Assa Abloy Corbin Russwin HPSK User manual

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected] FM339 10/18

Installation Instructions

permission of Corbin Russwin, Inc. is prohibited.

Push/Pull (HPSK) Paddle Trim for

ML2000 Series Mortise Locks

1Mortise Lock Handing Instructions.............................................2

Mortise Lock Door Preparation & Installation .....................................3

HPSK Trim Installation.....................................................5

Turn-Piece Installation.....................................................8

Coin-Turn Installation .....................................................8

TOC Table of Contents

Cover Screws

Cover

Paddle

Insert Insert

Screws

Surface Mount

Screws

Axle

Mounting

Post Screws

Inside Paddle

Chassis

Axle

Outside Paddle

Chassis

Surface Mount

Screws

Insert

Screws

Insert

Paddle

CoverCover Screws

Mounting

Posts

WARNING

This product can expose

you to lead which is

known to the state of

California to cause cancer

and birth defects or other

reproductive harm. For

more information go to

www.P65warnings.ca.gov.

08/2018

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

Push/Pull (HPSK) Paddle Trim

Installation Instructions

ML2000 Series Mortise Lock

permission of Corbin Russwin, Inc. is prohibited.

MAKE SURE CATCH PLATE IS

EVEN W/ TOP SURFACE

GOOD BAD

WARNING:

LOCK-IN CAN

OCCUR IF LATCH

IS NOTPROPERLY

INSTALLED

4. Push in latch while holding

screwdriver behind latch tail.

(Figure 3)

5. Rotate lock front to match bevel of door as

shown. (Figure 5)

1Mortise Lock Handing Instructions

Figure 1

Figure 2

Figure 3

RED Locking Screw

Catch Plate

LOCK HANDING

IS CRITICAL TO

ENSURE LOCK

FUNCTIONS

PROPERLY

Figure 4

1. Move the Red locking screw to side of lockbody

being locked.

2. Push in latch then depress catch plate with

screwdriver. (Figure 1)

3. Pull latch out of lock-body and turn latch over.

(Figure 2)

Figure 5

NOTE:

PUSH IN LATCH UNTIL CATCH

PLATE IS NO LONGER DEPRESSED.

(FIGURE 4)

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

Push/Pull (HPSK) Paddle Trim

ML2000 Series Mortise Lock

Installation Instructions

permission of Corbin Russwin, Inc. is prohibited.

Turn-Piece Door

Marker Template

Inside

of Door

Turn-Piece Door

Marker Template

Outside

of Door

2 Mortise Lock Door Preparation & Installation

Figure 6

Important: Be sure to hand the lockbody

before installing. See Section 1.

1. Insert mortise lock into door and fully

tighten 1" lock mounting combination

screws. (Figure 6)

2. TURN-PIECE FUNCTIONS ONLY:

Insert turn-piece door marker spindle into

lockbody on inside of door.

3. TURN-PIECE FUNCTIONS ONLY:

Slide turn-piece door marker over spindle.

4. TURN-PIECE FUNCTIONS ONLY:

Mark three holes for turn-piece. (Figure 8)

5. COIN-TURN FUNCTIONS ONLY:

Insert turn-piece marker spindle into

lockbody on outside of door.

6. COIN-TURN FUNCTIONS ONLY:

Slide turn-piece door marker template over

spindle.

7. COIN-TURN FUNCTIONS ONLY:

Mark two holes for coin-turn. (Figure 9)

NOTE:

USE SQUARE SIDE OF DOOR MARKER SPINDLE.

(FIGURE 7)

NOTE:

USE SQUARE SIDE OF DOOR MARKER SPINDLE.

(FIGURE 7)

Figure 7

Figure 8

Square

Side

Figure 9

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

Push/Pull (HPSK) Paddle Trim

Installation Instructions

ML2000 Series Mortise Lock

permission of Corbin Russwin, Inc. is prohibited.

Ø.290" Ø3/8"

Ø3/8"

Ø1/8" Ø1/8"

Figure 10

8. Remove lockbody from door.

9. TURN-PIECE FUNCTIONS ONLY:

Drill one middle hole (.290") and two outer holes

(3/8") halfway through door. (Figure 10)

10. COIN-TURN FUNCTIONS ONLY:

Drill two holes (1/8") halfway through door.

(Figure 11)

11. TURN-PIECE FUNCTIONS ONLY:

Install turn-piece thru-bolt plate using truss

head screw. (Leave screw slightly loose.)

(Figure 12)

12. Insert mortise lockbody into door and loosely

tighten 1" lock mounting combination screws.

NOTE:

MAKE SURE LOCK IS UNLOCKED. (FIGURE 13)

Figure 11

MAKE SURE LOCK

IS UNLOCKED

Un-Locked

Locked

Narrower Hole

Wider Hole

Strike Lip

* Strikes for Non-Deadbolt functions

only have narrower hole.

Figure 13

Figure 12

NOTE:

THE THRU-BOLT PLATE IS INSTALLED INSIDE

THE DOOR POCKET.

2Mortise Lock Door Preparation & Installation

Thru-bolt

Plate

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

Push/Pull (HPSK) Paddle Trim

ML2000 Series Mortise Lock

Installation Instructions

permission of Corbin Russwin, Inc. is prohibited.

Cylinder

Set Screw

Narrower Hole

Wider Hole

Strike Lip

3HPSK Trim Installation

Figure 14

Figure 15

1. Install strike using 3/4" strike mounting screws.

2. CYLINDER FUNCTIONS ONLY:

Slide cylinder(s) through spring and collar,

threading into lockbody until cylinder face is

ﬂush with collar. (Figure 15)

3. CYLINDER FUNCTIONS ONLY:

Install cylinder set screw(s). (Figure 17)

4. Fully tighten lock mounting screws.

5. Align cam and chassis as shown based on

desired paddle orientation. (Figure 18)

NOTE:

STRIKE MUST BE ORIENTED WITH

NARROWER HOLE ON LOWER HALF OF

STRIKE AND STRIKE LIP TOWARDS PULL

SIDE OF DOOR. (FIGURE 14)

NOTE:

PULL KEY SLIGHTLY OUT OF CYLINDER TO HELP

THREAD INTO LOCKBODY.

NOTE:

CYLINDER MUST BE ORIENTED CORRECTLY.

(FIGURE 16)

NOTE: Key and

cylinder must be

rotated as shown

Correct Incorrect

ASSA ABLO Y

ASSA ABLOY

Figure 16

Figure 17

Vertical Paddle

CAM

Vertical

Paddle UP

Vertical

Paddle DOWN

Horizontal Paddle

Mounting Post Location

=OR

Mounting Post Location

Mounting Post

Location

CAM

Figure 18

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

Push/Pull (HPSK) Paddle Trim

Installation Instructions

ML2000 Series Mortise Lock

permission of Corbin Russwin, Inc. is prohibited.

CAM

Spindle NOT Engaged

Spindle Engaged

OUTSIDE INSIDE

Mounting

Posts

Mounting

Screws

3HPSK Trim Installation

6. Insert mounting posts through outside

chassis then install trim on both sides of

door using mounting screws (loosely tighten

mounting screws). Make sure spindle is fully

engaged in lockbody. (Figure 19)

Figure 19

Figure 20

Figure 21

7. Fully tighten 1" lock mounting combination

screws then level out chassis using a

square. (Figure 20)

8. Fully tighten mounting post screws.

9. Rotate cam by hand to make sure trim is not

binding - latch must project freely when cam

is released. If trim binds loosen mounting

screws and re-align trim. (Figure 21)

10. Install surface mount screws. (Figure 22)

For Wood Door:

- Drill two (2) 7/64" holes for surface mount

screws

- Install surface mount wood screws

For Metal Door:

- Drill and tap door for #8-32 screws

- Install surface mount machine screws

NOTE:

USE SQUARE TO LEVEL OUT CHASSIS

Figure 22

Surface Mount

Screw Holes

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

Push/Pull (HPSK) Paddle Trim

ML2000 Series Mortise Lock

Installation Instructions

permission of Corbin Russwin, Inc. is prohibited.

Figure 20

Figure 22

3HPSK Trim Installation

11. Install insert on paddle based on desired paddle

orientation. (Figure 23)

Figure 26

Figure 24

CAUTION:

- SCREWS MUST BE POSITIONED BEHIND

PADDLE TO WORK PROPERLY

- Cover will be very difﬁcult to remove if

forced on backwards Figure 25

12. Attach paddle to chassis by aligning paddle

as shown then insert axle through pivot hole

in chassis. (Figure 24)

13. Install cover using 5/16" oval head mounting

screws. (Figure 25)

14. Install scalp using 3/16" Flat Head Screws.

(Figure 26)

Vertical Paddle UP Vertical Paddle DOWN

Horizontal Paddle

Paddle Insert Paddle Insert

Figure 23

NOTE:

COVER HOOKS UNDERNEATH CHASSIS

ON SIDE OPPOSITE MOUNTING SCREWS SCALP

For installation assistance contact Corbin Russwin

1-888-607-5703 • [email protected]

FM339 10/18

permission of Corbin Russwin, Inc. is prohibited.

Patent pending and/or patent: www.assaabloydss.com/patents

Corbin Russwin

225 Episcopal Road

Berlin, CT 06037

Phone: 800-543-3658

Fax: 800-447-6714

corbinrusswin.com

4 Turn-Piece Installation

1. Install turn-piece loosely using two (2) turn-

piece mounting screws. (Figure 27)

2. Adjust location of turn-piece on door until

turn-piece rotates easily, then fully tighten

mounting screws.

Figure 28

Figure 29

NOTE:

MAKE SURE LOCK IS UNLOCKED AND

TURN-PIECE IS ROTATED TOWARDS

LATCH. (FIGURE 28)

MAKE SURE LOCK

IS UNLOCKED

Un-Locked

Locked

Narrower Hole

Wider Hole

Strike Lip

* Strikes for Non-Deadbolt functions

only have narrower hole.

5 Coin-Turn Installation

Figure 27

1. Install coin-turn using two surface mount

screws. (Figure 29)

Table of contents

Other Assa Abloy Lock manuals

Assa Abloy

Assa Abloy effeff EX118R User manual

Assa Abloy

Assa Abloy Sargent 6500 Instruction Manual

Assa Abloy

Assa Abloy Corbin Russwin IN100 User manual

Assa Abloy

Assa Abloy EMTEK CF Mechanism User manual

Assa Abloy

Assa Abloy Yale P113 User manual

Assa Abloy

Assa Abloy Abloy EL590 User manual

Assa Abloy

Assa Abloy Sargent Passport 1000 PG User manual

Assa Abloy

Assa Abloy Yale YM Series User manual

Assa Abloy

Assa Abloy Cabinet Lock Series User manual

Assa Abloy

Assa Abloy 836S User manual

Assa Abloy

Assa Abloy 8800 Series User manual

Assa Abloy

Assa Abloy EMTEK A User manual

Assa Abloy

Assa Abloy Corbin Russwin BLSS ML2000 Series User manual

Assa Abloy

Assa Abloy SECURITRON MORTISE UNLATCH MUNL-12 User manual

Assa Abloy

Assa Abloy Yale YDM7116A User manual

Assa Abloy

Assa Abloy Yale Y-LL67AP User manual

Assa Abloy

Assa Abloy HES KS100 Aperio Assembly instructions

Assa Abloy

Assa Abloy YRD256 User manual

Assa Abloy

Assa Abloy Yale Real Living Assure Lock SL Series Technical specifications

Assa Abloy

Assa Abloy Yale Real Living B1L Z-Wave Technical specifications

Assa Abloy

Assa Abloy EL410 User manual

Assa Abloy

Assa Abloy Code Handle Window User manual

Assa Abloy

Assa Abloy Securitron EPT-SC Series User manual

Assa Abloy

Assa Abloy KESO KEK i-handle S User guide

Popular Lock manuals by other brands

Magic

Magic 105 manual

Gantner

Gantner GAT NET.Lock 7020 System Installation, configuration & operation

Wittkopp

Wittkopp Insys 7202 manual

Dorma

Dorma Studio Classic Installation instruction

Securam

Securam ECSL-601 quick start guide

Sudhaus

Sudhaus 3003 operating manual

Safety 1st

Safety 1st 48517 user guide

Pado

Pado FDS-10 user manual

Esco

Esco systeQ Series installation instructions

COMPX

COMPX National D8951 instruction sheet

secureo

secureo Key Box instruction manual

Stock Loks

Stock Loks C8713 instruction sheet

COMPX

COMPX 1T-058 Information

Auslock

Auslock T11 user manual

ELCOM

ELCOM 7205 Operating instruction

Stealth SAFES

Stealth SAFES ShadowVault Instructions & Troubleshooting

Knox

Knox KeySecure 5 Admin & user guide

Kwikset

Kwikset 48334/01 Quick installation guide
