Phoenix2

Rev. A - Owner's Manual 0399

Table of Contents

Phoenix2..................................2

Lifetime Warranty............................2

Remote Controls ............................2

Electronic Scan Prevention (ESP).....................3

Instant Remote Control Code Deletion..................3

One-Step Remote Control Code Learning................3

Valet Switch...............................3

Operating Instructions...........................4

To Arm The System ...........................4

To Disarm the System ..........................4

Remote-Controlled Silent Arm/Disarm .................4

User-Programmable Long-Term Silent Arm/Disarm ...........5

Two Stage Unlock Capability ......................5

Remote Panic with Safety Locks™....................5

Interior Light Illumination ........................5

User-Programmable Passive Door Lock .................5

User-Programmable Ignition-Controlled Door Lock/Unlock .......6

Protected Valet Mode ..........................6

Remote-Controlled Valet ........................6

Keyless Entry in Valet ..........................7

LED System Status Indicator .......................7

Remote-Controlled Accessory Outputs.................7

Zone

™ Impact Sensor .........................7

Remote-Controlled Sensor Bypass ....................8

Previous Intrusion Alert .........................8

Specific Zone Intrusion Identification ..................8

User-Programmable Door Ajar Indication ...............8

User-Programmable Siren Duration ...................9

Alarm State Memory ..........................9

Automatic Malfunction Override ....................9

User-Programmable Features .......................10

Programming Table for Alarm Features.................11

Programming Table for Remote Controls................12

Phoenix

Rev. A - Owner's Manual 0399

Phoenix 2

Congratulations! You have just purchased the Phoenix2

vehicle security system

manufactured by Avital Technologies, Inc.

To fully benefit from the capabilities of your system, we encourage you to

read the Owner’s Manual thoroughly before using the system. If you have any

problems or questions regarding your system, consult the dealer from whom

you purchased this product. To locate an authorized Avital dealer, contact

Avital Technologies directly at 1-800-253-0334 (toll-free within the U.S.) or

1-847-215-2233.

Lifetime Warranty

Avital guarantees the operation of your control unit and remote controls for as

long as you own your car. (Please refer to your Lifetime Limited Warranty

Card for complete information.) Make sure that you receive your warranty

card from your dealer, complete the required information and mail the

registration portion to Avital Technologies. You should retain the top portion

of the warranty card for your records.

Remote Controls

Included with your system are two AviGlo™ 4-button/9-channel remote

controls. Once exposed to light, the AviGlo remote control buttons will glow,

making the buttons visible in the dark.

The remote control (remote) is a miniature transmitter powered by a small

+12 volt battery. Obstructions, electrical or radio interference, weather

conditions, window tint or a weak battery can reduce range. Your remote is

the key to your system and can be used to arm and disarm your alarm, lock

and unlock your doors, "pop" your trunk, and control optional accessories

such as a remote engine starter, window roll-up and garage door opener.

The system can accept up to four Avital remote controls. Additional remote

controls and remote control batteries can be purchased from any authorized

Avital dealer, or by calling Avital Technolgies toll-free at 1-800-253-0334

(within the U.S.) or 1-847-215-2233.

Phoenix2

Rev. A - Owner's Manual 0399

Electronic Scan Prevention (ESP)

Your system includes ESP, which blocks electronic scanner codes preventing

unauthorized operation of your system.

Instant Remote Control Code Deletion

In the event of a lost or stolen remote control, all remote controls can be

erased from the system’s memory preventing unauthorized system operation.

(See the "Programming Table for Remote Controls" on page 12).

One-Step Remote Control Code Learning

Your system allows you to add new remote controls in one step. (See the

"Programming Table for Remote Controls" on page 12).

Valet Switch

The valet switch is a small hidden toggle switch which allows you to control all

of the system’s programmable features. (See "User-Programmable Features" on

page10).Thisswitchcanonlybecontrolledwiththeuseofyourignitionkey.

NOTE:Besuretohaveyourdealershowyouwherethevaletswitch islocated.

Phoenix2

Rev. A - Owner's Manual 0399

Operating Instructions

To Arm The System

The alarm can be programmed for active or passive arming. Active arming

means the alarm can only be armed by the remote control. Passive arming

means the alarm will automatically arm itself. (See the "Programming Table

for System Features" on page 11.)

Active Arming

Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp

twice, the parking lights will flash twice, the doors will lock, the LED will flash

slowly and the starter will be disabled.

Passive Arming

Turn the ignition key "OFF," exit the vehicle and close the doors. When the

interior lights turn off, the LED will begin flashing rapidly to indicate the alarm

is passive arming. After 30 seconds, the siren will chirp twice, the parking

lights will flash twice, the LED will flash slowly and the starter will be disabled

(at any time during passive arming, the alarm can be actively armed).

To Disarm the System

Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp

once, the parking lights will flash once, the doors will unlock, the interior

lights will turn on, the LED will turn off and the starter will be enabled.

Remote-Controlled Silent Arm/Disarm

Press the remote SILENT button for 1-2 seconds to arm or disarm your system

without the usual siren chirps.

Silent Arm Indications

The parking lights will flash twice, the doors will lock, the starter will be

disabled and the LED will flash slowly.

Silent Disarm Indications

The parking lights will flash once, the doors will unlock, the starter will be

enabled and the LED will turn off.

Phoenix2

Rev. A - Owner's Manual 0399

User-Programmable Long-Term Silent Arm/Disarm

This feature allows you to completely disable the arm/disarm siren chirps until

you decide to restore them. (See the "Programming Table for System Features"

on page 11.)

Two-Stage Unlock Capability

If the optional Two-Stage Unlock feature was installed, press the remote

ARM/DISARM button for 1-2 seconds and only the driver door will unlock.

Within 3 seconds, press the remote ARM/DISARM button again and the

passenger door(s) will unlock (may require an optional relay).

Remote Panic with Safety Locks™

In a threatening situation, you can activate Remote Panic with Safety Locks.

When activated, the siren will sound and the parking lights will flash. If you

are inside your vehicle and the ignition key is "ON," the doors will lock. If you

are outside the vehicle with the ignition key "OFF," the doors will unlock.

To Activate

1.Press the remote ARM/DISARM button for 3-4 seconds.

2. The siren will sound and the parking lights will flash.

3.If the ignition key is "OFF," the doors will unlock. If the ignition key is

"ON," the doors will lock.

To Deactivate

1.Press the remote ARM/DISARM button for 1-2 seconds.

2. The siren will shut off and the parking lights will stop flashing.

Interior Light Illumination

When the alarm system is remotely disarmed, the vehicle interior light(s) will

turn on for 30 seconds or until the ignition key is turned on.

User-Programmable Passive Door Lock

The system will not automatically lock the doors when the alarm passively

arms to prevent the keys and remote from being locked in the vehicle. If you

prefer, you can easily program the alarm to automatically lock the doors every

time the alarm passively arms. (See the "Programming Table for System

Features" on page 11.)

Phoenix2

Rev. A - Owner's Manual 0399

User-Programmable Ignition-Controlled Door Lock/Unlock

For the ultimate in security and convenience, the system is programmed to

automatically lock your doors when the ignition key is turned "ON" or the

engine is started, and will unlock when the ignition key is turned "OFF." This

feature can be programmed ON or OFF. (See the "Programming Table for

System Features" on page 11.)

Protected Valet Mode

You should place your system in Protected Valet Mode whenever your vehicle

is being serviced by mechanics, car wash personnel or driven by valet parking

attendants. While in the Protected Valet Mode, all alarm functions are

bypassed to prevent unauthorized or accidental operation. Remote-controlled

door lock/unlock , trunk release and all optional accessories will still operate.

To Turn On Protected Valet Mode

1.Turn your ignition key to the "ON" position or start the engine.

2.Flick the valet switch to the "ON" position.

3. The LED will turn on solid red to indicate the system is in Protected Valet

Mode.

4.Turn your ignition key to the "OFF" position.

To Turn Off Protected Valet Mode

1.Turn your ignition key to the "ON" position or start the engine.

2.Flick the valet switch to the "OFF" position.

3. The LED will turn off to indicate the system is no longer in Protected Valet

Mode.

4.Turn your ignition key to the "OFF" position

Remote-Controlled Valet

For your convenience, the system can be put into Valet mode via the remote

control. While in Remote-Controlled Valet, all alarm functions are bypassed.

To Activate Remote-Controlled Valet

1.Press the remote ARM/DISARM and SILENT buttons at the same time.

2. The parking lights will flash 4 times.

3.The LED will turn on solid red to indicate the alarm is now in

Remote-Controlled Valet.

Phoenix2

Rev. A - Owner's Manual 0399

To Deactivate Remote-Controlled Valet

1.Press the remote ARM/DISARM and SILENT buttons at the same time.

2. The parking lights will flash 3 times.

3.The LED will turn off to indicate the alarm is no longer in

Remote-Controlled Valet.

Keyless Entry in Valet Mode

While the system is in the Valet mode, you can still use your remote control to

lock and unlock the doors as well as activate any optional accessory such as

trunk release or remote engine starter.

LED System Status Indicator

The LED on your vehicle’s dashboard or center console will inform you of the

system status.

LEDStatus

OffSystem is disarmed

On solidIn a valet mode

Slow flashSystem is armed

Flashing in cyclesSee "Specific Zone Intrusion Identification"

on page 8

Rapid flashPassive arming

Remote-Controlled Accessory Outputs

These outputs allow you to add optional remote-controlled accessories to your

system such as a remote engine starter, trunk release, window roll-up, garage

door opener or fuel door release. To activate your optional accessories, see

the "Programming Table for Remote Controls" on page 12.

Zone2

™ Impact Sensor

The Zone2

Impact Sensor has two individual vibration/impact sensing zones.

Zone #1

If a less threatening vibration or impact is detected, the siren will issue 2

warn-away chirps. A second violation will also issue 2 warn-away chirps. If

within 45 seconds a third violation is detected, the sensor will automatically

trigger the alarm. The siren will sound and the lights will flash.

Zone #2

If a more threatening vibration or impact is detected at any time, the siren and

lights will activate instantly.7

Phoenix2

Rev. A - Owner's Manual 0399

Remote-Controlled Sensor Bypass

You can bypass the system sensor(s) at any time. The alarm system will still

provide full perimeter protection.

To Bypass the Sensor(s):

1.Press the remote TRUNK and OPTION buttons at the same time.

2. The siren will chirp twice. . . pause. . . chirp twice. . . pause . . . chirp

twice.

3.The sensor(s) is now bypassed until you remotely disarm and then re-arm

your system.

Previous Intrusion Alert

If the vehicle had been tampered with and the alarm has been triggered, the

siren will chirp 3 times upon remote disarm instead of the usual 1 chirp.

Specific Zone Intrusion Identification

If the alarm had been triggered in your absence, the siren will chirp 3 times

upon remote disarm (Previous Intrusion Alert). When you enter the vehicle

and turn the ignition "ON," the LED will flash in cycles to specifically identify

which zone has triggered the alarm.

LEDZone

One Flash...One Flash...Impact sensor

Two Flash...Two Flash...Hood/trunk trigger

Three Flash...Three Flash...Door trigger

User-Programmable Door Ajar Indication

When you remotely arm the alarm system and a door is ajar (not closed), the

siren will chirp 2 times, then chirp 3 times and the parking lights will flash 3

times. This feature provides audible and visual indication to prevent battery

drain. (See "Programming Table for System Features" on page 11.)

NOTE: If your vehicle has factory delayed lighting, this feature will be

turned off.

Phoenix2

Rev. A - Owner's Manual 0399

Other manuals for Phoenix 2

Table of contents

Popular Car Alarm manuals by other brands

Clifford

Clifford 3606X owner's guide

Ultra Start

Ultra Start 2500M SERIES install guide

Ultra Start

Ultra Start 650 Series owner's manual

Audiovox

Audiovox Prestige Platinum+ APS-511C owner's manual

Sparkrite

Sparkrite SRA8 Guide

Viper

Viper 4708V owner's manual

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Installation and maintenance manual

Falcon

Falcon Predator XL3 Installer manual

Audiovox

Audiovox Auto Security XR91 Programming guide

Clifford

Clifford Sabre II owner's manual

CrimeStopper

CrimeStopper CS-8717 Wiring diagram

Ultra Start

Ultra Start 450 SERIES install guide

Scytek electronic

Scytek electronic Vectra X3 product manual

Excalibur

Excalibur AL-1860-EDPB Operation guide

Clifford

Clifford CYBER 2 owner's manual

Gemini

Gemini 7057 user manual

FlashLogic

FlashLogic FLRSBA PRESTIGE Product guide

Magicar

Magicar FAI-440 manual
