Belkin F5L010 User manual

Laptop Power Adapter for travel

User Manual

P75573_F5L010ea_manual.indd 1P75573_F5L010ea_manual.indd 1 15/10/07 17:06:4215/10/07 17:06:42

Congratulations and thank you for purchasing the Laptop Power Adapter for travel from

Belkin. This new Adapter eliminates the need for multiple power supplies in today’s mobile

society. A user can connect to the most common sources of power including AC wall

sockets, cigarette-lighter assemblies (CLAs) that supply DC power from an automobile

battery, and DC power from a specially designed Belkin battery that can be connected to the

Adapter for short-term needs.

Through the use of patented power-tip technology, this Adapter will not only charge the most

popular laptops (12 tips are included), it will also charge the latest digital devices, including

cell phones, digital cameras, camcorders, portable DVD players, MP3 players, and more.

Introduction

P75573_F5L010ea_manual.indd 3P75573_F5L010ea_manual.indd 3 15/10/07 17:06:4315/10/07 17:06:43

For terms and conditions, to activate your warranty, and to register your Laptop Power

Adapter, please visit www.belkin.com/europe-powersupply.

Product Registration and Warranty

For information on this product disposal please

refer to http://environmental.belkin.com

P75573_F5L010ea_manual.indd 4P75573_F5L010ea_manual.indd 4 15/10/07 17:06:4315/10/07 17:06:43

Before use, please read the following important safety information.

Following these simple guidelines will ensure trouble-free operation and optimal

performance of the Laptop Power Adapter and compatible electronic devices.

1. Avoid pulling on the cords and cables. Always grip plugs firmly when unplugging from

power source and when disconnecting cables. Never force a power tip into an electronic

device.

2. Before use, completely review power-tip compatibility information found in the

instructions, or at www.belkin.com/ europe powersupply.

WARNING: Using the wrong power tip may damage your electronic device or cause it

to malfunction.

3. To avoid electrical hazard, be sure to unplug the Adapter from its external power source

before attaching the power tip.

4. For indoor use only. Avoid exposure to external heat sources; direct, prolonged sunlight;

dust; corrosive chemicals; and moisture.

5. It is normal for power adapters to become warm during use. Avoid touching the device

during use. Avoid placing in direct sunlight or near heat-sensitive materials.

6. Do not drop or subject the Laptop Power Adapter to undue shock.

7. Do not place anything on top of the Laptop Power Adapter.

8. Always use the supplied cables and connectors as shown. Use of cables, connectors,

or accessories not supplied with this product constitutes misuse and may result in injury

or damage.

9. Do not attempt to service or disassemble. The unit is not user-serviceable. Attempting

to disassemble or service the unit can result in electrical hazard, including death from

exposure to high voltage. If you experience problems with the unit, discontinue use

and contact Belkin for assistance. Attempting to open or service the unit voids all

warranties, express or implied.

Important: Safety Information

P75573_F5L010ea_manual.indd 5P75573_F5L010ea_manual.indd 5 15/10/07 17:06:4415/10/07 17:06:44

AC Wall Outlets: The Laptop Power Adapter for travel can be operated from any standard

wall outlet using the attached AC power cord. After attaching the appropriate power tip (see

the “Tip Selection” section) to the output cable of the power supply, insert or attach the tip

to your device to begin charging. Power will immediately be delivered to your device whether

it is powered on or not. Generally, if your unit is not powered on, the battery will begin to

charge. It is normal for power supplies to be warm during use. Avoid placing it near heat

sources, direct sunlight, or heat-sensitive materials.

Air/Auto/Boat/RV: When mobile, the Laptop Power Adapter for travel can be operated using

the cigarette-lighter assembly (CLA) designed by Belkin, provided with this Laptop Power

Adapter. As noted above, after attaching the appropriate power tip (see section VI) to the

output cable of the power supply, insert or attach the tip to your device. Next, insert the CLA

into the socket provided in your vehicle. Power will now be supplied to your laptop or other

mobile device.

Many low-power devices, such as cell phones, PDAs, and MP3 players, can be powered

using the standard USB output. Simply insert the USB cable provided with your device into

the USB port to begin charging or to supply power.

Using the Laptop Power Adapter

P75573_F5L010ea_manual.indd 6P75573_F5L010ea_manual.indd 6 15/10/07 17:06:4415/10/07 17:06:44

Technical Specifications

Input Voltage (AC) 100–240V

Input Voltage (CLA) 12–16VDC

Input Voltage (backbone – battery) 12–16VDC

Output Voltage 16–24V

Output Current 5A (max)

Output Power 69W

USB Output 5V @ 0 to 0.5A

Unit Dimensions 152 x 66 x 32mm

Weight 433.7g

AC Input Cable 635mm

DC Power Output Cable 172.7cm

CLA Cable 51.5cm

Storage Temperature -40 to 85° C

Operating Temperature 0 to 40° C

Relative Humidity (non-condensing) 95%, max

Built-In Circuit Protection Overvoltage, undervoltage,

over temperature

P75573_F5L010ea_manual.indd 7P75573_F5L010ea_manual.indd 7 15/10/07 17:06:4515/10/07 17:06:45

Belkin has made life easy for you by providing your new Laptop Power Supply with twelve

(12) power tips for virtually any PC-based laptop.*

To get going, follow these easy steps:

Unplug power supply

Choose power tip (see the “Tip Selection”x section and Tip Compatibility List)

Connect tip to output cable

Plug tip into laptop

Plug in power supply

If you wish to connect to a device using the built-in USB connector, the steps are similar:

Unplug power supply

Connect device cable to USB port

Plug cable into device

Plug in power supply

Getting Connected

P75573_F5L010ea_manual.indd 8P75573_F5L010ea_manual.indd 8 15/10/07 17:06:4515/10/07 17:06:45

Tip Selection

Each laptop has a specific tip that can be used for power. These tips have different

dimensions and deliver different levels of current and voltage. It is important that you

choose the correct tip for your laptop.

Belkin has provided twelve (12) of the most popular laptop tips with this device (see table

below). The tips can be used with laptops from major manufacturers that include HP®,

IBM®, Toshiba®, Sony®, Dell®, and others.

Power-Tip Compatibility List

Tip # Laptop Manufacturer

1 Acer®

3 Gateway®, Acer, IBM

4 IBM

5 Hewlett-Packard®, NEC®, Toshiba

6 Panasonic®, Sony

7 Sony

8 Toshiba

11 Compaq®

29 Compaq, Hewlett-Packard

36 Dell

125 IBM

129 Hewlett-Packard

*Laptop Guarantee: If we didn’t include a tip for your laptop, tell us at www.belkin.com/europe-powersupply

and we’ll ship your first tip free! (Excludes Apple®laptops)

P75573_F5L010ea_manual.indd 9P75573_F5L010ea_manual.indd 9 15/10/07 17:06:4515/10/07 17:06:45

If your device is not charging or operating properly, take the following steps:

1. Disconnect the Laptop Power Adapter from its power source.

2. Verify that the correct power tip has been installed by checking the Power-Tip

Compatibility List. NEVER force a power tip into an electronic device.

3. Reconnect the Laptop Power Adapter. Check that all connections are secure.

4. Plug the correct power tip into your electronic device. The device should begin charging

regardless of whether it is powered on or not.

5. Note that if the green power-indicator LED does not light, it may have simply burned out.

6. If you are still experiencing problems, please contact Belkin.

Troubleshooting

P75573_F5L010ea_manual.indd 10P75573_F5L010ea_manual.indd 10 15/10/07 17:06:4615/10/07 17:06:46

CE Declaration of Conformity

We, Belkin International, Inc., declare under our sole responsibility that the F5L010, to which

this declaration relates, is in conformity with Generic Emissions Standard EN 55022 and with

Generic Immunity Standard EN 55024 and LVD 1998.

Belkin International, Inc., Limited Lifetime Product Warranty

What this warranty covers.

Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this Belkin product

that the product shall be free of defects in design, assembly, material, or workmanship.

What the period of coverage is.

Belkin warrants the Belkin product for the 3-Year Warranty.

What will we do to correct problems?

Product Warranty.

Belkin will repair or replace, at its option, any defective product free of charge (except for

shipping charges for the product).

What is not covered by this warranty?

All above warranties are null and void if the Belkin product is not provided to Belkin

for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin

determines that the Belkin product has been improperly installed, altered in any way, or

tampered with. The Belkin Product Warranty does not protect against acts of God such

as flood, earthquake, lightning, war, vandalism, theft, normal-use wear and tear, erosion,

depletion, obsolescence, abuse, damage due to low voltage disturbances (i.e. brownouts or

sags), non-authorized program, or system equipment modification or alteration.

Information

P75573_F5L010ea_manual.indd 11P75573_F5L010ea_manual.indd 11 15/10/07 17:06:4615/10/07 17:06:46
