Audio Pro Bravo FX-01 User manual
Tekniska data:
Typ:......................................Sluten låda
Bestyckning: (Skärmade)
Diskant:.............1” Super Tweeter
Bas:...................................5 1/4”
Delningsfrekvens:.......................2.400Hz
Frekvensomfång:...............50-50.000Hz
50 - 42.000Hz (-3dB)
Känslighet: (1W / 1M)....................87dB
Impedans:...............................4 ohm
Rek. förstärkareffekt:............25 - 125 W
Dimensioner:(BxHxDmm)....190x290x260
Technical data:
Enclosure:...........................Closed box
Drive units: (Shielded)
Tweeter:............1” Super Tweeter
Woofer:..............................5 1/4”
Crossover:.................................2.400Hz
Frequency range:..............50-50.000Hz
50 - 42.000Hz (-3dB)
Sensitivity: (1W / 1M)....................87dB
Impedance:.................................4 ohm
Amp. requirement:...............25 - 125 W
Dimensions:(WxHxD mm)...190x290x260
Placering:
See the enclosed Audio Pro instruction
manual for further information.
Se medföljande Audio Pro instruktions-
bok för ytterligare information.
Placement:
Audio Pro AB, Helsingborg, Sweden
Swedish/English
BRAVO FX-01
FX-01 Tech data.pmd 2005-01-03, 11:451
Charactéristiques:
Type:.................Suspension acoustique
Haut-parleurs: (Avec blindage)
Tweeter:............1” Super Tweeter
Woofer:..............................5 1/4”
Fréquence de séparation:.........2.400Hz
Réponse en fréquence:......50-50.000Hz
50 - 42.000Hz (-3dB)
Sensibilité: (1W / 1M).....................87dB
Impédance:................................4 ohm
Puissance d’entrée:..............25 - 125 W
Dimensions:(LxHxP mm).....190x290x260
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:
Ôýðïò:..........................Êëåéóôü êïõôß
ÌåãÜöùíá: (ÈùñáêéóìÝíá)
Ôïõßôåñ:.........................Èüëïò 1"
Ãïýöåñ:............................5 1/4"
Crossover:................................2.400Hz
Aðüêñéóç óõ÷íïôÞôùí:.......50-50.000Hz
50 - 42.000Hz (-3dB)
Åõáéóèçóßá: (1W / 1M)...................87dB
Áíôßóôáóç..................................4 ohm
Åíßó÷õóç:................................25-125W
ÄéáóôÜóåéò:(ÐxYxB)....190x290x260mm
Emplacement:
Ãéá ðåñéóóüôåñåò ëåðôïìÝñåéåò
áíáöåñèåßôå óôï åã÷åéñßäéï ïäçãéþí.
Se référer au mode d’emploi ci-joint.
ÔïðïèÝôçóç
Audio Pro AB, Helsingborg, Sweden
Français/Åëëçíéêá
BRAVO FX-01
FX-01 Tech data.pmd 2005-01-03, 11:452
Technische gegevens:
Soort:........................................Gesloten kast
Speaker soort: (afgeschermd)
Tweeter:................1” Super Tweeter
Woofer:......................................5 1/4”
Crossover:.......................................2.400Hz
Freq. Bereik:...........................50-50.000Hz
50 - 42.000Hz (-3dB)
Gevoeligheid: (1W / 1M).....................87dB
Impedancy:..........................................4 ohm
Aanbevolen versterker vermogen: 25 - 125 W
Maten:(BxHxDmm):.............190x290x260
Plaatsing:
Weitere Informationen erhalten sie
aus der beiliegenden Audio Pro
Bedienungsanleitung.
Lees hiervoor de Audio Pro ge-
bruiksaanwijzing.
Aufstellung:
Audio Pro AB, Helsingborg, Sweden
Nederlands/Deutsch
Technische Daten:
Typ:.........Geschlossene Lautsprecherbox
Bestückung: (Magnetisch abgeschirmt)
Hochtöner:...........1”Super Tweeter
Baß:.............................................5 1/4”
Übergangsfrequenz:.....................2.400Hz
Frequenzgang:......................50-50.000Hz
50 - 42.000Hz (-3dB)
Schalldruck: (1W / 1M).......................87dB
Impedance:.........................................4 ohm
Empf. Verstärkerleistung:........25 - 125 W
Abmessungen:(WxHxDmm)..190x290x260
BRAVO FX-01
FX-01 Tech data.pmd 2005-01-03, 11:453
Tekniset tiedot:
Kotelotyyppi:.................................Suljettu
Elementit: (Magneettisuojattu)
Diskantti:...........1"Super Diskantti
Basso:.....................................5 1/4"
Jakotaajuus:.................................2.400Hz
Toistoalue:.............................50-50.000Hz
50-42.000Hz (-3dB)
Herkkyys: (1W / 1M)..........................87dB
Impedanssi:.....................................4 ohm
Vahvistin suositus:.................25 - 125 W
Mitat:(L x K x S mm)..........190x290x260
Sijoitus:
Katso mukana oleva ohje. Per ulteriori informazioni vedere
l’accluso manuale d’instruzione
Audio Pro.
Collocazione:
Audio Pro AB, Helsingborg, Sweden
Suomi/Italiano
Dati tecnici:
Tipo:........................................Cassa chiusa
Elementi: (schermati)
Tweeter:...............1” Super Tweeter
Woofer:......................................5 1/4”
Crossover:........................................2.400Hz
Gamma di frequenze:.............50-50.000Hz
50-42.000Hz (-3dB)
Sensibilita`: (1W / 1M).........................87dB
Impedenza:..........................................4 ohm
Potenza richiesta:......................25 - 125 W
Dimensioni: mm 190x290x260 (L x A x P)
BRAVO FX-01
FX-01 Tech data.pmd 2005-01-03, 11:454
Ubicación:
Vea el manual de instrucciones Audio
Pro adjunto para obtener más
información.
Datos técnicos:
Tipo:...........................................Caja cerrada
Altavoces: (con protección)
Tweeter:..........................Cúpula de 1”
Woofer:........................................5 1/4”
Frecuencia de cruce:......................2.400Hz
Banda de frecuencias:.........50 – 50.000Hz
50-42.000Hz (-3dB)
Sensibilidad: (1W / 1M).......................87dB
Impedancia: .......................................4 ohm
Requisitos de amplificador:.....25 – 125 W
Dimensiones:(AxAxP mm).....190x290x260
Español
Audio Pro AB, Helsingborg, Sweden
BRAVO FX-01
FX-01 Tech data.pmd 2005-01-03, 11:455
