Asus DSL-N66U User manual

Quick Start Guide

DSL-N66U

Dual-band WiFi ADSL/VDSL Modem Router

APAC8322_DSL-N66U_QSG.indb 1 4/26/13 1:45:19 PM

Table of contents

APC8322 / First Edition / April 2013

English.........................................................................................................................3

Bahasa Indonesia.....................................................................................................8

Bahasa Malaysia.......................................................................................................13

ไทย ..............................................................................................................................18

APAC8322_DSL-N66U_QSG.indb 2 4/26/13 1:45:20 PM

Hardware Features

Ethernet WAN DSL WAN

1. Reset button

2. USB 2.0 ports

3. Ethernet WAN

4. LAN 1~4 ports

5. DSL WAN

6. Power (DC-In) port

DSL

2.4GHz

5GHz

WPS

1. USB 2.0 LED

2. LAN LED

3. 5GHz LED

4. 2.4GHz LED

5. WAN LED

6. VDSL/ADSL LED

7. Power LED

8. Wireless button

9. WPS button

Front

Rear

English

APAC8322_DSL-N66U_QSG.indb 3 4/26/13 1:45:21 PM

• USB External HDD/Flash disk:

• This wireless router works with most USB HDDs/Flash disks up

to 2TB and supports read-write access for FAT16, FAT32, EXT2,

EXT3, and NTFS.

• To safely remove the USB disk, launch the web GUI

(http://192.168.1.1), click the USB icon on the Network Map

page and click Eject USB disk.

• Incorrect removal of the USB disk, such as during video/music

streaming or le downloading, may cause data corruption.

• For the list of le system and hard disk partitions that this

wireless router supports, visit:

http://event.asus.com/networks/disksupport

• For the list of printers that the wireless router supports, visit:

http://event.asus.com/2009/networks/printersupport

Package contents

If any of the items is damaged or missing, contact your

retailer.

DSL-N66U wireless modem router

Network cable (RJ-45)

AC adapter

Phone cable

Warranty card

Quick Start Guide

Support CD (User Manual/utilities)

Splitter (varies with regions)

English

APAC8322_DSL-N66U_QSG.indb 4 4/26/13 1:45:24 PM

English

Positioning your wireless router

For the best wireless signal transmission between the wireless router

and the network devices connected to it, ensure that you:

• Place the wireless router at the center of your network for maximum

wireless coverage.

• Keep the device away from metal obstructions and away from direct

sunlight.

• Keep the device away from 802.11g or 20MHz only Wi-Fi devices,

2.4GHz computer peripherals, Bluetooth devices, cordless phones,

transformers, heavy-duty motors, uorescent lights, microwave

ovens, refrigerators, and other industrial equipment to prevent

signal interference or loss.

• For optimum performance, adjust the internal cooling system. Refer

to the user manual for details.

• Always update to the latest rmware. Visit the ASUS website at

http://www.asus.com to get the latest rmware updates.

VSL-N66U

N900 Dual Band Wi-Fi VDSL Modem Router

APAC8322_DSL-N66U_QSG.indb 5 4/26/13 1:45:25 PM

Before you proceed

1. Connect your devices.

2. Before setting up your network, ensure that the DSL LED

indicator is a solid light.

Ethernet WAN DSL WAN

Network cable

Wall power outlet

Wall telephone

outlet

DSL

2.4GHz

5GHz

WPS

English

APAC8322_DSL-N66U_QSG.indb 6 4/26/13 1:45:27 PM

3. Launch a web browser and follow the Quick Internet Setup

(QIS) steps.

If the QIS web page does not appear after you launched

the web browser, disable the proxy settings on the web

browser.

4. Setup complete.

English

APAC8322_DSL-N66U_QSG.indb 7 4/26/13 1:45:29 PM

Fitur Perangkat Keras

Ethernet WAN DSL WAN

1. Tombol atur ulang

2. Port USB 2.0

3. WAN Ethernet

4. Port LAN 1~4

5. WAN DSL

6. Port daya (DC-IN)

DSL

2.4GHz

5GHz

WPS

1. LED USB 2.0

2. LED LAN

3. LED 5GHz

4. LED 2.4GHz

5. LED WAN

6. LED VDSL/ADSL

7. LED Daya

8. Tombol nirkabel

9. Tombol WPS

Depan

Belakang

Bahasa Indonesia

APAC8322_DSL-N66U_QSG.indb 8 4/26/13 1:45:30 PM

Bahasa Indonesia

• HDD Eksternal USB/Flash disk:

• Router nirkabel berfungsi dengan sebagian besar HDD USB//

Flash disk yang berkapasitas hingga 2 TB serta mendukung

akses baca-tulis untuk FAT16, FAT32, EXT2, EXT3, dan NTFS.

• Untuk melepas disk USB dengan aman, aktifkan GUI Web

(http://192.168.1.1), kemudian di sudut kanan atas halaman

Network Map (Peta Jaringan), klik ikon USB, lalu klik Eject

USB 1 (Lepas USB 1).

• Pelepasan disk USB yang tidak benar dapat menyebabkan

kerusakan data.

• Untuk mengetahui daftar partisi hard disk dan sistem le

yang didukung router nirkabel, kunjungi http://event.asus.

com/ networks/disksupport

• Untuk mengetahui daftar printer yang didukung router nirkabel,

kunjungi:

http://event.asus.com/2009/networks/printersupport

Isi kemasan

CATATAN: Jika salah satu item tersebut rusak atau tidak

ada, hubungi peritel.

Router modem nirkabel DSL-N66U

Kabel jaringan (RJ-45)

Adaptor AC

Kabel telepon

Kartu jaminan

Panduan Ringkas

CD Dukungan (Panduan Pengguna/utilitas)

Pembagi jalur (beragam menurut wilayah)

APAC8322_DSL-N66U_QSG.indb 9 4/26/13 1:45:31 PM

Mengatur posisi router nirkabel Anda

Untuk transmisi sinyal nirkabel terbaik antara router nirkabel dan

perangkat jaringan yang tersambung, pastikan Anda:

• Menempatkan router nirkabel di area tengah agar jangkauan

nirkabel maksimum untuk perangkat jaringan.

• Tidak menghalangi perangkat dengan benda logam dan

menjauhkan dari sinar matahari langsung.

• Menjauhkan perangkat dari perangkat Wi-Fi 802.11g atau hanya

20 MHz, periferal komputer 2,4 GHz, perangkat Bluetooth, telepon

nirkabel, trafo, mesin berat, cahaya neon, oven microwave, lemari

es, dan peralatan industri lainnya untuk mencegah interferensi atau

hilangnya sinyal.

• Untuk performa optimal, sesuaikan sistem pendinginan internal.

Untuk informasi rinci, lihat panduan pengguna.

• Selalu memperbarui ke rmware terkini. Untuk mendapatkan

pembaruan rmware terkini, kunjungi situs Web ASUS http://www.

asus.com.

VSL-N66U

N900 Dual Band Wi-Fi VDSL Modem Router

Bahasa Indonesia

APAC8322_DSL-N66U_QSG.indb 10 4/26/13 1:45:32 PM
