Beta Three T15a THUNDER Series Pro User manual

UM-T15a-20121105 ver C

T15a

User Manual

TwoWay15" Full Range

Active Speaker

THUNDER Series Pro Loudspeaker System

10.

Read the instruction first before using this product.

Pay attention to all warnings.

Obey all operating instructions.

Do not expose this product to rain or moisture.

Do not block any ventilation openings. Install according to instructions .

Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .

Only use spare parts by manufacturer.

Pay attention to the safety symbol on the of the cover.

manual

Please keep this manual for future reference

Clean this equipment with a dry cloth.

manufacturer's

supplied the

outside

SAFETY INSTRUCTIONS

PLEASE READTHIS MANUAL FIRST

Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual

for future reference. g

WARNING:

Thisproduct mustbeinstalledbyprofessionals.Whenusing hangingbracketsorrigging otherthanthosesuppliedwith

theproduct,pleaseensuretheycomplywiththelocalsafetycodes.

Theexclamationpoint withinan equilateral triangleis intendedtoalertyoutothe presenceof important

operatingand servicinginstructions.

ATTENTION:Don't refit the system or spare partswithoutbeingauthorizedasthiswill .voidthewarranty

WARNING: Don't (suchas candles) theequipment.placenakedflames closeto

T15a

CONTENT

Features

Description

Applications

Frequency Response and Impedance Curve

AMPLIFIER MODULE

INSTALLATION

Mounting Accessories

Installation Reference

INTRODUCTION

Technical Sheet

2D Dimension

TECHNICAL SPECIFICATION

Amplifier Module

THUNDER Series Pro Loudspeaker System

Product information is subject to change without

prior notification. Please visit www.elderaudio.com

for latest updates.

T15a

THUNDER Series Pro Loudspeaker System

Features

INTRODUCTION

Applications

Multifunctional hall

Auditorium

Church

Conference room

Small performance

TwoWay15" Full Range Active Speaker

Description

Compact lightweight design with unique appearance.

Performance enhanced with built-in DSP.

Heavy duty powered coated steel grill.

35mm SMART pole mount for vertical and 5°

downward tilt.

Integrated feet for stage monitor applications.

M8 rigging points for convenient installation.

New generation Class D amplifier, durable and reliable.

T15a

LINE OUT A

MIC/LINE IN A VOLUME

MODE

PWR SIG CLIP

MUSIC FLAT

LOWCUT

LINE MIC

0 dB

SYSTEM

RoHS ON

OFF

POWER

LINE OUT BLINE IN B MIX OUT

S/N:

WARNING - PLEASE FOLLOW

THE INSTRUCTIONS SUPPLIED

WITH THE LOUDSPEAKER.

DO NOT SUSPEND OVERHEAD.

15" ACTIVE LOUDSPEAKER

1100W

1 2 5

3 4 6

THUNDER Series Pro Loudspeaker System AMPLIFIER MODULE

8. Line input signal indicator.

9. Line/microphone input A.

10. Line/microphone output A.

11. Line input B.

12. Line output B.

13. Power ON/OFF switch.

14.Volume control.

1. Music mode

2. Flat mode

3. Low cut mode

4. Power indicator

5. Signal indicator

6. Clip indicator

7. Microphone input

signalindicator.

Elder Audio Manufacture Co.,Ltd.

Made In China

15. MIX output.

16. Protection fuse. Use only fuse of the

correct amp rating.

17. Power supply input. Make sure that

the voltage is set for your country's

correct voltage.

Attention :Before changing the MODE switch, please

power the speaker off to avoid possible damage.

Rear Panel Amplifier Module

FUSE:T10AL/250V

AC INPUT:100V-120V ~ 50/60Hz

RATED POWER CONSUMPTION:250W

T15a

THUNDER Series Pro Loudspeaker System

5. Speaker stand application

INSTALLATION

Installation Accessories(Optional) Installation Reference

1. Speaker stand

Warning:Make sure the mounting accessories safety

factor not less than 5:1 or meet the local standard during

installation .

1.Reference A

2.Reference B

3.Reference C

4.Reference D

2. U-Bracket

T15a

100

110

130

20 50 100 200 500 1k 2k 5k 10k 20k -180.0

-108.0

-36.0

36.0

108.0

180.0

Deg

THUNDER Series Pro Loudspeaker System TECHNICAL SPECIFICATION

Specification

Frequency response(-3dB):

Max. SPL:

Transducer:

Input:

Connector:

Input impedance(line):

Input level:

Input overloading level:

Wire connection:

Heat radiation:

Power cable:

45Hz-17kHz

133dB

1 15"Woofer×

XLR for input, XLR for output

20Kohm balanced input, 10Kohm unbalanced input

0 dBV (0.775V rms, 1.0V peak)Line-100Hz

Maximum input level 8V peak

pin 1: ground; pin2: signal +; pin3: signal -

Forced air-cooled drives

90°×60°

Dispersion(H×V):

1 1.7"×Compression Driver

Safety voltage range:

Amplifier power output:

Cabinet:

Handle:

Painting:

Cabinet dimension(W D H):× ×

Packing dimension :(W×D×H)

Net weight:

Gross weight:

1100W

Flying/ Mounting accessories：

Frequency response curve

8×M8 hanging point, SMART pole mount system

Polypropylene injection moulding

Rated impedance: 8 Ohms

Music mode

Flat mode

Low cut mode

32.0kg(70.4 lb)

28.7kg(63.1 lb)

460×396×780mm(18.2×15.6×30.7in)

528×480×865mm(20.8×18.9×34.1in)

Channel one (Mic/Line) balanced input

IEC 3 pin power connector

Two side, one rear

Powered coated grill

AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)

460mm

[18.2in]

780mm

[30.7in]

396mm

[15.6in]

T15a

THUNDER Series Pro Loudspeaker System

Top view

Front view

Side view Back view

Bottom view

2D Dimension

TECHNICAL SPECIFICATION

Notes:

文件（图）名版本第䕌댠䕌눱ヒ³

英文说明书

产品名称

客户⿆럅옯型号

文件（图）号

塑胶音箱

䕌䕌刯β㌯吱䕌（䕌ざ䕌㈰嚣©

文件（图）名版本第䕌页†共䕌页

英文说明书

产品名称

客户⿆럅옯型号

文件（图）号

塑胶音箱

䕌䕌刯β㌯吱䕌（䕌ざ䕌㈰嚣©
