AMX UPC20 Plus Parts list manual

Operation/Reference Guide

Control System Accessories

UPC20+

Universal Power Controller

Last Revised: 09/12/2007

AMX Limited Warranty and Disclaimer

AMX Corporation warrants its products to be free of defects in material and workmanship under normal use for

three (3) years from the date of purchase from AMX Corporation, with the following exceptions:

• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch

overlay components that are warranted for a period of one (1) year.

• Disk drive mechanisms, pan/tilt heads, power supplies, MX Series products, and KC Series products are

warranted for a period of one (1) year.

• Unless otherwise specified, OEM and custom products are warranted for a period of one (1) year.

• Software is warranted for a period of ninety (90) days.

• Batteries and incandescent lamps are not covered under the warranty.

This warranty extends only to products purchased directly from AMX Corporation or an Authorized AMX Dealer.

AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform. This

includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not liable

for any claim made by a third party or by an AMX Dealer for a third party.

This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim

(including negligence and strict product liability), a contract claim, or any other claim. This limitation of

liability cannot be waived or amended by any person. This limitation of liability will be effective even if AMX

Corporation or an authorized representative of AMX Corporation has been advised of the possibility of any such dam-

ages. This limitation of liability, however, will not apply to claims for personal injury.

Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or

exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of

the Limited Warranty may not apply. This Limited Warranty gives the owner specific legal rights. The owner may also

have other rights that vary from state to state. The owner is advised to consult applicable state laws for full

determination of rights.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX CORPORATION MAKES NO

OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX CORPORATION

EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY

IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS

LIMITED WARRANTY.

UPC20+ Wiring Requirements

In the United States, the UPC20+ must be wired by an authorized electrician in

accordance with the National Electrical Code, ANSI/NFPA 70-1987, as well as all

local codes.

In the European community, the UPC20+ unit must be wired by an authorized elec-

trician in accordance with all applicable European codes.

A readily accessible disconnect device shall be incorporated into the fixed wiring.

An insulated earthing conductor that is identical in size, insulation material and

thickness to be earthed and unearthed branch circuit supply conductors, except that

it is green with or without one or more yellow stripes, is to be installed as part of

the branch circuit which supplies the unit or system. The earthing conductor

described is to be connected to earth at the service equipment, or supplied by a

separately derived system, at the supply transformer or motor generator set.

Table of Contents

UPC20+ Universal Power Controller

Table of Contents

UPC20+ Wiring Requirements ............................................................................3

Product Information ...........................................................................................1

Specifications .......................................................................................................... 3

Control Options Modes ............................................................................................ 4

Motor Control mode ....................................................................................................... 4

Power Control mode....................................................................................................... 5

Remote Sensor Control mode ......................................................................................... 5

Channel codes (Remote Sensor mode)............................................................................ 6

Installation ..........................................................................................................7

P1 Terminal Connections .......................................................................................... 7

P2 Terminal Connections .......................................................................................... 7

Control Mode ........................................................................................................... 7

High Voltage Wiring Options.................................................................................. 10

Single circuit 120/240 VAC ........................................................................................... 10

Dual circuit 120/240 VAC.............................................................................................. 10

Dual circuit 277 VAC ..................................................................................................... 11

Wiring The UPC20+ to Either The IRX-DM+ Or IRX-SM+ ....................................... 11

Wireless IR Sensor Connection ............................................................................... 11

Installing the UPC20+ ............................................................................................. 12

ii UPC20+ Universal Power Controller

Table of Contents

Product Information

UPC20+ Universal Power Controller

Product Information

The UPC20+ Universal Power Control is a dual 20 Amp AC power and motor controller designed for

conduit installation. The UPC20+ is housed in a compact metal wall-mount enclosure and is

configurable for a wide variety of power and motor control modes. Low voltage contact-closures, open

collector inputs or serial data from an AMX IR receiver enable control by simple wall panels, remote

systems, or hand-held transmitters. A test switch with an LED indicator for each relay is provided for

local control and status indication.

Using Motor Control mode, the UPC20+ output alternates between two relays, providing a brief pause

in-between relay contacts, to protect the motor. A timing adjustment potentiometer is user adjustable for

automatic release of the relays. (The range is 0 to 90 seconds). 1-, 2-, and 3- button control modes are

selectable.

In Power Control mode, the UPC20+ provides power control for two independent circuits with a

combined total load of 20 Amps. Single-button momentary/latching and 2-button latching modes are

selectable.

 Momentary Power Relay contacts are closed only as long as a closure from input to

common is maintained.

 Latching Power Relay contacts are toggled (from open to closed and closed to open) each

time a closure from input to common is momentarily pulsed.

All functions and capabilities of the UPC20+ (including information on high voltage wiring, low voltage

wiring, and DIP switch settings) are described on a sticker installed inside the enclosure. FIG. 1 shows

the UPC20+ (inside view).

The UPC20+ will work the NXC-I/O10 input/output control card.

Product Information

2UPC20+ Universal Power Controller

FIG. 1 UPC20+

75°C INSULATION

USE COPPER ONLY

DISCONNECT SWITCH MAY BE REQUIRED TO DE-ENERGIZE

RISK OF ELECTRIC SHOCK - MORE THAN ONE

VOLTAGE PRIOR

POWER TO UNIT

TO APPLYING

IMPORTANT

SWITCH MUST

MATCH INPUT

TO CIRCUIT BD

THE EQUIPMENT BEFORE SERVICING

ELECTRONICS

GND

CAUTION

Richardson, Texas

800-222-0193

UPC20+

469-624-8000

CLASS 2 CIRCUIT ONLY

RECEIVER

PART # 91-0672-01, REV F

+12V

JP1

SEE INSIDE COVER FOR DETAILED WIRING

NOTE: NO HIGH VOLTAGE THIS CONNECTION

AND DIP SWITCH INFORMATION

IN 4

CONTROL

INPUT INPUTS

GND

DATA

GND

IN 1

IN 2

IN 3

CONTACT

+12

REMOTE

IND.CONT.EQ.

LISTED

68WF

High voltage

terminal and

wiring arrangement

label

Spade terminal

block P1

Power and Motor

control relays

PB1 PB2

Test switches with

status LEDs

Motor Time Delay

Potentiometer

Jumper JP1

Low voltage

terminal and wiring

arrangement label

Low voltage

and IR remote

control

DIP switch

controls mode

and function

Power switch

(115/230 VAC)

High voltage wiring

(120/240, 277 VAC)

connections

The UPC+ cover contains information on high voltage wiring, low voltage wiring, and

DIP switch settings.

Product Information

UPC20+ Universal Power Controller

Specifications

UPC20+ Specifications

Power Self-powered when used with 110/220 VAC

Power input (for control board) 120/240V ~, 50-60 Hz, 0.05/0.025A

-or-

12 VDC, 0.2A max

Power output per relay • 20A @ 120/240V ~, 50-60 Hz (RESISTIVE LOAD)

• 6A @ 277V ~, 50-60 Hz (FLUORESCENT BALLAST)

• 1 HP @ 120V ~, 50-60 Hz (INDUCTIVE LOAD)

• 2 HP @ 240V ~, 50-60 Hz (INDUCTIVE LOAD)

Total Current through both relays CAN NOT exceed 20 amp.

Maximum operating ambient

temperature

55°C

Approvals UL / C-UL / CE

Includes • 1-, 2-, and 3-button logic modes

• Local test switches with status LEDs

• 120, 240, and 277 VAC control capability

Inputs • 4 closure inputs, operation defined by mode.

• One IR remote sensor input.

• Motor Control mode alternates between the timed operation of the two

power relays.

• Power Control mode allows independent control of both power relays.

Control Ports Two 2400 W power relays. Total combined current through both relays is 20

Amps.

Input Power Switch (S1) • Set this switch according to the high voltage wiring that will be connected

to terminals 5 and 6 on P1. Refer to theP1 Terminal Connections section

on page 7.

• Set switch S1 to the line input voltage value used before applying power to

the UPC20+.

High Voltage Terminal Block (P1) High voltage input and output wiring for motor or power control.

Low voltage and Control

Terminal Block (P2)

Contact closure, open-collector or CMOS logic level remote control wiring.

Inputs 5 - 8 are referenced to the common connection at pin 4.

Jumper JP1 Sets control mode of the unit to contact closure or remote sensor serial

data.

Test Switches (PB1 and PB2) Provides local operation of relays K1 and K2 for testing power circuits or

motors connected to the relay terminals. An LED indicates relay power

applied.

Motor Time Delay Potentiometer

(R8)

Only used in motor control modes. User adjusted for setting relay release

time between 0 and 90 seconds.

DIP Switch (S2) Provides selection of control mode options. See Motor Control Mode DIP

Switch S2 Positions table on page 4 and Control Input Wiring to Connector

P2 Terminals table on page 4 for control mode settings.

Enclosure Metal with black matte finish, knockouts for conduit.

Dimension (HWD) • 8.5" (10.5" including flange) x 4.5" x 2.2"

• (220 mm (270 including flange) x 110 mm x 60 mm)

Weight 3.0 lbs. (1.4 kg) with flange

Options 12 VDC power supply (for 277 VAC applications)

Product Information

4UPC20+ Universal Power Controller

Control Options Modes

FIG. 2 UPC20+ inoperative mode warning label

Motor Control mode

The table list options and connections for motor control. DIP switch settings provide 1, 2 or 3 button

remote control contact arrangements. This mode is typically used for screen and drape motor control.

In motor control mode, only one power relay (motor) can be energized at a time. When switching from

one direction to another, the first motor is automatically turned off and a half-second delay is inserted

before the other motor will turn on.

Once a motor is turned on, it will automatically be turned off after the amount of time determined by the

motor time delay potentiometer, R8. Delay time can range from 0 to 90 seconds. It is typically set to

allow direction limit switches to operate, or to reach the desired position.

 Single Button Mode operates with one pushbutton in a sequence: Up, Stop, Down, Stop and

so on for each successive button press.

 Two/Three Button Mode operates with two pushbuttons, one for Up and one for Down.

 Momentary On/Off operates only when the button is pressed.

ATTENTION INSTALLER

FACTORY SET TO INOPERATIVE MODE

(UNIT WILL NOT WORK UNTIL DIP SWITCHES ARE SET)

SEE CHART ON LID TO SET

DIP SWITCHES FOR ACTIVE MODE

If UPC20+ is powered up when changes are made to Dip Switch settings, then power

must be cycled before changes can take effect.

Motor Control Mode DIP Switch S2 Positions

1 2 3 4 Control Mode

On On Off On Single button

Off Off Off On 2-button

Off On Off On Momentary On/Off

Control Input Wiring to Connector P2 Terminals

4 5 6 7 8 Control Mode

Common Up Down Stop N/A Two, three button

Common Up/Stop/Down N/A N/A N/A Single button

Other manuals for UPC20 Plus

This manual suits for next models

Table of contents

Other AMX Controllers manuals

AMX

AMX NetLinx NI-2000 User instructions

AMX

AMX NetLinx Integrated Controller NI-3100 User manual

AMX

AMX SX16+ Owner's manual

AMX

AMX NXC-VAI4 User manual

AMX

AMX NetLinx Integrated Controllers NXI-x000... Operating and maintenance manual

AMX

AMX FG1090-170 User manual

AMX

AMX AXB-PT15 User manual

AMX

AMX NetLinx Integrated Controller NI-3100 User instructions

AMX

AMX AXB-F117 Stealth 1 User manual

AMX

AMX NetLinx Integrated Controller NI-4100 User instructions

AMX

AMX Axcent3 pro User manual

AMX

AMX NetLinx Integrated Controller NI-700 User manual

AMX

AMX AXP-PLV Guide

AMX

AMX Power Controller PC1 User manual

AMX

AMX Tango DAS-T0804-SIG User manual

AMX

AMX NXC-COM2 Guide

AMX

AMX AXF-MINI User manual

AMX

AMX NetLinx Integrated Controller NI-900 User manual

AMX

AMX AXC-232 User manual

AMX

AMX Control Card RDC-DC Assembly instructions

AMX

AMX NetLinx NI-3101-SIG Parts list manual

AMX

AMX EXP-PT1370 User manual

AMX

AMX NXA-WAPZD1100 User manual

AMX

AMX NetLinx Integrated NXI Parts list manual

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

ABB

ABB ACS580-01 drives Hardware manual

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual
