Article LENIA User manual

Assembly Instructions

LENIA

6 Drawer Double Dresser

VERSION 1.3

Page 2 of 4

ASSEMBLY INSTRUCTIONS

Read these instructions carefully and keep for future

reference. Refer to parts inventory for guidance, and

ensure you have all pieces before starting.

When assembling, place all parts on a soft, clean, and ﬂat

surface such as a carpet to prevent scratches.

team is always here to help. Call us at 1.888.746.3455

during business hours, email [email protected] or chat

live at article.com.

LENIA 6 Drawer Double Dresser

20 min

PARTS INVENTORY

ID DESCRIPTION QTY

LEFT LEG 1

RIGHT LEG 1

CROSSBAR 1

FELT PAD 4

COMPRESSION FITTING

ANCHOR 2

M8 × 8MM SCREW 2

M8 × 15MM BOLT 8

ALLEN KEY 1

TIME# OFPEOPLE DIFFICULTY

REQUIRED TOOL

ANTI-TIP

Installation Required

Page 3 of 4

× 4

× 2

× 4

LENIA 6 Drawer Double Dresser

Page 4 of 4

LENIA 6 Drawer Double Dresser

× 2

× 8

Crossbar is situated at

the front side of the dresser.

ANTI-TIPInstallationPage 1of 3

20 min

TIME

REQUIRED TOOL

8MM / 5/16" DRILL BIT

# OFPEOPLE DIFFICULTY

To prevent injury and property damage from unexpected

tipping of furniture, we highly recommend installation of

the anti-tip kit included with this product.

1010 Raymur Ave.

Vancouver, BC V6A 3T2

Children have died from furniture tipover.

To reduce the risk of furniture tipover:

• ALWAYS install tipover restraint provided.

• NEVER put a TV on this product.

• NEVER allow children to stand, climb or hang

on drawers, doors, or shelves.

• NEVER open more than one drawer at a time.

• Place heaviest items in the lower drawers.

ANTI-TIP RESTRAINT INSTALLATION

WARNING!

PARTS INVENTORY

ID DESCRIPTION QTY

M8 × 51MM PLUG 4

MOUNTINGPLATE 4

NYLON STRAP 2

M4 × 17MM SCREW 4

• Determine where the piece is to be placed

and mark location on the wall for the

mounting bracket screw holes. They should

be placed approximately below the top on

the back piece of furniture.

• Drill the hole and use the appropriate

wall plug that is suitable for your walls

composition.

• Attach the mounting bracket vertically to the

wall using appropriate fastener, through the

holes in the bracket and 2 wall plugs that

are suitable to your walland then tighten

securely.

• Next using the short screws attach the

2nd bracket to the back of the piece of

furniture’s top.

• Lace the nylon strap down through the

brackets. Slide the thin end of the strap

through the receivnhg end on the nylon

strap. Pull to tighten the piece of furniture

snug against the wall.

Attaching furniture to wall

with anti-tip kits:

M6 × 70MM SCREW 4

ANTI-TIP Installation Page of 3

× 4 × 4

Drill holes in wall using

8mm / 5/16"drill bit.

Before drilling check wall for

hidden pipes and cables.

If ﬁxing to wood make sure

that is is not chipboard as

screws can easily pull away

from the core structure.

Use an appropriate wall

plug provided you are sure

your wall is sound.

Special toggle wall

plugs are needed.

Seek expert advice.

Wood Brick or Masonry Cavity Wall

× 4

Page 3 of 3

ANTI-TIP Installation

CARE INSTRUCTIONS :

1. Hardware may loosen overtime.

Periodically check that all connections

are tight and re-tighten as necessary.

2. Wipe with a soft, dry cloth. To protect

ﬁnish, avoid the use of chemicals and

household cleaner.

Pull strap down until it snap-locks.

× 2

LENIA Soft Close Drawer

Adjustment InstructionsPage 1 of 3

FIXED A CROOKED DRAWER

SOFT CLOSING DRAWERS

ADJUSTMENT INSTRUCTIONS

Structural integrity is warranted only if all

fasteners are properly installed & tightened,

and the bed is moved only per instructions.

×2

Adjust levelers on either side of drawer

as needed to straighten drawer.

LENIA Soft Close Drawer

Adjustment InstructionsPage 2 of 3

REMOVE DRAWER

×2

To unlock.

LENIA Soft Close Drawer

Adjustment Instructions Page 3 of 3

INSTALL DRAWER

×2

To lock.

×2
