Allseating HALSA Single Midback Installation instructions

For material recycling information, please refer to the End of Life Recovery Matrix and

Listing Recycling Facilities, which is available at www.allseating.com.

Document: CAM-326

Revision: 01

Date: May 19, 2016

Disassembly Instructions

HALSA Single Midback

Back Frame

(Steel )

Seat

(Upholstered/Foam)

Arm

(Steel )

Back

(Upholstered/Foam)

Arm Pad

(Plastic or Wood)

Chair Frame

(Steel )

Glides

(Plastic)

Disassembly Instructions

HALSA Single Midback

Document: CAM-326

Revision: 01

Date: May 19, 2016

Tools: #2 #3 Phillips Head, Pliers, Allen Key, 5/16"-18 Head

Skill Set: Good manual dexterity

Estimated Time: 10 min. per chair

Steps:

1. Back Rest - 2 min.

Locate the 2 fasteners at the rear of the chair frame, and unfasten them. Pull the backrest

upwards to remove it from the frame.

In the case of a double chair, repeat step 1 again for the adjacent backrest.

2. Seat - 4 min.

Turn the chair upside down so the bottom is easily accessible. Locate the fasteners on the

underside of the frame, and unfasten them to remove the seat from the chair frame.

In the case of a double chair, repeat step 2 again for the adjacent seat.

3. Arm Pad - 2 min.

Locate the 2 fasteners on the underside of the armrest, and unfasten them to remove the

arm pads.

4. Glides - 2 min.

Turn the chair upside down. Using pliers, firmly grasp the feet glides, and wiggle/pull

upwards until free from the legs. Repeat the process for all four chair legs.
