Alfa Electric AVC145 User manual

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 1/19

UMA-CDZ-AVC145xxAE-04

USER’S MANUAL (PART 2)

AIR CONDITIONER FOR ELECTRICAL ENCLOSURES

INDOOR APPLICATION

AVC145

Document: UMA-CDZ-AVC145.xxx-04 Date Name

Description

Original user’s manual for air conditioner AVC145 series

Language: English

ISSUE 24/02/2020 Ascheri M.

REV. 04 07/09/2020 Ascheri M.

REV. 05

REV. 06

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 2/19

UMA-CDZ-AVC145xxAE-04

TECHNICAL DATA

age

2-INSTALLATION Page 3

2.1 - PRODUCT HANDLING

Page

2.2 - GENERAL CHECKS BEFORE INSTALLATION

Page

2.3 - FITTING Page 4

CTRICAL

CONNECTION

Page

3.1 - WIRING DIAGRAM

Page

3.1.1 – AVC145.000 Page 7

3.1.2 – AVC145.010

Page

3.1.3 – AVC145.020

Page

3.1.4 – AVC145.001 Page 10

3.1.5 – AVC145.011

Page

3.1.6 – AVC145.021

Page

STARTING AND ADJUSTMENT

Page

4.1 - DIGITAL THERMOSTAT

Page

4.2 - MECHANICAL THERMOSTAT

Page

PARE PARTS LIST

Page

5.1 - SPARE PARTS FOR AVC145.000, AVC145.010, AVC145.020

Page

5.2 - SPARE PARTS FOR AVC145.001, AVC145.011, AVC145.021

Page

WARRANTY

Page

CONFORM

ITY DECLARATION

Page

TECHNICAL

DATA

Features Unit AVC145.000 AVC145.001 AVC145.010 AVC145.011 AVC145.020 AVC145.021

Power supply V/Hz 230V - 1ph – 50/60 115V - 1ph – 50/60 400V - 2ph – 50/60

Dimensions HxWxD mm 800x400x240

Cooling capacity

A35A35 W 1450/1500

Cooling capacity

A35A50 W 1150/1200

Max current A 3.7/4.2 7.4/8.4 1.35/2.1

Delayed fuse A 10

Absorbed electric power

A35A35 W 660/700

Absorbed electric power

A35A50 W 800/860

Refrigerant type /

charge - / kg R134a / 0,7kg

Operating temperature

(ambient) °C +20/+55

Operating temperature

(enclosure) °C +20/+45

Noise level dB(A) 65

Electrical connection - Three-pole connector

Protection degree

EN60529/1 (enclosure) - IP54

Protection degree

EN60529/1 (ambient) - IP34

Weight (with packaging) kg 37 (38) 49 (50) 49 (50)

Colour - RAL 7035

Conformity/Certifications - CE

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 3/19

UMA-CDZ-AVC145xxAE-04

INSTALLATION

2.1 PRODUCT HANDLING

AIR CONDITIONER AVC series must be handled in upright

position and protected against accidental tipping over.

The air conditioner handling, when unpacked, can be done thanks to lifting eye bolt.

If lifting eye bolts are not included, please provide an adequate M6 male lifting eye bolt (2)

and screw it inside blind threaded (1) insert placed on top of the air conditioner

Check the proper fixing of eye bolts before lift the air conditioner.

2.2 GENERAL CHECKS BEFORE INSTALLATION

Before the installation make sure that the cabinet is disconnected from the

electrical supply.

GENERAL CHECKS

electrical enclosure must be disconnected

form powe

supply

- electrical data shown on rating label pasted on air conditioner side must be

guaranteed

- Electrical enclosure must be sized according to air conditioner dimensions and

weight.

Electrical

enclosure must have at least IP54 protection degree

- Internal and external components of electrical enclosure don’t have to affect the

proper

installation

air conditioner

- The installation site must be free from excessive dirt, aggressive ambient

conditions and moisture.

The installation site must be free from

hot air

flows

The

internal side of

lectrical enclosure must b

free from

dirt

and moisture

- The environment temperature must be within the range specified on label pasted

air

conditioner side

- Inside of electrical enclosure there must not be components that could affect the

proper ventil

ation

- the enclosure positioning with installed air conditioner must be carefully selected to

ensure good ventilation (clearance between the air conditioner and the near walls

must be at least 500 mm in each side).

oper

disposing of condensate discharge

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 4/19

UMA-CDZ-AVC145xxAE-04

2.3 FITTING

1) Make the fixing hole on the enclosure as is shown in the drilling template

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 5/19

UMA-CDZ-AVC145xxAE-04

Deburr all sharp edges to avoid accidental injuries

2) Apply the gasket (included in fixing kit) on the back panel of the air

conditioner;

3) Lift the air conditioner by lifting eyebolt and place it near the enclosure wall

4) Mount the air conditioner on the electrical cabinet according to the drilling

template with M6X16 screws and washers against unscrewing (included in

mounting kit)

5) Connect the condensate drain pipe as is shown in picture below

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 6/19

UMA-CDZ-AVC145xxAE-04

Air conditioner produces condensate because the moist air inside of the

enclosure meets cold heat exchanger (evaporator) and then it becomes water;

water production decreases during air conditioner working because

enclosure air becomes dry.

The enclosure must be IP 54 protected, if enclosure is not airtight, condensate

production could increase.

The enclosure IP54 degree is guaranteed only if the air conditioner is proper

mounted.

ELECTRICAL

CONNECTION

The electrical installation must be carried out by a qualified electrician who

is responsible for compliance with the applicable standards and

regulations.

Wire male plug (included) with an adequate cable as is shown by following picture

Cable section must be at least 1,5mm2

The male plug is fitted with spring terminals:

1) Push the spring with a screwdriver and then

insert the wire.

2) Check the proper wire insertion.

3) Connect the unit with the power supply

Electrical data shown on rating label pasted on air conditioner side must be

guaranteed

Install the delayed fuse recommended on rating plate pasted on air

conditioner side to protect the line and enclosure components against

short-circuit.

Upstream of the electrical connection, an efficient disconnection system

must be provided and it must be clearly identified

Air conditioner is already fitted with a temperature controller, no additional

temperature control must be connected upstream of the unit.

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 7/19

UMA-CDZ-AVC145xxAE-04

3.1 WIRING DIAGRAM

3.1.1 – AVC145.000

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 8/19

UMA-CDZ-AVC145xxAE-04

3.1.2 – AVC145.010

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 9/19

UMA-CDZ-AVC145xxAE-04

3.1.3 – AVC145.020

Designation: AIR CONDITIONER FOR ELECTRICAL ENCLOSURE Page 10/19

UMA-CDZ-AVC145xxAE-04

3.1.4 – AVC145.001
