Ameriwood HOME 8077333 User manual

8077333

3DoorWardrobe

B34807733300

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.systembuild.com

AssemblyDifficultyMeter

Easy Tough

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

SecureYourFurniture

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

systembuild.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitsystembuild.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:2HOURS

3

systembuild.com

BeforeYouStart



Quick

Tip

Assembly



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

systembuild.com

BoardIdentification

Notactualsize

Thispartispaperboard

construction.Itisnotmade

fromwood,butisrequiredfor

theassemblyofyourunit.

LeftPanel

38077333010

RightPanel

38077333020

Partition

38077333030

Bottom

38077333050

Top

38077333040

Shelf

38077333060

SmallShelf

38077333070

Adjustableshelf

38077333080

kick

38077333090

door

38077333100

BackPanel

K72260000

ABC

FG H I

5

systembuild.com

BoardIdentification

Notactualsize

Thispartispaperboard

construction.Itisnotmade

fromwood,butisrequiredfor

theassemblyofyourunit.

6

systembuild.com

PartList

ActualSize

(x24)

#A23030

confirmatscrew

(x16)

#A21660

wooddowel

(x4)

#A53510

anglebracket

(x8)

#A12120

#8x7/16"panhead

(x2)

#A11080

#6x7/16"flathead

(x2)

#A82020

rodbracket

(x44)

#A21110

nail

(x8)

#A80250

shelfsupport

(x20)

#A24039

screwheadcap

(x6)

#A89210

pad

(x6)

#A17400

8‐32x7/8"bolt

7

systembuild.com

PartList

NotActualSize

(x9)

#A65615

hinge

(x3)

#A50415

handle

(x1)

#A84050

safetybracketkit

(x1)

#I20410

wardroberod

12 14a

14b

14c

14d

8

systembuild.com

STEP1

(x3)

#A65615

(x1)

#A82020

(x1)

#A11080

12 Loosenscrewandseparate

hingeplatefromhingearm.

finishededge

9

systembuild.com

STEP2

10 12

(x1)

#A11080

Loosenscrewandseparate

hingeplatefromhingearm.

finishededge

(x1)

#A82020

(x3)

#A65615

(x4)

#A21660

Notice,thewooddowels(2)willinsertintothelargerendholes.

10

systembuild.com

STEP3

(x3)

#A65615

Loosenscrewandseparate

hingeplatefromhingearm.

finishededge
