Airwell MAY 90RCE User manual

Owner’s Manual

High Quality Window Type Room Air Conditioner

MAY 90RCE

Standby

Operate

Timer

Filter

RCA INST MANUAL

INTRODUCTION

PRODUCT DESCRIPTION

USE OF WIRELESS REMOTE CONTROL

REMOTE CONTROL

ON UNIT CONTROLS

MODES OF OPERATION, FUNCTIONS AND FEATURES

OPERATION PROCEDURE

Turning on the air conditioner

Ventilating operation

Cooling operation

Cooling operation with auto fan mode

Heating operation

Heating operation with auto fan mode

Auto cooling / heating operation

Dry operation

Selecting the temperature

Sleep function

Timer operation

Timer operating modes

Turning off the air conditioner

Current clock time set

PROTECTION MODES

CARE AND MAINTENANCE

OPERATING TIPS

PRECAUTIONS

BEFORE CALLING FOR SERVICE

CONTENTS

IF YOUR AIR

CONDITIONER IS FOR

COOLING ONLY, PLEASE

DISREGARD THE

HEATING INSTRUCTIONS

PLEASE READ THESE

INSTRUCTIONS BEFORE

OPERATING THE AIR

CONDITIONER

RCA INST MANUAL

This air conditioner is a domestic electrical product of the class 1 anti-

shock protection category. The user should have grounding

equipment to ensure that the grounding terminal of the air

conditioner’s plug can be secured grounded, the method of power

connection in the air conditioner is M type connection.

This air conditioner fully utilizes water condensation. This improves

condensation effects and increases air cooling efficiency. Moreover,

we have adopted special noise reduction devices to reduce the noise

of water pumping.

The maximum input power and electric current marked on the label

are values under the most condition before the air conditioner left the

factory. The outdoor temperature was 43 C. But the input power and

electric current rating marked on the label were obtained from testes

conducted under conditions in which the outdoor temperature was

35 C and voltage was 220V.

The noise value marked on the label was obtained from tests

conducted in the Noise Measurement Room at the factory.

The water proof level marked on the label is outdoor IXP4. That is

where the air conditioner is in stated of actual installation, the front

cover and the wall is sealed. Under these conditions, the IXP4 test is

carried out on the outside unit of the air conditioner.

Note: If your air conditioner is the type that for cooling only, ignore the

instructions related to heating.

INTRODUCTION - GENERAL INFORMATION

IMPORTANTNOTICE:

This air conditioner must be

grounded to protect against

electrical shock.

Electrical connections and

power cord replacement

should be made by

authorized electricians and in

accordance with electrical

regulations and local codes.

Cooling

Heating.

Dehumidifying

Air Filtration

Ventilation

To ensure correct and safe use of the air conditioner, be sure to install

in accordance with the installation instructions. Before using

the air conditioner, read these instructions carefully and keep them in a

safe place.

This window-type air conditioner can be used for commercial, residential

or other purposes.

properly

RCA INST MANUAL

Horizontal Air Louvre

Air Exhaust Control

Power Cord

Air Intake Grille Air FilterFront Panel

Reset key (H) (manual control button)

Protective Cover of

the Control Panel

Vertical Air Louvre

adjustment Knob.

ON UNIT INDICATORS AND CONTROLS

PRODUCT DESCRIPTION

AIR CONDITIONER CONTROL PANEL

Cool / heat / on / off air conditioner operation

keys (manual control buttons)

Power Indicator Light (A)

Operation Indicator Light (B)

Timer Indicator Light (C)

Filter Indicator Light (D)

Air Conditioner

Control Unit

RCA INST MANUAL

When the room is full of fouled air, you can put the air exhaust lever

to open position to discharge the fouled air out of the room.

Four positional adjustments can be made to the direction of this

machine’s upper air outlet. Select the air direction that best

meets your requirements.

VENTILATION

AIR FLOW DIRECTION ADJUSTMENT

Note:

If the lever for air outlet

adjustment is kept in

the open position, the

effectiveness of the air

cooling operation and

the drying function will

be reduced.

Ventilation (air exhaust control)

Vertical

adjustment of air

exhaust louvre

Horizontal

adjustment of air

exhaust louvre

RCA INST MANUAL

COOL Cools, dehumidifies and filters the room air. Maintains the desired room

temperature.

OPERATION MODES, FUNCTIONS

AND FEATURES

SLEEP Designed to create comfortable sleeping conditions. When in COOLING mode,

the temperature rises one degree centigrade every hour, for to three hours, from

the start of the mode. The temperature rise prevents the feeling of over-cooling

while sleeping (when your body is at rest). In HEATING mode the reverse occurs;

the air conditioner lowers its temperature one-degree every hour. When in SLEEP

mode, the air conditioner will be automatically turned off after have operated for

seven hours. The result is a more comfortable and invigorating sleep, which leaves

you feeling fresh and energetic on the next morning.

TIMER Real time control and display, automatically turns the air conditioner ON and

OFF according to the time of day setting, ensuring comfort conditions before

returning home, without wasting electricity. It turns the air conditioner off

automatically when sleeping.

HOT KEEP In HEATING and in AUTO FAN, the fan will be turned off when the compressor

is not in operation and will not be restarted, unless the indoor coil reaches

adequate temperature. The fan speed will vary automatically according to the

room temperature.

AUTO FAN The air conditioner automatically selects the FAN speed in accordance to with the

room temperature. At the start, the unit operates at high fan speed. As the room

air approaches to the desired temperature, the fan switches to a lower speed for

quieter operation.

FAN Recirculates and filters the room air. Maintains constant air movement in

the room.

DRY Dehumidifies and softly cools the room In DRY Mode, the air conditioner

operates at an inceased dehumidifying power. This function is recommended

to be used when temperature is rather low but the humidity is high.

AUTO Automatically switches from COOLING to HEATING or from HEATING to

COOLING, maintaining the desired temperature according to the room conditions.

HEAT Heats and filters the room air. Maintains the desired room temperature.

RCA INST MANUAL

BUZZER A soft buzzer will sound from the indoor unit display to indicate that a command

sent by the remote control has been accepted and stored in the unit s memory.

This feature may be easily cancelled by the user from the display panel.

3-MIN

DELAYED RUN

This compressor is protected by a three-minute delayed restart.

ON UNIT

OPERATION

The air conditoner can be aturned ON for COOLING or HEATING or be turned

OFF directly form the indoor unit display panel without the use of the remote

control.

SETTING

STORED

The air conditioner will store all the settings of the MODE button in COOL, HEAT,

AUTO, DRY and FAN

FILTER

INDICATION Filter indicator on the indoor unit display is turned on when the filter requires

cleaning. After cleaning and reistalling the filter, the system should be reset.

MEMORY The microprocessor retains the last data entry whether or not the unit is plugged

in. Therefore, when the unit restarts after a power distruption or failure, it will

resume operating in the same mode as before the power was disrupted.

RCA INST MANUAL

USE OF WIRELESS REMOTE CONTROL

WIRELESS REMOTE

CONTROL PUTS ALL

FUNCTIONS AT YOUR

FINGERTIPS

●

Aim at the infrared signal receiver on the room air conditioner when operating.

●

The remote control signal can be received at a distance of up to about 8 m.

●

Be sure that there is nothing between the remote control and the signal receptor.

●

Do not drop or throw the remote control.

●

Do not place the remote control in a location exposed to direct sunlight, or next to a

heating unit, and/or other heat source.

●

Do not expose the air conditioner signal receiver to a strong light such as fluorescent

lamp or sunlight

REMOTE CONTROL BATTERY CHANGE

● Remove the batteries from the remote control as shown.

● Use two 1.5 volt size AAA batteries

● Perform reset operation by pressing buttons (9), (10), (13), (14)

Prior to operating your air

conditioner, make sure that:

PRIOR TO

OPERATION

●

The unit is properly

plugged into the electrical

socket.

●

Stand bu Indicator (A) on the

unit's display is lit, meaning

that the air conditioner is ready

to accept your remote control

command.

●

The red tap protecting the

remeote control batteries has

been removed.

●

For clock setting, see page 11.

Use the remote control holder

when unit is not in use.

REMOTE CONTROL

HOLDER (DESK TYPE)

Remote control can be slipped

in or out its holder.

RCA INST MANUAL

REMOTE CONTROL

AUTO

OFF

MODE

TIMER

SET

CLEAR

START/STOP button

Operation mode

selection button

COOLING

HEATING

AUTO COOL/HEAT

DRY

FAN

FAN SPEED and

AUTO FAN button

Room temperature

UP button

Room temperature

DOWN Button

SLEEP button

Airflow direction

AUTO-CONTROL

button

TIMER button

TIMER UP button

TIMER DOWN button

LCD operation display

Infrared signal

transmitter

TIMER SET button

TIMER CLEAR button

Transmission sign

AUTO

OFF

MODE

TIMER

SET

CLEAR

RCA INST MANUAL

OPERATION PROCEDURE

MODE

TIMER

SET

CLEAR

MODE

TIMER

SET

CLEAR

MODE

TIMER

SET

CLEAR

MODE

TIMER

SET

CLEAR

AUTO

OFF

AUTO

OFF

AUTO

OFF

AUTO

OFF

AUTO

OFF

MODE

TIMER

SET

CLEAR

Press START/STOP button (1) to turn the air conditioner. After connecting to the

power supply,Theindicator (B)on the air conditioner light up, indicating that the air

conditioner is in the standby status. Please note that LCD operation display (11) will

always show the last mode of operation and the function used. If you

want to change the control settings, proceed according to the following instructions.

Otherwise, the air conditioner will start and operate in the same mode and functions prior to

being turned off.

Select the ventilating mode by pressing MODE button (2). Switch to the desired

fan speed by pressing FAN speed button (3).

Select the COOLING mode by pressing MODE button (2). Switch to the desired

FAN SPEED or to AUTO FAN by pressing button (3). Select suitable temperature

setting. By selecting the COOLING mode, the air flap will move automatically to air

delivery position, optimal for cooling.

This operation starts with the highest air flow in order to quickly lower the room

temperature. It will then automatically switch to the low air flow to quietly maintain

the selected temperature.

Select the HEATING mode by pressing MODE button (2). Switch to the

desired FAN SPEED or to AUTO FAN by pressing FAN button (3). Select

suitable temperature setting. By selecting the HEATING mode, the air flap will

move automatically to air delivery position, optimal for heating.

TURNING ON THE AIR CONDITIONER

VENTILATING OPERATION

COOLING OPERATION

COOLING OPERATION WITH AUTO FAN MODE

HEATING OPERATION

HEATING OPERATION WITH AUTO FAN MODE

This operation starts with the highest air flow in order to quickly raise the room

temperature. It will then automatically switch to a lower air flow to quietly maintain

the selected temperature. HEATING with AUTO FAN will automatically provide

the user with the HOT KEEP function. The fan will be turned off when the indoor

coil temperature is not sufficiently hot to prevent uncomfortable cold air drafts.

AUTO

OFF

MODE

TIMER

SET

CLEAR

RCA INST MANUAL

Table of contents

Other Airwell Air Conditioner manuals

Airwell

Airwell High Wall HDA User manual

Airwell

Airwell CADE024 User manual

Airwell

Airwell AW-YSDM048-H11 User manual

Airwell

Airwell VRF Series Installation and operation manual

Airwell

Airwell AWAU-YDV280-H13 User manual

Airwell

Airwell AWSI-HZDE009-H11 User manual

Airwell

Airwell Aqu@Scop Advance R410A Manual

Airwell

Airwell HVVA-025/022N-01M22 Guide

Airwell

Airwell CCD User manual

Airwell

Airwell YBZE218-324-430 User manual

Airwell

Airwell AWSI-HDDE009-H11 User manual

Airwell

Airwell MAY 180 User manual

Airwell

Airwell DDMX-035N-09M25 User manual

Airwell

Airwell Aqu@Scop Advance R410A User manual

Airwell

Airwell CX 25 User manual

Airwell

Airwell MAY Series User manual

Airwell

Airwell VVFA-220R-01T32 User manual

Airwell

Airwell CDM Cassette AW-YDFA012-H91 User manual

Airwell

Airwell AWSI-HMF009-N12 User manual

Airwell

Airwell AW-FWDB018-N91 User manual

Airwell

Airwell HVVA-025N-01M22 User manual

Airwell

Airwell IU-MINV-HW-9H User manual

Airwell

Airwell DFMD-100N-01M25 User manual

Airwell

Airwell AWAU-YCV080-H11 User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual
