Amano WPR900-1-0-AC Series User manual
MODEL NUMBER:
WPR900-1-0-AC-XX WMR900-1-0-AC-XX
WPK900-1-0-AC-XX WMK900-1-0-AC-XX
WDP900-1-0-AC-XX WKM900-1-0-AC-XX
WIEGAND READERS
Wiegand 125 kHz Passive Proximity Readers
INSTALLATION MANUAL
SPECIFICATIONS
Read Capability............................
Slim Tags, Omega Tags, Impro Trinary Tags
and HID 125 kHz Tags.
NOTE: HID is a registered trademark of
HID Global Corporation (an ASSA
ABLOY Group Brand).
Working Environment
WPR900 and WPK900..................
Designed to work in indoor or outdoor
environments similar to IP53.
NOTE: These Readers are RoHS
compliant and do not contain any
UV stabilizer.
WMR900 and WMK900.................
Designed to work in harsh (industrial) indoor or
outdoor environments similar to IP53.
WDP900........................................
The IP rating for this Wiegand Reader is
dependant on the user supplied housing. The
rating of the Reader on its own is similar to
IP35.
NOTE: These Readers are RoHS
compliant and do not contain any
UV stabilizer.
WKM900........................................
Designed to work in an indoor or outdoor
environment similar to IP42.
NOTE: These Readers are RoHS
compliant and do not contain any
UV stabilizer.
Input Voltage Rating....................
5 V DC to 16 V DC, polarity sensitive.
WPR300-0-0-AC-04
March 2009
Page 2
Power Requirements
Current (mA)
Power (W)
Supply Voltage 5 V DC all
Indicators on...........................
50
0.25
Supply Voltage 12 V DC all
Indicators on...........................
50
0.60
Wiegand Bus
Electrical Interface..................
„0‟ and „1‟ Data streams.
Data Format...........................
Tag information: 44-bit or 26-bit Wiegand.
Key information: 26-bit Wiegand only.
Inputs
Quantity..................................
4.
Type.......................................
Dry Contact.
Function.................................
Operation of the Buzzer, LED and Scanner
Inhibit.
Buzzer...........................................
4 kHz piezo-electric single volume, single tone.
Status Indicators
Status LED.............................
Tri-colored Red, Green or Amber (Default)
(externally visible).
WPK900, WMK900 and WKM900 models only
Keypad
WPK900 and WMK900.........
12 Alphanumeric keys.
WKM900................................
12 Numeric Keys and 1 Bell Button.
PIN-codes.....................................
5 Digit codes in the range 00000 to 65535.
4 Digit codes in the range 0000# to 9999#.
Blank Space
WPR300-0-0-AC-04
March 2009
Page 3
INSTALLATION INFORMATION
Accessories
Find the following when unpacking the Wiegand Reader:
WPR900 and WPK900
Either a Wiegand Plastic Non-keypad Reader (WPR900-1-0-AC-XX) housed in a
dark gray, ABS plastic housing. The Wiegand Reader consists of a Front Cover
and a Backing Plate (the Backing Plate is attached with a Self-tapping Screw (M3 x
8 mm)). The front cover assembly includes 1 m (3.28 ft) of West Penn 3272,
shielded, multi-strand, 10-core cable.
Or a Wiegand Plastic Keypad Reader (WPK900-1-0-AC-XX) housed in a dark
gray, ABS plastic housing. The Wiegand Reader consists of a Front Cover and a
Backing Plate (the Backing Plate is attached with a Self-tapping Screw (M3 x 8
mm)). The front cover assembly includes 1 m (3.28 ft) of West Penn 3272,
shielded, multi-strand, 10-core cable.
One 2-Way Programming Pin.
Four Brass Wood Screws (3.5 mm x 25 mm).
Four Wall Plugs (7 mm).
An extra Serial Number Label.
WMR900 and WMK900
Either a Wiegand Metal Non-Keypad Reader (WMR900-1-0-AC-XX) housed in a
Zinc alloy die-cast housing. The Wiegand Reader consists of a Front Cover and a
Backing Plate (the Backing Plate is attached with a Hexagonal Screw (M3 x 8
mm)). The front cover assembly includes 1 m (3.28 ft) of West Penn 3272,
shielded, multi-strand, 10-core cable.
Or a Wiegand Metal Keypad Reader (WMK900-1-0-AC-XX) housed in a Zinc alloy
die-cast housing. The Wiegand Reader consists of a Front Cover and a Backing
Plate (the Backing Plate is attached with a Hexagonal Screw (M3 x 8 mm)). The
front cover assembly includes 1 m (3.28 ft) of West Penn 3272, shielded, multi-
strand, 10-core cable.
An Allen Key (2 mm).
One 2-Way Programming Pin.
Four Brass Wood Screws (3.5 mm x 25 mm).
Four Wall Plugs (7 mm).
An extra Serial Number Label.
WDP900
A Wiegand Door Entry Panel (WDP900-1-0-AC-XX) housed in a Black, ABS
Plastic housing. The Wiegand Door Entry Panel includes 1 m (3.28 ft) of West
Penn 3272, shielded, multi-strand, 10-core cable.
One 2-way Programming Pin.
An extra Serial Number Label.
WPR300-0-0-AC-04
March 2009
Page 4
WKM900
A Wiegand Keypad Mullion Reader (WKM900-1-AC-XX) housed in a Black, ABS
Plastic housing. The Wiegand Reader consists of a Front Cover and a Mounting
Bracket (the Mounting Bracket is attached with a Self-tapping Screw (M2 x 6 mm)).
A 1 m Wiegand Connector Cable.
One 2-Way Programming Pin.
Two Counter-sunk Self-tapping Screws (M2 x 6 mm).
Two Counter-sunk Self-taping Screws (2. Mm x 25 mm).
Two Wall Plugs (5 mm).
An extra Serial Number Label.
General
Remember the following when installing the Wiegand Readers:
Maximum Data Communications Distance
CAUTION: When implementing the 150 m cable distances with the Wiegand
Readers use the 12 V power input option.
Install the Wiegand Readers no further than 150 m (164 yd) from the Host unit. The
cable individual conductor cross-sectional area should not be less than 0.2 mm2
(0.0003 in2).
Distance between Wiegand Readers
To avoid mutual interference, install the Wiegand Readers no closer than 500 mm (20
in) apart.
Mounting the Wiegand Readers
CAUTION: Make certain that you mount the Readers on a vibration-free
surface.
Select the mounting position of the Wiegand Readers, considering accessibility, routing
of wires and visibility of the externally visible LED.
Secure the Wiegand Readers to the mounting surface, using four suitable screws and
wall plugs (supplied), nuts and bolts or rivets.
NOTE: The Wiegand Door Entry Panel is designed for mounting in a user supplied
enclosure. The Reader has 4 mounting holes, drilled to 4 mm in diameter.
The mounting holes accommodate M3 bolts and nuts.
Blank Space
WPR300-0-0-AC-04
March 2009
Page 6
Figure 2: Wiegand Reader Connected to the Nexus 220 Controller
WPR300-0-0-AC-04
March 2009
Page 7
Figure 3: Wiegand Reader Connected to the Amano MfT or the AXP121 Controller
WPR300-0-0-AC-04
March 2009
Page 8
Figure 4: Wiegand Reader Connected to the Amano TA or Amano iTA
WPR300-0-0-AC-04
March 2009
Page 9
Figure 5: Wiegand Reader Connected to the Amano RL (Amano RS and
Amano RH)
WPR300-0-0-AC-04
March 2009
Page 10
Wiegand Mode
The Wiegand Readers offer four different Output Mode Combinations:
Mode 1 (1 Beep): 26-bit, HID Normal.
Mode 2 (2 Beeps): 44-bit, HID Normal (Default).
Mode 3 (3 Beeps): 26-bit, HID Raw.
Mode 4 (4 Beeps): 44-bit, HID Raw.
The 26-bit and the 44-bit refer to the output format of EMM and Impro Trinary Tags.
HID Tags output in either normal or 45-bit raw mode.
Figure 6: Wiegand Pin Placement
Setting the Wiegand Mode
The Output Mode can be selected by doing the following:
1. Remove the Backing Plate from the Wiegand Reader.
2. Short circuit Pin 4 and Pin 5 (as shown in Figure 6) using the 2-Way Programming
Pin supplied.
3. Power up the Unit.
4. Remove the 2-Way Programming Pin after hearing the number of beeps
corresponding with the required mode (Refer to page 10 for Wiegand Output Mode
Combinations).
NOTE: The number of beeps on power-up indicates the selected Output Mode.
5. Replace the Backing Plate.
