AQUATECH Scout & Shadow User manual
Scout & Shadow Sound Blimp
Instruction Manual
FEATURES
Main O-rings - located on the front before
the “Tube” threads and the back surface
of the Shadow & Scout. These are used to
help seal and prevent the camera sound
from exiting the main openings.
Two-Button switch - allows you to have
focus on the bottom button and shutter
release on the top button. This is a eld
replaceable part.You can simply slide it
up and down. Do NOT pull on the rubber
buttons.
Quick Control Dial - allows you to review
your images and control some of your
cameras functions.
Easy Access Single Action Latch - allows
you to get to your controls fast and quietly.
Monopod / Tripod Insert - a 3/8 insert has
been installed. Located in the bottom of
your Shadow for easy use with Straps /
pods.
Acoustic Sound Foam – secures and locates
your camera as well as suppresses the
sound of your camera shutter.
Camera Cable Release - plugs into your
camera & the inside circuit board. Supplied
with a Stereo Minijack at one end and the
camera cable release at the other end.This
is also a eld replaceable part.
Clear LCD screen - allows you to view
images when required.
O-Ring grease – a small amount should be
applied to the threads.This will allow your
Tube to spin easier.
Pocket Wizard -With the removal of your
Two Button Switch, a Pocket Wizard
(which plugs in like a head phone jack)
can be installed allowing you to wirelessly
trigger your camera.This is set up only for
receiving a signal. Contact AquaTech for
transmitting a signal.
IMPORTANT: Our Shadow & Scout
Sound Blimps are NOT waterproof
and should never be used in or
around the water.
For any technical questions please contact
Instructions
Thank you for purchasing the AquaTech
“Scout / Shadow” Sound Blimp.
For ease of use please remove all camera
straps before loading camera into blimp.
Carefully connect the electronic cable
release into your cameras cable release
jack. The cable release is eld replaceable
and this part is sold via AquaTech directly.
Place your camera into the blimp without
a lens and secure the rear section of the
blimp with the quick action latch.
Attach your lens to your camera body and
test camera functions to ensure cable
release and rear controls are functioning
as desired.
Instructions
The front two button switch will allow you
to have focus on the bottom button and
shutter release on the top button. To lock
focus you must hold the bottom button
and have your camera’s focusing selection
set accordingly. This shutter button is
eld replaceable and is sold via AquaTech
directly.
To function properly, your Sound Blimp
requires the use of a Lens Tube that
threads to the front of the main body. Each
Lens Tube is specic to the type of lens
you are using.To attach, simply line up
the threads and screw the Lens Tube in a
clockwise direction.
The Lens Tube will thread on and after a
few turns will disengage the thread and
become looser. At this point, your Blimp
Lens Tube will move freely and will allow
you to rotate and engage your lens zoom
gear where applicable.
To remove your Tube, simply pull and spin
outward on your Tube until you feel the
Tube threads engage with the Sound Blimp
threads.You can then unscrew until the
Tube is fully removed.
Please note: sound foam is very weak as
it cannot be dense like other foams. The
more dense usually the more sound can
vibrate and exit the unit. We make the area
tight around the zoom area so the gear
can engage.The only way to avoid this
breaking down is to limit the times you
enter the lens into the tube and when you
do enter you MUST be gentle.
