AirLive WIAS-1200G User manual

Quick Setup Guide

WIAS-1200G

802.11g Internet Access Server

English ●●●

Polski ●●●

Español ●●●

Deutsch ●●●

Česky ●●●

Русский ●●●

Português ●●●

日本語 ●●●

Slovensky ●●●

802.11g Internet Access Server

WIA

1200G English

English

Declaration of Conformity

We, Manufacturer/Importer

OvisLink Corp.

5F., NO.6, Lane 130, Min-Chuan Rd.,

Hsin-Tien City, Taipei County, Taiwan

Declare that the product

802.11g Internet Access Server

WIAS-1200G

is in conformity with

In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive

Clause Description

■ EN 300 328 V1.6.1 Electromagnetic compatibility and Radio spectrum Matters (ERM)

(2004-11) Wideband transmission equipment operating in the 2.4GHz ISM band

And using spread spectrum modulation techniques; Part 1：technical

Characteristics and test conditions Part2：Harmonized EN covering

Essential requirements under article 3.2 of the R&TTE Directive

■ EN 301 489-1 V1.6.1 Electromagnetic compatibility and Radio spectrum Matters (ERM);

(2005-09) Electromagnetic compatibility(EMC) standard for radio equipment and

■ EN 301 489-17 V1.6.1 Services; Part 17：Specific conditions for wideband data and

(2005-09) HIPERLAN equipment

■ EN 60950-1:2006 Safety for information technology equipment including electrical

Business equipment

■ CE marking

Manufacturer/Importer

Signature： ______________

Name ： Albert Yeh____

Position/ Title : Vice President

Date： 2007/6/7_____

802.11g Internet Access Server

WIA

1200G English

Note on the FCC standard

This equipment has been tested and found to comply with the limits for a

Class B digital device pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interferences

when the equipment is operating in a commercial area. This equipment

generates, uses and may radiate radio frequency energy, and if not installed

in accordance with the user guide, may cause interference in the

transmission of radio communications. If operating in a residential area, it is

probable this equipment will cause harmful interference, in which case the

user will be required to try to correct this interference using his own means.

Note on CE Marking

This is a Class B product. In a residential area this product may cause radio

interference, in which case the user can be required to take the appropriate

measures. OvisLink Corp. hereby declares that WIAS-1200G meets the

basic requisites of directive 99/05/CE, and is therefore liable for the accuracy

of these data: OvisLink Corp.

5F, No.6 Lane 130,

Min-Chuan Rd, Hsin-Tien City,

Taipei, Taiwan

TEL: +886-2-2218-6888

Warranties

This product has undergone various quality controls to ensure proper

operation.

This product is covered by a two-year warranty for countries inside European

Union. For other countries, the warranty period is one year only. In the

event of any manufacturing fault or breakdown, it will be repaired by OvisLink

Corp. Please contact your supplier for details on the procedure to follow.

This warranty shall not be applicable in the event of damage caused by

improper use of the product, accidents, faulty handling or manipulation nor

any future incompatibility with third party products.

English

802.11g Internet Access Server

WIA

1200G English



The managed ports are LAN 3 and LAN 4



The default IP address is 192.168.2.254



The default Subnet Mask is 255.255.255.0



LED Indicators

LED Status (when LED is ON)

Power Proper connection to the power supply.

WLAN Proper AP function

WAN Good connection to the WAN port

LAN3/LAN4 Good connection to the LAN port

LAN1/LAN2 Good connection to the LAN port

English

Important Information

802.11g Internet Access Server

WIA

1200G English

Hotspot Connecting Example

WAN: Connects to Internet or Intranet.

LAN1/LAN2: Connects to the open network environment. It can be

chosen to require or not require authentication to access

network resources and Internet.

LAN3/LAN4: Connects to the trusted Internet network.

Authentication is not required to access network

resources.

Console: Configures the system via Hyper Terminal.

Reset: Press this button to restart the system.

DC Power: The power adaptor is attached here.

English

WIAS-1200G used in the hotspot environment is usually connected to

the Internet through ADSL. Please refer to the following diagram for

connecting WIAS-1200G with an ADSL modem.

802.11g Internet Access Server

WIA

1200G English

Web UI Configuration example

English

After completing the hardware installation and successfully logging into the

web management interface, click the System Configuration from the top

menu and Run Wizard to begin the Configuration Wizard.

STEP 1: Change Admin’s Password

802.11g Internet Access Server

WIA

1200G English

English

STEP 3: Set System Information

yHome Page: Enter the URL that clients should be initially redirected to

after being successfully authenticated to the network.

yNTP Server: Enter the URL of the external time server for

WIAS-1200G time synchronization or use the default.

yDNS Server: Enter a DNS Server provided by your ISP (Internet

Service Provider). Contact your ISP if you are not sure

of the DNS IP Address.

STEP 2: Choose System’s Time Zone

802.11g Internet Access Server

WIA

1200G English

STEP 4: Select the Connection Type for WAN Port

STEP 4 (Cont): Set PPPoE Client’s Information

Enter the Username and Password provided by your ISP.

English

802.11g Internet Access Server

WIA

1200G English

STEP 5: Select Authentication Methods

STEP 5 (Cont): Add User

Enter the Username (e.g. test), Password (e.g. test), and MAC (optional).

Assign a policy to add this particular local user.

English

802.11g Internet Access Server

WIA

1200G English

English

STEP 6: Set Wireless – Access Point Connection

ySSID: Enter a SSID (up to 32 characters) for the system.

yTransmission Mode: It supports two transmission modes:

802.11b and 802.11 (b+g).

yChannel: If the default channel is occupied by many other APs, it is

necessary to select another channel from the Channel field

for a better performance.

STEP 7: Save and Restart AirLive WIAS-1200G

Now the basic configuration for Hotspot environment has been finished!

User PC connects to Public Port or Wireless interface of WIAS-1200G to

obtain an IP address automatically. After the IP address is obtained,

launch an Internet browser and link to any website. The User Login Page

will appear.

Key-in the username and password (e.g. test@Local for the username

and test for the password) or from on-demand user account, click Submit

to connect to the network.

For further information, please refer to the user’s manual.
