C-17

Incredible value and performance: a

solid 17” display choice for reliability in

home and ofﬁce environments.

e highly-aordable C-17 oers the vivid image quality,

convenient inputs for analogue and digital signals, crisp 60,000:1

dynamic contrast ratio, as well as built-in speakers for multi-

media entertainment. With a sleek design and VESA compatible

wall mounts that allow for a variety of mounting options, the

C-17 is designed perfectly for home use or multi-display oce

environments where cost is a consideration.

> Slim and sleek design

> Economical and durable concern

> Fast 3ms response time

> Crisp 60,000:1 dynamic contrast ratio

> Built-in speakers

> Auto-adjustment for optimal viewing

> Kensington® security socket

> VESA standard wall mount

> WEEE, RoHS, REACH certied

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: C17000 Version 1.0 20110110

Sleek design with anti-glare display panel for

superior viewing comfort

VESA standard wall mount allows for secure

mounting almost anywhere

Built-in speakers provide easy access to multimedia

applications

Speciﬁcations C-17

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

TFT LCD

17.0” (432 mm)

SXGA 1280 x 1024

0.264 mm

250cd/m2 (Typical)

60,000:1 (DCR)

Hard Coating (3H),

Anti-glare treatment

160°/160° (Typical)

16.7M

3ms (GTG)

Frequency (H/V) H: 30 kHz - 83 kHz

V: 55 Hz - 75 Hz

Max. Pixel Clock 140 MHz

Input Analogue

Digital

15-Pin D-Sub

24-Pin DVI-D

Audio Audio In

Speaker

3.5mm Audio Line-in

1W x 2

Power AC-DC Adaptor

Power

Consumption

Internal

AC 100 - 240 V, 50 - 60 Hz

< 25 W (On)

< 1 W (Stand-by)

< 1 W (Off)

Plug & Play VESA DCC 2B

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-25 °C ~ 55 °C

5% ~ 85%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt -5° ~ +20°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

372 x 383 x 190 mm

(14.6” x 15.1” x 7.5”)

448 x 387 x 131 mm

(17.6” x 15.2” x 5.2”)

Weight Product Weight

Packaged Product Weight

3.9 kg (8.6 lbs)

5.4 kg (11.9 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC, CB, CE, WEEE, RoHS,

REACH

Accessories Supplied CD ROM (user manual), 15-Pin

D-Sub cable, audio cable, AC

power cord

C-17
