Report Number: 030355-D

April 29, 2003

Page 1 of 27

Rev. 00

FCC CLASS B COMPLIANCE REPORT

(DoC)

for

Electromagnetic Emissions

LCD Monitor

Trade Name : COMPAL; AG neovo

Model Number : GM678; F-417

Serial Number : N/A

Report Number : 030355-D

Date : April 29, 2003

Prepared for：

Compal Electronics Inc.

No. 581, Jui Kuang Rd., Neihu,

Taipei, (114) Taiwan, R.O.C.

Prepared by：

C&C LABORATORY, CO., LTD.

No. 81-1, 210 Lane, Pa-de 2nd Road, Lu-Chu Hsiang,

Taoyuan, Taiwan, R.O.C.

TEL: (03) 324-0332

FAX: (03) 324-5235

This report shall not be reproduced, except in full, without the written approval of

C&C LABORATORY, CO., LTD.

The client to claim product certification, approval or endorsement by NVLAP, NIST or any agency

of the federal government must not use this report.

Report Number: 030355-D

April 29, 2003

Page 2

Rev. 00

TABLE OF CONTENTS

1VERIFICATION OF COMPLIANCE.......................................................3

2SYSTEM DESCRIPTION.........................................................................4

3PRODUCT INFORMATION ....................................................................5

4SUPPORT EQUIPMENT..........................................................................6

5MEASUREMENT PROCEDURE ............................................................7

5.1 PRELIMINARY LINE CONDUCTED EMISSION TEST.............................7

5.2 FINAL LINE CONDUCTED EMISSION TEST.............................................8

5.3 PRELIMINARY RADIATED EMISSION TEST ...........................................9

5.4 FINAL RADIATED EMISSION TEST.........................................................10

6SUMMARY DATA...............................................................................11

7TEST FACILITY.....................................................................................14

8TEST EQUIPMENT LIST.......................................................................15

9BLOCK DIAGRAM OF TEST SETUP..................................................16

10 APPENDIX 1 PHOTOGRAPHS

(TEST SETUP OF LINE CONDUCTED EMISSION TEST)................17

11 APPENDIX 2 PHOTOGRAPHS

(TEST SETUP OF RADIATED EMISSION TEST)...............................19

12 APPENDIX 3 PHOTOGRAPHS OF EUT...........................................21

13 APPENDIX 4 LABELING REQUIREMENTS...................................25

Report Number: 030355-D

April 29, 2003

Page 3

Rev. 00

1 VERIFICATION OF COMPLIANCE

Equipment Under Test: LCD Monitor

Trade Name: COMPAL; AG neovo

Model Number: GM678; F-417

Serial Number: N/A

Applicant: Compal Electronics Inc.

No. 581, Jui Kuang Rd., Neihu, Taipei, (114) Taiwan, R.O.C.

Manufacturer: 1.) Compal Electronics Inc.

No. 8, Nan-Tung Rd., Pin-Cheng City, Tao-Yuan Hsien, Taiwan,

R.O.C.

2.) Compal Electronics (China) Co., Ltd.

No. 988, Tung Fen East Rd., Economic & Technical Development Zone

Kunshan, Jiangsun, P.R. China

Type of Test: FCC Class B (DoC)

Measurement Procedure: ANSI C63.4: 2001

File Number: 030355-D

Date of Test: April 24 ~ 25, 2003

Deviation: None

Condition of Test Sample: Normal

Final Result: Pass

Worst Data: See below

Test Item Freq. (MHz) Measured Data Margin (MµC) Remark

Radiated Emission 179.76 27.7 (dB/m) -2.3 dB (± 3.3498 dB)

Conducted Emission 0.150 41.5 (dB) -24.5 dB (± 2.8216 dB)

 The negative sign in Margin cell means under the specific limit.

 This test result traceable to national or international standards.

The above equipment was tested by C&C Laboratory, Co., Ltd. for compliance with the

requirements set forth in the FCC Rules and Regulations Part 15, Subpart B and the measurement

procedure according to ANSI C63.4. This said equipment in the configuration described in this

report shows the maximum emission levels emanating from equipment are within the compliance

requirements.

The test results of this report relate only to the tested sample identified in this report.

Approved by: Reviewed by:

Jonson Lee / EMC Director Susan Su / Section Manager

Report Number: 030355-D

April 29, 2003

Page 4

Rev. 00

2 SYSTEM DESCRIPTION

EUT Test Program:

1. EMI test program was loaded and executed in Windows 98 mode.

2. Data was sent to EUT filling the screen with upper case of “H” patterns.

3. Test program sequentially exercised printer and modem, then sent “H” patterns to them

individually.

4. Repeat 2 to 3. Test program is self-repeating throughout the test.

Report Number: 030355-D

April 29, 2003

Page 5

Rev. 00

3 PRODUCT INFORMATION

Housing Type: Plastic

EUT Power Rating: 100~240VAC, 50 / 60Hz

AC power during Test: 120VAC/ 60Hz

AC Power Cord Type: Unshielded, 1.8m (Detachable)

OSC/Clock Frequencies: 14.318MHz

LCD Panel Manufacturer: Hyundai Model: HT17E12-200

Power Board Manufacturer: COMPAL Model: VP-719

Main Board Manufacturer: COMPAL Model: VL-720

Key Board Manufacturer: COMPAL Model: VK-718

VGA Cable Type: Shielded, 1.8m (Non-detachable) with two cores

I/O Port of EUT

I/O Port Type Q’TY Tested with

1). Video Out Port (VGA) 1 1

Note: The differences between of the two model numbers (list on this report) are identical, just for

marketing purpose only.

Report Number: 030355-D

April 29, 2003

Page 6

Rev. 00

4 SUPPORT EQUIPMENT

No. Equipment Model

# Serial

# FCC

ID Trade

Name Data

Cable Power

Cord

1. PC EVO D300 6K1BKF83F18F FCC DoC Compaq N/A Unshielded, 1.8m

2. Modem 2400 94-364-176277 DK467GSM24

Computer

Peripherals Shielded, 1.8m Unshielded, 1.8m

3. Printer EPSON

STYLUS

C20SX DW4E130540 FCC DoC EPSON Shielded, 1.8m Unshielded, 1.8m

4. PS/2

Keyboard SK-2800C B1C790BCPJCN6L GYUR79SK Compaq Shielded, 1.8m N/A

5. PS/2 Mouse M-CAA43 LZA11750827 FCC DoC Logitech Shielded, 1.8m N/A

Note: All the above equipment/cables were placed in worse case positions to maximize emission

signals during emission test.

Grounding: Grounding was in accordance with the manufacturer’s requirements and conditions for

the intended use.

Report Number: 030355-D

April 29, 2003

Page 7

Rev. 00

5 MEASUREMENT PROCEDURE

5.1 PRELIMINARY LINE CONDUCTED EMISSION TEST

1) The equipment was set up as per the test configuration to simulate typical actual usage per the

user’s manual. When the EUT is a tabletop system, a wooden table with a height of 0.8 meters

is used and is placed on the ground plane as per ANSI C63.4 (see Test Facility for the

dimensions of the ground plane used). When the EUT is a floor-standing equipment, it is

placed on the ground plane which has a 3-12 mm non-conductive covering to insulate the EUT

from the ground plane.

2) Support equipment, if needed, was placed as per ANSI C63.4.

3) All I/O cables were positioned to simulate typical actual usage as per ANSI C63.4.

4) The EUT received AC power through a Line Impedance Stabilization Network (LISN) which

supplied power source and was grounded to the ground plane.

5) All support equipment received power from a second LISN supplying power of 110VAC/60Hz,

if any.

6) The EUT test program was started. Emissions were measured on each current carrying line of

the EUT using a spectrum analyzer / Receiver connected to the LISN powering the EUT. The

LISN has two monitoring points: Line 1 (Hot Side) and Line 2 (Neutral Side). Two scans

were taken: one with Line 1 connected to Analyzer / Receiver and Line 2 connected to a 50

ohm load; the second scan had Line 1 connected to a 50 ohm load and Line 2 connected to the

Analyzer / Receiver.

7) Analyzer / Receiver scanned from 150kHz to 30MHz for emissions in each of the test modes.

8) During the above scans, the emissions were maximized by cable manipulation.

9) The following test mode(s) were scanned during the preliminary test:

Mode(s):

1. 1280 × 1024 Resolution 75Hz

2. 1024 × 768 Resolution 75Hz

3. 800 × 600 Resolution 75Hz

10) After the preliminary scan, we found the following test mode producing the highest emission

level.

Mode: 1.

Then, the EUT configuration and cable configuration of the above highest emission level were

recorded for reference of final testing.

Report Number: 030355-D

April 29, 2003

Page 8

Rev. 00

5.2 FINAL LINE CONDUCTED EMISSION TEST

1) EUT and support equipment was set up on the test bench as per step 10 of the preliminary test.

2) A scan was taken on both power lines, Line 1 and Line 2, recording at least the six highest

emissions. Emission frequency and amplitude were recorded into a computer in which

correction factors were used to calculate the emission level and compare reading to the

applicable limit. If EUT emission level was less –2dB to the A.V. limit in Q.P. mode, then the

emission signal was re-checked using an Average detector.

3) The test data of the worst case condition(s) was reported on the Summary Data page.

Data Sample:

Freq.

MHz

Q.P.

Raw

dBuV

Average

Raw

dBuV

Q.P.

Limit

dBuV

Average

Limit

dBuV

Q.P.

Margin

Average

Margin

Note

x.xx 43.95 --- 56 46 -12.05 -2.05 L 1

Freq. = Emission frequency in MHz

Raw dBuV = Uncorrected Analyzer/Receiver reading +

Insertion loss of LISN, if it > 0.5 dB

Limit dBuV = Limit stated in standard

Margin dB = Reading in reference to limit

Note = Current carrying line of reading

“---“ = The emission level complied with the

Average limits, with at least 2dB margin

limits, so no further recheck.

Calculation example:

Margin (dB) = RAW (dBuV) – Limit (dBuV)

LINE CONDUCTED EMISSION LIMIT

Maximum RF Line Voltage

Frequency Q.P. AVERAGE

150kHz-500kHz 66-56dBuV 56-46dBuV

500kHz-5MHz 56dBuV 46dBuV

5MHz-30MHz 60dBuV 50dBuV

Note: The lower limit shall apply at the transition frequency.

Report Number: 030355-D

April 29, 2003

Page 9

Rev. 00

5.3 PRELIMINARY RADIATED EMISSION TEST

1) The equipment was set up as per the test configuration to simulate typical actual usage per the

user’s manual. When the EUT is a tabletop system, a wooden turntable with a height of 0.8

meters is used which is placed on the ground plane as per ANSI C63.4 (see Test Facility for the

dimensions of the ground plane used). When the EUT is a floor-standing equipment, it is

placed on the ground plane which has a 3-12 mm non-conductive covering to insulate the EUT

from the ground plane.

2) Support equipment, if needed, was placed as per ANSI C63.4.

3) All I/O cables were positioned to simulate typical actual usage as per ANSI C63.4.

4) The EUT received AC power source from the outlet socket under the turntable. All support

equipment received 110VAC/60Hz power from another socket under the turntable, if any.

5) The antenna was placed at 10 meter away from the EUT as stated in ANSI C63.4. The

antenna connected to the Analyzer via a cable and at times a pre-amplifier would be used.

6) The Analyzer / Receiver quickly scanned from 30MHz to 1000MHz. The EUT test program

was started. Emissions were scanned and measured rotating the EUT to 360 degrees and

positioning the antenna 1 to 4 meters above the ground plane, in both the vertical and the

horizontal polarization, to maximize the emission reading level.

7) The following test mode(s) were scanned during the preliminary test:

Mode(s):

1. 1280 × 1024 Resolution 75Hz

2. 1024 × 768 Resolution 75Hz

3. 800 × 600 Resolution 75Hz

8) After the preliminary scan, we found the following test mode producing the highest emission

level.

Model: 1.

Then, the EUT and cable configuration, antenna position, polarization and turntable position of the

above highest emission level were recorded for reference of final testing.

Report Number: 030355-D

April 29, 2003

Page 10

Rev. 00

5.4 FINAL RADIATED EMISSION TEST

1) EUT and support equipment were set up on the turntable as per step 8 of the preliminary test.

2) The Analyzer / Receiver scanned from 30MHz to 1000MHz. Emissions were scanned and

measured rotating the EUT to 360 degrees, varying cable placement and positioning the antenna

1 to 4 meters above the ground plane, in both the vertical and the horizontal polarization, to

maximize the emission reading level.

3) Recorded at least the six highest emissions. Emission frequency, amplitude, antenna position,

polarization and turntable position were recorded into a computer in which correction factors

were used to calculate the emission level and compare reading to the applicable limit and only

Q.P. reading is presented.

4) The test data of the worst case condition(s) was reported on the Summary Data page.

Data Sample:

======================================================================

Freq. Raw Corr. Emiss. Limits Margin

Data Factor Level

(MHz) (dBuV) (dB) ( dBuV/m ) (dB)

======================================================================

xx.xx 14.0 11.2 26.2 30 -3.8

======================================================================

Freq. = Emission frequency in MHz

Raw Data (dBuV) = Uncorrected Analyzer / Receiver reading

Corr. Factor (dB) = Antenna factor + Cable loss – Amplifier gain

Emiss. Level = Raw reading converted to dBuV/m and CF added

Limit dBuV/m = Limit stated in standard

Margin dB = Reading in reference to limit

P = Peak Reading

Q = Quasi-peak Reading

A = Average Reading

Calculation example:

Margin (dB) = Emiss. Level (dBuV/m) – Limits (dBuV/m)

Emission Level (dBuV/m)=Raw Data (dBuV) + Corr Factor (dB)

RADIATED EMISSION LIMIT

Frequency

(MHz)

Distance

(m)

Maximum Field Strength Limit

(dBu V/m/ Q.P.)

30-230 10 30

230-1000 10 37

Note: The lower limit shall apply at the transition frequency.

Other manuals for GM678

This manual suits for next models

Table of contents

Other AG Neovo Monitor manuals

AG Neovo

AG Neovo PN Series User manual

AG Neovo

AG Neovo H-W22 Instruction Manual

AG Neovo

AG Neovo X-19 User manual

AG Neovo

AG Neovo X-17P User manual

AG Neovo

AG Neovo 17" LCD Display E-17B User manual

AG Neovo

AG Neovo PN-55D User manual

AG Neovo

AG Neovo M-17 User manual

AG Neovo

AG Neovo SC-17 User manual

AG Neovo

AG Neovo SX-17P User manual

AG Neovo

AG Neovo FM-27 User manual

AG Neovo

AG Neovo QM-65 User manual

AG Neovo

AG Neovo TX-42 User manual

AG Neovo

AG Neovo M-19 Instruction Manual

AG Neovo

AG Neovo QX-24 User manual

AG Neovo

AG Neovo DR-17G User manual

AG Neovo

AG Neovo TM-22 User manual

AG Neovo

AG Neovo PM-48 User manual

AG Neovo

AG Neovo PN-46D User manual

AG Neovo

AG Neovo HX-32 User manual

AG Neovo

AG Neovo TX-W32 User manual

AG Neovo

AG Neovo QM Series User manual

AG Neovo

AG Neovo F-419 User manual

AG Neovo

AG Neovo M-19 User manual

AG Neovo

AG Neovo F-17 User manual

Popular Monitor manuals by other brands

Linear Acoustic

Linear Acoustic LQ-1000 user guide

AOC

AOC I2579V user manual

Gateway

Gateway FPD1520 user guide

Furuno

Furuno Mu 120c Operator's manual

Asus

Asus VB171D - 17" LCD Monitor Service manual

Dell

Dell S2230MX Setting up

Philips

Philips 107C64 user manual

Dell

Dell S2409WFP user guide

EverFocus

EverFocus EN-7517E instruction manual

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Service manual

Dell

Dell Precision 7680 Connection guide

LG 50PM1M - - 50" Plasma Panel Service manual

Bosch

Bosch DDU 9 manual

Acer

Acer A231HL user manual

Philips

Philips 86BDL4152T user manual

NEC

NEC AccuSync LCD5V user manual

Emay

Emay SleepO2 user manual

IBM

IBM 6360 Product support manual
