Avocent SwitchView SC120 User manual

Proven and Secure Access for Any Environment

The Avocent SwitchView SC100 and SC200 KVM switch series offers proven, secure

access for any desktop environment where security is mandatory. NIAP validated to EAL4+

and with USB Common Access Card (CAC) reader support (available on the SwitchView

SC200 switches), three levels of physical security, and controlled USB connectivity, you

can consolidate multiple workstations of varying security classiﬁ cation levels with one

keyboard, monitor and mouse without compromising network security.

The SwitchView SC200 switches allow desktop IT administrators to deploy a single CAC

reader that will switch to all computers connected to the switch. (CAC support is required

for all government employees attempting to log in to government systems and is speciﬁed in

the Homeland Security Presidential Directive 12 [HSPD12].)

Both the SwitchView SC100 and SC200 switches include three layers of

tamper-proof hardware security at the desktop. In addition, SwitchView SC100

and SC200 switches ensure that only USB human interface devices (HIDs)

function on target computers by constantly monitoring all devices attached to the

console ports. These switches ignore communication from non-HIDs (such as

ﬂash drives, hard disk drives, cameras and printers) when switching data to the

target. In situations where the only USB port(s) for HIDs are enabled on the target

computer, the SwitchView SC switch will not introduce security vulnerabilities.

The SwitchView SC100 and SC200 switches offer support for USB and/or PS/2

peripherals and target computers.

Switchview SC100 and

SC200 Switch Beneﬁts

NIAPValidated to EAL4+

CAC support. USB Common

Access Card (CAC) reader

support in the SwitchView

SC200 switch series.

Software security. U.S designed

ﬁrmware allows only keyboard

and mouse human interface

devices (HIDs) to switch to

the target computers.

Three layers of hardware security:

a) Tamper-evident tape: A

visual indication of an attempt

to gain access to the internal

components of the switch

b) Chassis intrusion detection:

Prevents malicious tampering with

the switch. If the cover is removed

from the switch, the switch becomes

inoperable and the LEDs ﬂash

c) Locked memory: Prevents

tampering and reprogramming

of the ﬁrmware

Secure channels: Two to

eight secure channels

Clears buffer: Automatically clears

the keyboard buffer immediately

after data is transmitted

through the switch, so no data

is ever left in the switch

SwitchView SC100 and SC200 switching solutions provide with

three layers of tamper-proof hardware security. The SC200

switches add CAC support at the desktop.

SwitchView® SC100 & SC200 KVM Swicthes Enhance Security at the Desktop

CAC support allows desktop IT administrators to deploy a single CAC reader that can

be switched to all computers connected to the switch.

Avocent, the Avocent logo, The Power of Being There, DSR, Mergepoint and

DSView are trademarks or registered trademarks of Avocent Corporation or its

afﬁliates. All other marks are the property of their respective owners.

0507-TCP-WKBK

Corporate Headquarters

4991 Corporate Drive, Huntsville, AL 35805

TEL 866.286.2368 FAX 256.430.4030

www.avocent.com

Part Number Model Description

Ordering Details

SC120-001 SwitchView SC120 1x2 SwitchView SC switch

PS/2, USB & VGA, intrusion detection

SC140-001 SwitchView SC140 1x4 SwitchView SC switch

PS/2, USB & VGA, intrusion detection

SC180-001 SwitchView SC180 1x8 SwitchView SC switch

PS/2, USB & VGA, intrusion detection

SC220-001 SwitchView SC220

1x2 SwitchView SC switch

PS/2, USB & VGA, CAC reader

support,intrusion detection

SC240-001 SwitchView SC240

1x4 SwitchView SC switch

PS/2, USB & VGA, CAC reader

support,intrusion detection

SC280-001 SwitchView SC280

1x8 SwitchView SC switch

PS/2, USB & VGA, CAC reader

support,intrusion detection

Speciﬁcations

Mechanical

Size: 1.72” (4.37 cm)H, 10.36”

(26.31 cm)W, 5.68” (14.43 cm)D

Weight: 2.3 lbs (1.04 Kg)

Style: Desktop

Environmental

Operating Temperature: 32 to 104 F (0

to 40 C)

Storage Temperature: 4 to 122 F (-20

to 50 C)

Humidity: 10% to 95% (Non-

condensing)

Power

Operating Voltage: 100-240 VAC

Power Frequency: 50-60 Hz

Input: .8A

Supported Hardware

Target Devices: IBM, Sun, PC/AT, USB,

PS/2 and 100% compatibles

Monitors: VGA, SVGA, XGA, SXGA,

UXGA, WVGA, WSVGA, WXGA,

WSXGA, AND WUXGA

Maximum Resolution: 2048x1536 @

85Hz

Peripherals: USB and/or PS/2 keyboard,

USB and/or PS/2 mouse

Standards

Approved Agency: CE, UL 60950-1,

CSA C22.2 No 60950-1, EN60950,

FCC Part 15 Class B EN55022 Class

B, EN55024 61000-3-3, VCCI Class B,

C-Tick CISPR22, ICES-003

WARRANTY

Two Year
