U-17

AG Neovo’s most eco-minded

display with unmatched durability

and power efciency in a stylish

design ideal for the busiest multi-

user environments.

With a bright 17-inch screen, stereo speakers, side-mount

headphone jack and USB port, the U-17’s multimedia feature set

is matched only by its breakthrough power-saving technology.

Reduce power consumption up to 50% compared to standard

LCD monitors (67% versus CRTs), or cut power usage to zero with

EcoSwitch. Add durable touch-sensor controls, best-in-class NeoV™

Optical Glass, and the U-17 easily becomes the smartest, most eco-

friendly choice of professionals.

> NeoV™ Optical Glass

> Contemporary & professional design

> 1280 x 1024 resolution, 1000:1 contrast ratio and 3ms response

> Eco-friendly: Slash CO2 emissions up to 50%; Recyclable materials and green design

> Energy ecient: Cut power bills up to 50%; Zero-watt consumption with EcoSwitch

> Built-in headphone jack and stereo speakers

> Wear-resistant touch sensor controls

> Easy-access USB port (pass through)

> New intuitive OSD with settings lock

> Dual PC inputs: VGA and DVI

> Kensington® security socket

> VESA standard wall mount

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: U170B0 Version 6.1, 20130701

Side-mount headphone jack, USB port and built- in

stereo speakers for multimedia convenience

Durable, long-lasting touch sensor controls won’t wear

out like mechanical buttons

NeoV™ Optical Glass protects against scratches, impacts

and other physical damage

Slash power bills and CO emissions by up to 50% (67%

versus CRTs); EcoSwitch cuts power usage to zero when o

Specications U-17

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

TFT LCD

17.0” (432 mm)

SXGA 1280 x 1024

0.264 mm

250 cd/m2 (Typical)

1000:1 (Typical)

170°/160° (Typical)

16.7M

3 ms (GTG)z

Frequency (H/V) H: 24 kHz - 81 kHz

V: 56 Hz - 75 Hz

Input Analogue

Digital

15-Pin D-Sub

24-Pin DVI-D

Audio Audio In

Audio Out

Speaker

3.5 mm Audio Line-in

3.5 mm Headphone Jack

1W x 2

Power Power Supply

Power Requirements

Consumption

Internal

AC 100 - 240 V, 50 - 60 Hz

< 20 W (On)

< 0.5 W (Stand-by)

< 0.5 W (Off)

= 0 W (EcoSwitch off)

NeoV™

Optical Glass

Thickness

Reection Rate

Transmission Rate

Coating Hardness

3.0 mm (0.12”)

< 1%

> 96%

> 9H

Plug & Play VESA DCC 2B, DDC/CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 x 100mm)

Tilt Tilt 0° ~ +20°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

397 x 390 x 174 mm

(15.6” x 15.4” x 6.9”)

480 x 460 x 145 mm

(18.9” x 18.1” x 5.7”)

Weight Product

Packaged

5.7 kg (12.5 lbs)

7 kg (15.4 lbs)

Regulation

Approval

Certications &

Compliance

CB, FCC, CE, GOST-R, WEEE,

Energy Star, RoHS, REACH

Accessories Supplied CD ROM (user manual and

drivers), audio cable, AC power

cord and 15-Pin D-Sub cable

U-17
