AG Neovo SC-19P User manual

www.agneovo.com

A value 19” surveillance display

with rapid response time, quick

signal-switching and robust video

support for security and control

centre environments.

For a cost-eective surveillance display solution, look no further

than the AG Neovo SC-19P. A bright, high resolution full colour

screen with quick signal-switching and 3ms response time

ensures sharp, smooth video playback. Looping BNC video

inputs and NTSC/PAL support maximise exibility for system

integration. And with built-in speakers, stylishly slim prole and

VESA mountability, the SC-19P will look just as attractive as its

amazingly aordable price.

> High 1280 × 1024 SXGA resolution

> Anti-Burn-inTM technology

> Built-in Image Enhancer: 3D Comb Filter/Deinterlace/Noise Reduction

> Versatile connectivity (BNC in/out, S-Video, VGA, HDMI, Audio in/out)

> Looping BNC video inputs for multiple connections

> Quick signal-switching time ( ≤ 0.8 sec. )

> NTSC/PAL auto-detection

> Selectable signal source

> PC compatible

> Built-in speakers

> Key lock function

> Auto-adjustment for optimal setting

> Security socket

> VESA standard wall mount

> Tilt capacity from -2° ~ 20°

SC-19P

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: SC9P00 Version 1.1, 20140414

SC-19P

Stylish and slim design ideal for

professional security environments

Video versatility, including VGA, HDMI, S-Video

and BNC In/Out

Looping BNC video inputs allow multiple display

connections

Built-in speakers enable more rigorous

security monitoring

Specications SC-19P

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

LED-Backlit TFT LCD

19.0” (482.6mm)

SXGA 1280 x 1024

0.294 mm

250 cd/m2 (Typical)

1000:1 (Typical)

170°/160° (Typical)

16.7M

3 ms (GTG)

Horizontal

Resolution

TV Lines 600TVL (NTSC), 600TVL (PAL)

Frequency (H/V) H: 31.5 kHz - 80 kHz

V: 50 Hz - 75 Hz

Input Analogue

HDMI

CVBS

S-Video

15-Pin D-Sub

HDMI

BNC x 1

4-Pin mini DIN

Out CVBS BNC x 1

Audio Audio In

Audio Out

Speaker

3.5ø mm audio jack

1W x 2

Power Power Supply

Power Requirements

Consumption

Internal

100 ~ 240V, 50 - 60Hz

< 20 W (On)

< 0.5 W (Off)

Plug & Play VESA EDID

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

10% ~ 95%

Mounting VESA FPMPMI Yes (100 x 100mm)

Tilt Tilt -2° ~ 20°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

418.4 x 411.8 x 184mm

(16.5” x 16.2” x 7.2”)

464 x 585 x 121mm

(18.3” x 23.0” x 4.8”)

Weight Product Weight

Packaged Weight

3.6 kg (7.9 lbs)

4.4 kg (9.7 lbs)

Regulation

Approval

Certications &

Compliance

CB, FCC, CE, BSMI, GOST-R,

WEEE, RoHS

Accessories Supplied User manual, power cord,

15-Pin D-Sub cable, audio

cable, warranty card
