Amana ABB1921DEW15 Troubleshooting guide
CABINET PARTS
1
For Model: ABB1921DEW15
(White)
3−09 Litho In U.S.A. (mat)(bay) Part No. W10260129 Rev.A
REFRIGERATOR
CABINET PARTS
2
For Model: ABB1921DEW15
(White)
W10260129
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175445
Owners Manual
W10183276
Energy Tag
W10238839
Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
M0310729 White
4 12249902 Label, Fill Tube
5 12580304 Roller Assembly
6
12627302SP
Clip, Grille
7 10351005 Pin, Center Hinge
8 12606103 Bolt, Adjusting
(Rear)
9 12992602 Screw
10 12477501 Cover, Fill Tube
11 12992201 Screw (3)
12 12990101 Screw
13 A3076901 Plug, Button
14 12992403 Screw (3)
15 Hinge, Center
12607103WD
White
16 10354002 Foot Brake (2)
17 Cover, Corner
12587703W
White
18
12566606ED
Hinge, Top
20 12991302 Screw (8)
21 Cover, Hinge
12477601W
White
22 Grille Assembly
(Includes Clips)
12734404W
White
23 10200802 Pin, Bottom Hinge
25 12990511 Screw (9)
26 Hinge, Bottom
12465002WD
White
27
W10217701
Cover, Water Valve
28
W10210978
Cover, Unit
29 12820505 Insulation, Sound
30
W10210987
Tube, Drain
33 B5759655 Gasket
34 Shim
M0274057 White
35 Cover, Lw Hinge
12561901W
White
REFRIGERATOR LINER PARTS
3
For Model: ABB1921DEW15
(White)
W10260129
REFRIGERATOR LINER PARTS
4
For Model: ABB1921DEW15
(White)
W10260129
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 12724303 Bracket, Control
and Lights
3 12650101 Belt, Damper
4 12649601 Tensioner, Belt
5 12566303 Timer, Defrost
6
C3680310V
Switch, Light
7 12706201 Knob, Front
8
12476401V
Housing, Light
9
A0282810V
Bulb, Light (2)
10
12570701V
Socket, Light (2)
11 12724201 Cover, Light
12
12990514V
Screw (2)
13 12649903 Cover, Damper
14 12650002 Insulation
15 12796101 Gear, Damper
Assembly
16 12694001 Knob
17 M0310343 Plug Button
18 12649207 Logo
19 12724401 Pan, Timer
Light Housing
Following Parts Not Illustrated
12679901 Harness, Controls
(Refrigerator)
(Includes # 16)
FREEZER LINER PARTS
5
For Model: ABB1921DEW15
(White)
W10260129
FREEZER LINER PARTS
6
For Model: ABB1921DEW15
(White)
W10260129
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam (2)
3 12476101 Panel, Fz Control
4 12476302 Cover, Light
5
A0282810V
Bulb, Light
6
12476401V
Housing
7 12226107 Cover, Evaporator
8 12990101 Screw (8)
9 12351008 Control, Fz Temp
10 13058002 Clip, Motor
11 12466105 Switch, Light
12
12570701V
Socket
13 A3189397 Gasket, Bottom
14 12476002 Module, Freezer
15 13057901 Shroud, Evaporator
16 2169142 Blade
17 12476209 Knob, Fz Control
18
W10128551
Motor, Evaporator
19
W10121318
Grommet
20 D7753903 Funnel, Drain
21 B8381501 Gasket
22 M0500703 Seal
23 13024803 Grille, Freezer
24 12932103 Guide, Fill Tube
Following Parts Not Illustrated
12966001 Harness, Lights
(Freezer)
REFRIGERATOR DOOR PARTS
7
For Model: ABB1921DEW15
(White)
W10260129
REFRIGERATOR DOOR PARTS
8
For Model: ABB1921DEW15
(White)
W10260129
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(w/ Insulation)
12658501WQ
White
3
12744905V
Door, Compartment
4
12369502SP
Tray, Dairy
5
12557204V
Bucket (2)
(Medium)
6 12528501 Nameplate
7 Plug, Button (2)
12246601 White
8 Gasket, Door
Magnetic
W10164030
White
9 Handle, Door
12753101W
White
10 12990508 Screw
11 12557202 Bucket (2)
Small
12 12248201 Screw
13 Bushing
10961006W
White
14 12557904 Retainer, Door
15 12990504 Screw
16 Stop, Door
10447111 White
17
12660304W
Trim, Handle
Lower
18
12641702W
Trim, Handle
Upper
FREEZER DOOR PARTS
9
For Model: ABB1921DEW15
(White)
W10260129
FREEZER DOOR PARTS
10
For Model: ABB1921DEW15
(White)
W10260129
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(w/ Insulation)
13024224WQ
White
2 Handle, Door
12610803W
White
3 Gasket, Door
W10164032
White
4 12990301 Screw
5 12246601 Plug, Hole White
6
10961006W
Bushing (4)
7 Stop, Door
10447111 White
8 12990504 Screw (2)
9 12737501 Retainer, Basket
