Bosch D9412GV3 User manual

D9412GV3/D7412GV3/D7212GV3

Control Panels Quick Reference Guide

en Quick Reference Guide

D9412GV3/D7412GV3/D7212GV3 Table of Contents | en 3

Bosch Security Systems, Inc. Quick Reference Guide F01U170805 | 01 | 2010.11

Table of Contents

1 GV3 Control Panel Connections (D9412GV3 Shown) 5

2 Upgrade GV3 Hardware and Programming 7

2.1 Receive Existing Control Panel Programming 7

2.1.1 Receive Existing Control Panel Programming with RPS 7

2.2 Upgrade Hardware to a GV3 Series Control Panel 7

2.2.1 Prepare to Remove Existing Hardware 7

2.2.2 Remove the Existing Control Panel 7

2.2.3 Install the GV3 Control Panel In the Enclosure 8

2.2.4 Replace the Terminal Strips 8

2.3 Upgrade Programming to a GV3 Control Panel Programming 9

2.3.1 Upgrade a GV2 Series, G Series, or Non-G Series Control Panel to a GV3 v8.03 or Later Using Remote

Programming Software (RPS) 5.13 or Later9

3 Programming the Control Panel 10

3.1 RPS Programming over a Network Using the DX4020 Ethernet Network Interface Module 10

3.2 RPS Programming over a Network Using the ITS-DX4020-G GPRS/GSM Communicator 10

3.3 RPS Programming Using the DX4010V2 RS-232/USB Serial Interface Module 10

3.4 RPS Programming Using the Keypad Programming 10

4 Programming to Set Up Central Station Reporting 11

4.1 Basic Telephone Set Up in RPS 11

4.2 Basic Internet Protocol (IP) 11

4.3 Account Number 11

5 Programming the Control Panel for Common Reporting Options 12

5.1 Set Up Daily Test Report Using RPS 12

5.2 Set Up Open and Close Reports Using RPS 12

5.2.1 Area Wide Parameters 12

5.2.2 Set Authority Level 12

6 Setting Up Points and Outputs 13

6.1 Using the Relay Option Within Point Assignments 13

6.2 Point Index (Default Values) 14

7 Add System Users Locally With a Keypad 16

7.1 Add Users (CMD 56) Using a Keypad 16

7.2 Add Card (CMD 56) for Access Control Only Using a Keypad 16

8 Turning the System ON or OFF and Keypad Commands 17

8.1 Arming and Disarming the System 17

8.1.1 Master Arming 17

8.1.2 Disarming 17

8.1.3 Set Duress +1 Using RPS 17

4en | Table of Contents D9412GV3/D7412GV3/D7212GV3

F01U170805 | 01 | 2010.11 Quick Reference Guide Bosch Security Systems, Inc.

8.2 Basic and Advanced Commands 17

8.3 SIA CP-01 False Alarm Prevention Options 18

9 Setting DIP Switches 19

9.1 D9127 U/T POPIT Dip Switch Key 19

9.2 D9210B Switch Settings 19

9.3 D720, D1255, D1260 Dip Switch Settings 19

9.4 D9131A Dip Switch Settings 19

9.5 D8129 OctoRelay Dip Switch Settings 19

9.6 D8128C OctoPOPIT Dip Switch Settings 19

9.7 D8128D OctoPOPIT Dip Switch Settings 19

10 Reporting Format Definitions 20

11 Frequently Asked Questions 24

D9412GV3/D7412GV3/D7212GV3 GV3 Control Panel Connections (D9412GV3 Shown) | en 5

Bosch Security Systems, Inc. Quick Reference Guide F01U170805 | 01 | 2010.11

1 GV3 Control Panel Connections (D9412GV3 Shown)

6en | GV3 Control Panel Connections (D9412GV3 Shown) D9412GV3/D7412GV3/D7212GV3

F01U170805 | 01 | 2010.11 Quick Reference Guide Bosch Security Systems, Inc.

D9412GV3/D7412GV3/D7212GV3 Upgrade GV3 Hardware and Programming | en 7

Bosch Security Systems, Inc. Quick Reference Guide F01U170805 | 01 | 2010.11

2 Upgrade GV3 Hardware and Programming

2.1 Receive Existing Control Panel Programming

2.1.1 Receive Existing Control Panel Programming with RPS

1. In RPS, double-click on the control panel name.

2. Click Connect. Once connected, the Panel Sync window opens.

3. Select the Recieve Panel Data option button and click OK.

2.2 Upgrade Hardware to a GV3 Series Control Panel

2.2.1 Prepare to Remove Existing Hardware

1. Power down the existing control panel by disconnecting the battery and the AC power.

2. Remove the four removable terminal strips by tilting the strip up and outward.

Do not remove the wiring from the terminal strip.

2.2.2 Remove the Existing Control Panel

1. Remove the lock down tab screw.

2. Lift up on the control panel to free it from the enclosure mounting hooks, and remove the

control panel from the enclosure it.

NOTICE!

GV3 Series v8.11 and later Control Panels are not compatible with the D5200 Programmer.

1 - Removable terminal strips

1 - Lock down tab

8en | Upgrade GV3 Hardware and Programming D9412GV3/D7412GV3/D7212GV3

F01U170805 | 01 | 2010.11 Quick Reference Guide Bosch Security Systems, Inc.

2.2.3 Install the GV3 Control Panel In the Enclosure

1. Place the GV3 Control Panel in the enclosure using the mounting skirt hook holes on the

back of the control panel and the mounting skirt hooks on the enclosure.

2. Replace the lock down tab screw.

2.2.4 Replace the Terminal Strips

1. Replace the four removable terminal strips by pushing them straight down until they snap

into position.

2. Connect the battery and AC power.

1 - Mounting skirt hook holes

2 - Mounting skirt hooks

3 - Lock down tab

NOTICE!

If the control panel was previously mounted using the screw hole configuration, the you must

re-mount the new control panel. The GV3 control panel mounting screw hole locations do not

align with the locations for older control panels.

D9412GV3/D7412GV3/D7212GV3 Upgrade GV3 Hardware and Programming | en 9

Bosch Security Systems, Inc. Quick Reference Guide F01U170805 | 01 | 2010.11

2.3 Upgrade Programming to a GV3 Control Panel Programming

2.3.1 Upgrade a GV2 Series, G Series, or Non-G Series Control Panel to a GV3

v8.03 or Later Using Remote Programming Software (RPS) 5.13 or Later

1. In RPS, highlight the control panel name by selecting it.

2. Click the View button on the Remote Programmer Toolbar.

3. In the resulting Panel Data - View window, click the Edit button.

4. In the resulting Panel Data - Edit window, select the new control panel type from the

Panel Type drop-down. (If the control panel is a G or Non-G Series control panel, you

must upgrade to GV2 first, and then repeat each of these steps to choose the GV3

control panel.) Click OK to close the window.

5. Click Save in the Panel View window to save the changes and close the Panel View

window.

6. Click Connect. Once connected, the Panel Sync window opens.

7. Select the Send ALL RPS Data to Panel option button and click OK.

8. Once the sync completes, click Disconnect to disconnect from the control panel.

9. Exit RPS.

10. Test the control panel for operation.

NOTICE!

You must upgrade G Series and Non-G Series control panels to GV2 programming prior to

upgrading to GV3 programming.

10 en | Programming the Control Panel D9412GV3/D7412GV3/D7212GV3

F01U170805 | 01 | 2010.11 Quick Reference Guide Bosch Security Systems, Inc.

3 Programming the Control Panel

You can program the control panel with RPS using a network connection or serial connection.

You can program some paramaters of the control panel with keypad programming.

3.1 RPS Programming over a Network Using the DX4020 Ethernet

Network Interface Module

For additional information, refer to IP Address Programming in the Conettix DX4020 Network

Interface Module Installation Guide (P/N: F01U045288).

3.2 RPS Programming over a Network Using the ITS-DX4020-G

GPRS/GSM Communicator

For additional information, refer to the Conettix ITS-DX4020-G Installation Guide

(P/N: F01U163066).

3.3 RPS Programming Using the DX4010V2 RS-232/USB Serial

Interface Module

For additional information, refer to the DX4020 RS-232/USB Serial Interface Module Installation

Instructions (P/N: F01U083036).

3.4 RPS Programming Using the Keypad Programming

For additional information, refer to the D9412GV3/D7412GV3 Program Entry Guide

(P/N: F01U170807) or the D7212GV3 Program Entry Guide (P/N: F01U170808).

D9412GV3/D7412GV3/D7212GV3 Programming to Set Up Central Station Reporting | en 11

Bosch Security Systems, Inc. Quick Reference Guide F01U170805 | 01 | 2010.11

4 Programming to Set Up Central Station Reporting

4.1 Basic Telephone Set Up in RPS

1. Go to PANEL WIDE PARAMETERS→Phone and Phone Parameters.

2. Enter the primary telephone number in the Phone 1 field.

3. If a secondary telephone number is required, enter it in the Phone 2 field.

4. Go to Panel Wide Parameters→Routing→Route Group 1.

5. Enter Phone 1 in the Primary field.

6. If a secondary telephone is required, enter Phone 2 in the Backup field.

4.2 Basic Internet Protocol (IP)

1. Go to PANEL WIDE PARAMETERS→Routing→Route Group 1 Primary.

2. Enter SDI 88 Path 1 (or SDI 92 Path 1).

3. Go to AUXPARM→Enhanced Communications.

4. Select or enter the following values:

4.3 Account Number

In RPS, go to AREA WIDE PARAMETERS and enter the account number (up to 10 digits) in

the Account Number parameter.

NOTICE!

You can program these items using RPS and the steps listed below. You can also use keypad

programming with v8.11 and later (refer to the D9412GV3/D7412GV3 Program Entry Guide

(P/N: F01U170807) or the D7212GV3 Program Entry Guide (P/N: F01U170808).

NOTICE!

Enhanced Communications settings usually follow the recommendations of the Central

Stations’ staff.

If using an ITS-DX4020-G for communication, refer to the ITS-DX4020-G Installation and

Operation Guide (P/N: F01U163066).

Parameter Value

Enable Enhanced Communication YES

Path 1 IP Address IP address of Central Station receiver

Path 1 Port Number Port Number of Central Station receiver

Path 1 Poll Rate (seconds)1Poll rate recommended by Central Station

Path 1 ACK Wait Time 13 sec (default setting)

Path 1 Retry Count 5 (default Setting)

1If the control panel is programmed to send a heartbeat poll to the central station, a rate of 75 sec

maintains the virtual link in most network configurations.

NOTICE!

Area 1 is the only area turned on by default.
