AG Neovo TM-27 User manual

www.agneovo.com

TM-27

Given its multi-touch capability and

a spacious screen size, the TM-27 is

specied for professional multi-user

interactive applications.

e TM-27, a multi-touch display built on state-of-the-art projected

capacitive technology, enables users to navigate the display

intuitively and precisely on a spacious screen. Highlighting its

10-point touch capability, multiple users can share the interactive

experience on the same screen simultaneously. Its versatile inputs

allow for eortless system integration. Leveraging a exible dual-

hinge stand, it provides height adjustability and a wide tilt range

that optimise multi-user comfort and productivity. A combination

of function and aesthetic, the TM-27 is suitable for a spectrum of

interactive environments where eciency is essential.

> MVA panel provides consistent and accurate colour from all viewing angles

> Incorporates Projected Capacitive Touch Technology

> 10-point touch capabilities for systems with Microso® Windows® 7 and 8

> LED-backlit technology with 1920 x 1080 Full HD resolution

> Flush touch screen makes surface neat and clean

> Connectivity: VGA, HDMI and DisplayPort

> Built-in USB Port (USB 3.0) for easy connection with peripheral devices

> HID compliant for easy integration without additional drivers

> Integrated 2M-pixel webcam

> Built-in speakers

> Flexible dual-hinge stand design to maximise viewing comfort for multiple users

> Tilt capacity from - 5o to 90o

> VESA standard wall mount

> Kensington® Security socket

Integration of 10-point touch and projected capacitive

touch technology provides accurate and precise touch

experience

Flexible dual-hinge stand design to maximise viewing

comfort for multiple users

Versatile connectivity: VGA, HDMI, DisplayPort and

USB port allow for eortless system integration

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: TM2700 Version 1.0, 20140219

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ration

Viewing Angle (H/V)

Disply Colour

Response Time (GTG)

LED-Backlit TFT LCD (MVA Panel)

27.0”

FHD 1920 x 1080

0.311 x 0.311

270 cd/m2 (Typical)

1,000 : 1 (Typical)

178°/178°

16.7 M

6 ms (GTG)

Frequency (H/V) H Freq.

V Freq.

30kHz – 83kHz

55Hz -75Hz

Input VGA

HDMI

DisplayPort

15-Pin D-Sub

HDMI

DisplayPort

USB Port USB Port USB 3.0 x 4

Audio Audio In

Speaker

1 x stereo audio in for PC

(audio jack, 3.5 Ø)

2 W x 2

Touch Screen Technology

Panel Interface

Projected Capacitive

USB (Type-B, HID compliant)

Web cam Resolution 2 Mega-pixel

Power Power Supply

Power Requirements

Consumption

Internal

100 ~ 240V, 50 - 60Hz

< 40W (On)

< 5W (Stand-by)

< 0.5W (Off)

Operating

Conditions

Temperature

Humidity

0°C ~ 40°C (32°F~104°F)

10% ~ 85% (No condensation)

Mounting VESA FPMPMI Yes (100mm x 100mm)

Dimensions with Base (W x D x H)

Packaging (W x H x D)

660mm x 328.5mm x 454mm

(26.0” x 12.9” x 17.9”)

753mm x 204mm x 527mm

(29.6” x 8.0” x 20.7”)

Weight Product Weight (with base)

Packaging Weight

11.0 kg (24.2 lbs)

12.8 kg (28.2 lbs)

Regulation

Approval

Certications &

Compliance

FCC, CB, CE, RoHS, GOST-R, WEEE,

REACH

Accessories Supplied CD ROM (user manual), warranty

card, power cord, 15-Pin D-Sub

cable, USB cable, Audio cable

TM-27

Specications TM-27

MVA panel provides superb clarity from all

viewing angles

- 5o to 90o
