAT / 1 COOL Single or Dual Transformer

Set Installer Switch to CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelay(appearsasW1/Eon2220)

Y1 CompressorRelay

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

Typical Wiring Conﬁgurations

NOTE: The “Installer Switch” option will be conﬁgured in the next step.

Conventional Systems

24VAC Power

Terminal (C)

NOTES - Conventional Systems

[1]Ifbatteriesareinstalledthe24VoltACcommonconnectionisoptional

[2]Removefactoryinstalledjumperfordualtransformersystems

[3]Indualtransformersystems,transformercommonmustcomefrom

 coolingtransformer

[4]Ifneededforsystem

Provide disconnect and overload protection as required.

2 HEAT / 2 COOL Single or Dual Transformer (2220 Only)

Set System Type to CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelayStage1

W2 HeatRelayStage2

Y1 CompressorRelayStage1

Y2 CompressorRelayStage2 [note 4]

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

Heat Only or Millivolt

Set Installer Switch to CONV

 PowerConnection

W HeatRelay(appearsasW1/Eon2220)

G FanRelay[note 4]

C 24VoltACTransformerCommon[note 1]

Factory Setting

Switch Default Options Comments

NOTES - Heat Pump Systems

[1]Ifbatteriesareinstalledthe24VoltACcommonconnectionisoptional.

[2]SelectOforcoolactiveor Bforheatactive.

[3]InstallaeldsuppliedjumperbetweentheW2 and Eterminalsif

 thereisnoseparateemergencyheatrelayinstalled.

Provide disconnect and overload protection as required.

 CONV/HP CONV

 F/C F

 HE/HG HG

Set Installer Switches

 CONV Selectforconventionalsystems

 HP Selectforheatpumpsystems

 F Selectforfahrenheittemperaturescale

 C Selectforcelsiustemperaturescale

 HG Selectforgasheat

 HE Selectforelectricheat

Typical Wiring Conﬁgurations

NOTE: The “Installer Switch” option will be conﬁgured in the next step.

Heat Pump Systems

1 HEAT / 1 COOL - No Auxiliary Heat

Set Installer Switch to HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O or B

 ChangeoverValve [note 2]

Y1 CompressorRelay

G FanRelay

C 24VoltACTransformerCommon [note 1]

2 HEAT / 1 COOL - Including Auxiliary Heat (2220 only)

Set Installer Switch to HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O or B

 ChangeoverValve[note 2]

CompressorRelay(1ststageheating/cooling)

W2 AuxiliaryHeatRelay(2ndstageheating)

[note 3]

E EmergencyHeatRelay[note 3]

G FanRelay

C 24VoltACTransformerCommon [note1]

TheInstallerswitchesarelocatedonthebackofthethermostatandmust

beproperlysetforthisthermostattooperateproperly.

Attach Thermostat to Sub-Base

1.Lineupthethermostatbodywiththesub-base.

2.Carefullypushthethermostatbodyagainstthesub-baseuntilitsnaps

 intoplace.

3.Insertquickreferencecardintoslotontopofthermostat.

System Testing

Warning

Read Before Testing

• Donotshort(orjumper)acrossterminalsonthegasvalveoratthe

 heatingorcoolingsystemcontrolboardtotestthethermostatinstalla-

 tion.Thiscoulddamagethethermostatandvoidthewarranty.

• DonotselecttheCOOLmodeofoperationiftheoutsidetemperature

 isbelow50ºF(10ºC).Thiscouldpossiblydamagethecontrolledcool-

 ingsystemandmaycausepersonalinjury.

• Thisthermostatincludesanautomaticcompressorprotectionfeatureto

 avoidpotentialdamagetothecompressorfromshortcycling.When

 testingthesystem,makesuretotakethisdelayintoaccount.

NOTE: The compressor delay can be bypassed by pressing the reset button

on the front of the thermostat. All user settings will be returned to factory

default.

1 MovetheSYSTEMswitchtoHEATmode.

2 Presstoraisethesettemperatureaminimumof3degreesabove

thecurrentroomtemperature.Thesystemshouldstartwithinafew

 seconds.Withagasheatingsystem,thefanmaynotstartrightaway.

3 MovetheSYSTEMswitchtotheOFFmode.Allowtheheatingsystemto

 fullyshutdown.

4 MovetheSYSTEMswitchtotheCOOLmode.

5 Presstolowerthesettemperatureaminimumof3degreesbelow

thecurrentroomtemperature.Thesystemshouldstartwithinafew

 seconds(unlesscompressorshortcycleprotectionisactive–See

 noteabove).

6 MovetheSYSTEMswitchtotheOFFmode.Allowthecoolingsystemto

 fullyshutdown.

7 MovetheFANswitchtotheONmode.Thesystemfanshouldstart

 withinafewseconds.

MovetheFANswitchtotheAUTOmode.Allowthesystemfantoturnoff.

NOTE: Installer switches are located on the back of the thermostat. The

reset button must be pressed after making any changes to these switches.

UP UP

User Factory Setting

No. Options Default Options Comments

Programming

PRO 7 PRO 7

Selectfor7DayProgrammingMode

   Mode   PRO 52 Selectfor5-2DayProgrammingMode

PRO NO SelectforNon-ProgrammableMode

2 1ststage

0.5

0.5, 1.0,

Selecta1ststagetemperature

differential

2.0 differentialof.5˚,1˚or2˚F(0.2˚,

       0.5˚or1˚C)

3 2ndstage

2.0

1.0, 2.0,

 Selecta2ndtemperature

differential

3.0, 4.0

, differentialof1˚,2˚,3˚,4˚,5˚or6˚F

(2220Only)

5.0, 6.0

 (.5˚,1˚,1.5˚,2˚,2.5˚or3˚C)

LNG

Selectslong(permanent)holdmode

24HRS

Selects24hr.(temporary)holdmode

 5 

OFF

Disableslterservicemonitorfeature

30, 60, 90

, Selectsanumberofdaysbefore

120, 180,  thethermostatwillashaService

365 Filterreminderinthedisplay.

 6    OF REC Disablesadaptive(early)

       recoverymode

ON REC Enablesadaptive(early)

       recoverymode

Table of User Options

Detailed Explanation of User Options:

Programming Mode

(User Option 1)

Selectstheprogrammingmode(choosefrom7day,5-2Day(weekday/

weekend)programmingornon-programmable.

Temperature Differential

(User Option 2 and 3)

Thedifferentialsettingisthetemperaturecontrolrangethatyourthermostat

willprovide.Thesmallerthesetting,thetighteryourrangeoftemperature

controlandcomfortwillbe.The2ndstagedifferentialisonlyforsystems

withasecondstageofheating(auxiliaryheat).

Setting User Options

Advanced User Options

Useroptionsallowyoutocustomizesomeofyourthermostat’sfeatures.

Mostuserswillnotneedtomakeanychangestothesettingsinthissection.

To enter the User Options menu, hold down the RETURN button

for

approximately 3 seconds until the screen changes and displays the

ﬁrst User Option.

PresstheorbuttontochangethesettingforthedisplayedUserOption.

Afteryouhavemadeyourdesiredsetting,pressRETURNtoadvancetothe

nextUserOption.

Thethermostatwillreturntonormalmodeafteryourlastuseroptionis

madeorafternokeyshavebeenpressedfor15seconds.

Extended

HoldPeriod*

Filter

Service

Monitor

LNG

Adaptive

Recovery

Mode(ARM

OF REC

OFF

Setting Your Program Schedule

Setting the Time and Day

Innormaloperatingmode,presstheDAY/TIME

 button.Thedisplaywillswitchtotheday/time

 settingmodeandthehourwillbeashing.

2. Pressortoadjustthehour.

 PressDAY/TIME.

3. Pressortoadjusttheminute.Press

DAY/TIME.

4. Pressortoadjustthedayoftheweek.PressRETURNtoexit.

Extended Hold Period*

(User Option 4)

TheExtendedHoldPeriodletsyouselecttheperiodyourthermostatwill

holdthetemperaturewhentheHOLDmodeisactivated(See“Temperature

Adjustment”).WhenLNGisselectedthethermostatwillholdyour

temperatureindenitely.When24HRisselected,thethermostatwillhold

yourtemperaturefor24hoursandthenreturntothecurrentprogramat

thattime.

Service Filter Monitor

(User Option 5)

TheServiceFilterMonitorisauserselectable

servicemonitorthatwilldisplayareminderfor

arequiredairlterreplacementbyashingthe

SERVICEFILTERsegmentinthedisplay.Whenthe

selectedintervalhasbeenreached,andrequired

cleaningorreplacementhasbeenperformed,

touchtheRETURNbuttontoresetthetimerandresettheservicemonitor.

SelectOFForasetnumberofdaysbeforethereminderwillappear.

Adaptive Recovery Mode (early recovery)*

(User Option 6)

AdaptiveRecoveryModeisausersettingthatcontrolswhenthethermostat

willstarttorecoverfromsetback.

Tips Before Setting Your Program Schedule

• Makesureyourcurrenttimeanddayoftheweekaresetcorrectly.

• Whenprogramming,makesuretheAMandPMindicatorsarecorrect.

• YourNIGHTeventcannotexceed11:50p.m.

This thermostat has been conﬁgured with one of the following

programming options:

• 7dayprogrammingmodewith4eventsperday(default)

• 5-2(weekday/weekend)programmingmodewith4eventsperday.

• Non-Programmablemode

ARM

Setting Result

OFF  Startchangeatprogrammedtime

ON  Finishchangeatprogrammedtime

*NotavailableifUserOption1issettonon-programmable

NOTE: If this thermostat was set in the

Installer Settings to be non-programmable, then

you cannot set a user program. If you press the

PROG or HOLD buttons, the word “NO” will

appear in the display, indicating there is no

program present. See section 5, “Setting User

Options” to change this setting.

Energy Saving Programs

Thisthermostatcomespre-programmedwithadefaultenergysaving

program.Thefollowingtablesoutlinethepre-programmedtimesandtem-

peraturesforheatingandcoolingineachofyour4dailyevents.Ifyouwish

tousethesesettingsthennofurtherprogrammingisnecessary:

MORN

DAY

EVE

NIGHT

Time: 6:00 pm

Heat: 70˚ F (21˚ C)

Cool: 78˚ F (26˚ C)

Time: 8:00 am

Heat: 62˚ F (17˚ C)

Cool: 85˚ F (29˚ C)

Time: 6:00 am

Heat: 70˚ F (21˚ C)

Cool: 78˚ F (26˚ C)

Time: 10:00 pm

Heat: 62˚ F (17˚ C)

Cool: 82˚ F (28˚ C)

4 Event All Days

7 Day Programming

Factory Settings

Weekday Weekend

MORN

DAY

EVE

NIGHT

Time: 6:00 pm

Heat: 70˚ F (21˚ C)

Cool: 78˚ F (26˚ C)

Time: 8:00 am

Heat: 62˚ F (17˚ C)

Cool: 85˚ F (29˚ C)

Time: 6:00 am

Heat: 70˚ F (21˚ C)

Cool: 78˚ F (26˚ C)

Time: 10:00 pm

Heat: 62˚ F (17˚ C)

Cool: 82˚ F (28˚ C)

4 Event

Time: 6:00 pm

Heat: 70˚ F (21˚ C)

Cool: 78˚ F (26˚ C)

Time: 8:00 am

Heat: 62˚ F (17˚ C)

Cool: 85˚ F (29˚ C)

Time: 6:00 am

Heat: 70˚ F (21˚ C)

Cool: 78˚ F (26˚ C)

Time: 10:00 pm

Heat: 62˚ F (17˚ C)

Cool: 82˚ F (28˚ C)

5-2 Day Programming– Weekday/Weekend

Factory Settings

Table of contents

Other Braeburn Thermostat manuals

Braeburn

Braeburn 3000 User manual

Braeburn

Braeburn 5970 User manual

Braeburn

Braeburn 7320 User manual

Braeburn

Braeburn 2010 User manual

Braeburn

Braeburn Premier Series User manual

Braeburn

Braeburn Premier 5050 User manual

Braeburn

Braeburn 2000 User manual

Braeburn

Braeburn Premier 5300 User manual

Braeburn

Braeburn Premier 5400 User manual

Braeburn

Braeburn 6100 User manual

Braeburn

Braeburn 3020 User manual

Braeburn

Braeburn Premier 3300 User manual

Braeburn

Braeburn 1200 User manual

Braeburn

Braeburn Builder 1000NC User manual

Braeburn

Braeburn 3000 User manual

Braeburn

Braeburn 5020 User manual

Braeburn

Braeburn 229100 User manual

Braeburn

Braeburn 5200 User manual

Braeburn

Braeburn 3020 Instructions for use

Braeburn

Braeburn 4030 User manual

Braeburn

Braeburn BlueLink 7205 User manual

Braeburn

Braeburn 3020 Operating and maintenance manual

Braeburn

Braeburn Economy Series User guide

Braeburn

Braeburn Builder 1010 User manual

Popular Thermostat manuals by other brands

EWELLY

EWELLY EW-181 manual

Prolon

Prolon T1100 Hardware guide

Computherm

Computherm Q20 operating instructions

Heatmiser

Heatmiser neoStat user manual

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA user manual

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat user manual

Saswell

Saswell SAS920XWHB-7-S-RF User manual and warranty card

Aircalo

Aircalo TFP1-ET85P2 operating manual

Honeywell

Honeywell CM721 user manual

Carrier

Carrier DEBONAIR 33CS Installation and operating instructions

Lennox

Lennox iHarmony Zone Thermostat Installation and setup guide

Gemtech

Gemtech GT7000 Operation

Rollei

Rollei Smartes 45000 manual

Sinope

Sinope TH1300RF user guide

Honeywell

Honeywell RLV4305 owner's guide

Honeywell

Honeywell Prestige 2.0 THX9421 manual

NuTone

NuTone NTBZ48 Installation & operation guide

Stelpro

Stelpro MAESTRO ASMT402AD user guide
