Bose SOUNDLINK REVOLVE II User manual

SOUNDLINK REVOLVE II

ENG

CONTENTS

Conﬁrm that the following parts are included:

SoundLink Revolve II

Bluetooth speaker

USB cable

NOTE: If any part of the product is damaged, don’t use it. Contact your authorized

Bose dealer or Bose customer service.

Visit: worldwide.Bose.com/Support/SLRiiworldwide.Bose.com/Support/SLRii

WHAT’S IN THE BOX

ENG

BOSE CONNECT APP SETUP

The Bose Connect app lets you set up and control the speaker from any mobile

device, such as a smartphone or tablet.

Using the app, you can manage Bluetooth connections, choose your voice prompt

language, manage speaker settings, and get new features.

DOWNLOAD THE BOSE CONNECT APP

1. On your mobile device, download the Bose Connect app.

BOSE CONNECT

2. Follow the app instructions.

ENG

SPEAKER PLACEMENT

PLACEMENT GUIDELINES

• For best Bluetooth performance, place your mobile device within 30 ft (9 m) of your

speaker, and make sure there is a clear line of sight between you and your speaker.

Moving your device farther away, or not having a clear line of sight may impact

sound quality, and your device may disconnect from your speaker.

• Keep other wireless equipment at least 3 ft (1 m) away from your speaker.

• Place your speaker and your device outside of and away from metal cabinets,

other audio/video components, and direct heat sources.

CAUTIONS

• Stand your speaker on its base. Standing your speaker on any other side may cause

damage to your speaker and aect sound quality.

• Avoid placing your speaker on wet or dirty surfaces.

ENG

POWER

CONNECT TO POWER

Your speaker ships with a partial charge. Before using your speaker for the ﬁrst time,

connect it to an AC (mains) outlet. Your speaker does not need to be fully charged,

but it does require the initial connection to activate the battery.

NOTE: Use a 1500mA (1.5A) USB power supply for the best speaker charging

experience. Using a power supply with less than 1500mA (1.5A) may result

in a slower charging time or your speaker may not be able to charge while

playing audio.

1. Plug the small end of the USB cable into the micro-B USB connector on

your speaker.

2. Plug the other end into a USB power supply (not provided).

The battery light 6blinks amber, and your speaker emits a tone. When fully

charged, 6glows green.

POWER ON/OFF YOUR SPEAKER

On the button pad, press the Power button I.

• The ﬁrst time you power on your speaker, the Bluetooth light glows blue, and you

hear a voice prompt to select a language (see page 18).

• If you have already powered on your speaker and paired at least one mobile device,

the Bluetooth light blinks white and connects to the last two paired mobile devices.

You hear “Battery <number> percent. Connected to <mobile device name>.” The

Bluetooth light glows solid white.

POWER

ENG

BATTERY PROTECTION MODE

When your speaker is unplugged and unused for more than three days with a

remaining charge of less than 10 percent, it enters battery protection mode to

preserve battery power. To reactivate your speaker, connect it to AC (mains) power.

When not in use, store your speaker in a cool place.

CAUTION: Do not store your speaker for extended periods when fully charged or

when the battery light 6blinks red.

AUTO-OFF

Your speaker powers o after 20 minutes of inactivity (no sound coming from your

speaker) while using the following connections and power sources:

• AUX connection operating on battery or AC (mains) power.

• Bluetooth connection operating on battery power.

Disable auto-o

1. Press and hold Hand the Input mode button 7simultaneously.

You hear “Auto-o disabled.”

2. Repeat to re-enable the auto-o feature.

ENG

SPEAKER CONTROLS

The button pad enables you to power on your speaker and control your speaker’s

playback, volume, and speakerphone.

NOTE: Certain mobile devices may not support these functions.

Power button

Bluetooth

button

Multi-function button

Input

mode

button

Volume up

Volume down

SPEAKER CONTROLS

ENG

The Multi-function button Vcontrols music sources and speakerphone calls on your

mobile device from your speaker.

MEDIA PLAYBACK AND VOLUME

FUNCTION WHAT TO DO

Play/Pause

Press V.

NOTE: In Input mode, pressing Vmutes the audio

(see page 24).

Skip forward to the

next track Double-press V.

Skip backward to the

previous track Triple-press V.

Volume up Press H.

Volume down Press z.

SPEAKER CONTROLS

ENG

PHONE CALLS

FUNCTION WHAT TO DO

Make a call

Press and hold the Multi-function button Vto activate

voice control on your mobile device. See “Access voice

control” below.

Switch a call from

speakerphone to your

mobile device, while on a call

Press and hold V.

Answer/End a call Press V.

Decline an incoming call Press and hold V.

Answer a second incoming

call and put the current call

on hold

While on a call, press Vto answer a second call.

Decline a second incoming call

and stay on current call While on a call, press and hold Vfor one second.

Switch between two calls With two active calls, double-press V.

Mute/unmute a call While on a call, press Hand zsimultaneously.

Access voice control

The microphone in the speaker acts as an extension of the microphone in your

smartphone. Using Von the speaker, you can access voice control on your mobile

device to make/take calls, play music, tell you the weather, give you the score of a

game, and more.

Press and hold Vto access voice control on your device. You hear a tone that

indicates voice control is active.

Voice alerts

Your speaker identiﬁes incoming callers (when applicable). To disable this feature, see

page 18.

ENG

Voice prompts guide you through the Bluetooth pairing and connecting processes.

PRE-INSTALLED LANGUAGES

• English • German • Korean • Swedish • Polish

• Spanish • Mandarin • Italian • Dutch

• French • Japanese • Portuguese • Russian

SELECT A LANGUAGE

1. Press zor Hto scroll through available languages.

2. When you hear your language preference, press and hold the Multi-function

button Vto select it.

You hear a beep and “Ready to pair.”

CHANGE THE LANGUAGE

1. Press and hold zand the Input mode button 7simultaneously until you hear the

voice prompt for the ﬁrst language option.

2. Press zor Hto scroll through available languages.

3. When you hear your language preference, press and hold Vuntil you hear a beep,

and “Connected to <mobile device name>.”

DISABLE VOICE PROMPTS

Press and hold zand Hsimultaneously until you hear “Voice prompts o.”

NOTE: Repeat to re-enable voice prompts.

VOICE PROMPTS
