FriendlyNET®FS4124R

24-Port 10/100 Fast Ethernet Switch

FS4116R FS4124R

10/100 Fast Ethernet Ports 16 24

Plug-and-Play Operation Yes Yes

Chassis 10.5” Metal 10.5” Metal

Recommended Network Size Up to 1024 Up to 4,000

Rackmountable Yes (1U high) Yes (1U high)

Internal Power Supply Yes Yes

Asante 100/100 Switch

High-speed 10/100 Network Friendly Switching for

Either Desktop or Rackmount Applications

Need to connect more users to your small oce or work group network ? Asante’s

FS4124R 24-port Fast Ethernet Switch delivers outstanding performance in a compact,

exible desktop or rackmountable form factor.

Each RJ-45 jack provides up to 200 Mpbs (full duplex) speed of dedicated bandwidth per

connection. FS4124R is a non-blocking, wire-speed switch with store and forward

technology . It’s ideal for quickly moving large emails and other les.

To simplify network expansion, Asante’s Auto-Uplink™ technology lets you directly

connect to another industry-standard 10/100 switch, router, or hub. There is no any

needs to congure uplink, ports or use special crossover cables. It is truly Plug and Play.

Rugged metal chassis with internal, auto-ranging power supply is designed

for continuous operation.

Compact desktop 10.5” design can also be mounted to standard 19” racks using

rackmount kit (included)

Free telephone technical support for connecting to Mac OS, Linux and Windows

clients and servers.

Free telephone technical support for connecting to Mac OS, Linux and Windows

clients and servers.

A Communication Division of UIC Corporation

asante.com/products/switches 2

TECHNICAL SPECIFICATIONS

Overview

Fast Ethernet: 24 x 10/100BaseTX Fast Ethernet portswithAuto-Uplink: RJ-45 shielded connectors

Configuration: IEEEAuto Negotiation (sets 10/100 Mbps speed and half/full duplex)

Status Indicators

System: Power

Per Port: 2 LEDs. Link (solid)/activity (blink). 100 Mbps (on)/10 Mbps (off)

Performance

Efficiency: Non-blocking, Fast Ethernet switching

SwitchArchitecture: Single-chip design with on-board frame buffers

Forwarding MAC Table: 4K addresses with 128-entry CAM

On-Chip Buffer: 192 KBytes

Physical

Dimensions (W x D x H): 10.5 x 6.8 x 1.7 inches (267x 175 x 44 mm)

Weight: 2.8 lbs (1.3 Kg)

Power: Internal, auto-switching, 100-240 VAC, 50-60 Hz

Operating Temperature: 32º to 104º F (0º to 40º C)

Relative Humidity: 10% to 90%, non-condensing

Standards Compliance

Network: IEEE 802.3u Fast Ethernet over 2 pairs of UTPCategory 5 (100BaseTX)

IEEE 802.3 Ethernet over 2 pairs of UTP Category 3 (10BaseT)

Network Protocols: TCP/IP, CSMA/CAwithACK

Emissions: FCC ClassA, CE Mark

Safety: UL, cUL, CE Safety

Support

Technical Support: 24-hour support via weband ftp. 2-year email and telephone support

Product Warranty: 2-year product warranty covers defects in manufacturing and workmanship

ORDERING INFORMATION noitpircseD*emaNledoM tiktnuomkcarhtiwhctiwstenrehtEtsaF001/01tro24 - pR2414SF

* For international part numbers, please refer to theAsanté price list.

FS4124R (99-00709) 050708 •FS4124R_DS

47709 Fremont Blvd, Fremont, CA 94538 USA· Phone 408.435.8388 · Website www.asante.com

All other names may be trademarks or registered trademarks of their respective owners. Specifications subject to change without prior notice.

A Communication Division of UIC Corporation
