EN User Manual

Washer Dryer

LWX7E8622S

CONTENTS

1. SAFETY INFORMATION.............................................................................................3

2. SAFETY INSTRUCTIONS.............................................................................................6

3. INSTALLATION............................................................................................................7

4. PRODUCT DESCRIPTION.........................................................................................11

5. CONTROL PANEL..................................................................................................... 12

6. DIAL AND BUTTONS................................................................................................14

7. PROGRAMMES .........................................................................................................16

8. BEFORE FIRST USE................................................................................................... 21

9. SETTINGS...................................................................................................................21

10. DAILY USE - WASHING ONLY...............................................................................22

11. DAILY USE - WASHING & DRYING....................................................................... 27

12. DAILY USE - DRYING ONLY...................................................................................28

13. FLUFF IN THE FABRICS..........................................................................................29

14. HINTS AND TIPS..................................................................................................... 30

15. CARE AND CLEANING.......................................................................................... 32

16. TROUBLESHOOTING.............................................................................................36

17. CONSUMPTION VALUES.......................................................................................40

18. TECHNICAL DATA..................................................................................................41

19. ACCESSORIES.........................................................................................................41

20. ELECTROLUX / AEG MAJOR APPLIANCES - WARRANTY CONDITIONS........41

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com/webselfservice

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

www.aeg.com

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance,

carefully read the supplied instructions. The

manufacturer is not responsible for any injuries or

damages that are the result of incorrect installation or

usage. Always keep the instructions in a safe and

accessible location for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent

disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be

kept away unless continuously supervised.

•Children of less than 3 years of age should be kept

away unless continuously supervised.

•Do not let children play with the appliance.

•Keep all packaging away from children and dispose of

it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•If the appliance has a child safety device, it should be

activated.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

ENGLISH 3

1.2 General Safety

•Do not change the specification of this appliance.

•The appliance shall be installed as a freestanding

product or below the kitchen worktop if space

margins permit.

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite

side, that would prevent the appliance door from

being fully open.

•Connect the mains plug to the mains socket only at

the end of the installation process. Make sure that the

mains plug is accessible after installation.

•The ventilation opening in the base must not be

covered by a carpet, mat, or any floor covering.

•WARNING: The appliance must not be supplied

through an external switching device, such as a timer,

or connected to a circuit that is regularly switched on

and off by a utility.

•Ensure good air ventilation in the room where the

appliance is installed to avoid the backflow of

unwanted gases into the room from appliances

burning gas or other fuels, including open fires.

•Exhaust air must not be discharged into a flue which is

used for exhausting fumes from any appliances

burning gas or other fuels.

•The operating water pressure at the water entry point

from the outlet connection must be between 0.5 bar

(0.05 MPa) and 8 bar (0.8 MPa).

•Do not exceed the maximum load of 8 kg (refer to the

"Programme chart" chapter).

•The appliance must be connected to the water mains

using the new supplied hose sets, or other new hose

sets supplied by the Authorised Service Centre.

•Old hose sets must not be reused.

•If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised

www.aeg.com

Service Centre or similarly qualified persons to avoid

an electrical hazard.

•Wipe away lint or packaging debris that has

accumulated around the appliance.

•Items that have been soiled with substances such as

vegetable or mineral oil, acetone, alcohol, petrol,

kerosene, spot removers, turpentine, waxes and wax

removers should be washed separately with an extra

amount of detergent before being dried in the washer

dryer.

•Do not use the appliance if items have been soiled

with industrial chemicals.

•Do not dry unwashed items in the wash dryer.

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, and rubber backed articles and

clothes, or pillows fitted with foam rubber pads should

not be dried in the washer dryer.

•Fabric softeners, or similar products, should only be

used as specified by the product manufacturer’s

instructions.

•Remove all objects from items that could be a source

of fire ignition such as lighters or matches.

•Never stop the washer dryer before the end of the

drying cycle unless all items are quickly removed and

separated so that residual heat can dissipate.

•The final part of the washer dryer cycle takes place

without heat (cool down cycle) to ensure that items

reach a temperature that will not cause damage to

them.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•Clean the appliance with a moist cloth. Use only

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

ENGLISH 5

2. SAFETY INSTRUCTIONS

2.1 Installation

• Follow the installation instruction

supplied with the appliance.

• Do not install or use the appliance

where the temperature can be less

than 0°C or where it is exposed to the

weather.

• Always keep the appliance vertical

when being moved.

• Make sure that there is air circulation

between the appliance and the floor.

• Remove all the packaging and the

transit bolts.

• The floor area where the appliance is

to be installed must be flat, stable,

heat resistant and clean.

• Keep the transit bolts in a safe place.

If the appliance is to be moved in

future they must be reattached to lock

the drum to prevent internal damage.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use a damaged

appliance.

• Do not install the appliance where the

appliance door cannot be fully

opened.

• Adjust the feet to have the necessary

space between the appliance and the

flooring.

• When the appliance is in its

permanent position, check that it is

fully level with the aid of a spirit level.

If it is not, adjust the feet accordingly.

2.2 Electrical Connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the

E.E.C. Directives.

2.3 Water Connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes,

pipes not used for a long time, where

repair work has been carried out or

new devices fitted (water meters,

etc.), let the water flow until it is clean

and clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

2.4 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

• This appliance is for household use

only.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Do not touch the glass door while a

programme is in operation. The glass

can get hot.

• Do not dry damaged (torn, frayed)

items that contain padding or fillings.

• If laundry has been washed with a

stain remover, carry out an additional

rinse cycle before starting a drying

cycle.

• Make sure that all metal objects are

removed from the laundry.

• Only dry fabrics that are suitable to

dry in the washer dryer. Follow the

cleaning instruction on the item label.

• Plastic items are not heat resistant.

– If a detergent ball is used, remove

it before starting a drying

programme.

– Do not use a detergent ball if

setting a non-stop programme.

WARNING!

Risk of injury or damage to

the appliance.

• Do not sit or stand on the open door.

www.aeg.com

• Do not dry dripping wet clothes in the

appliance.

2.5 Disposal

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of

it.

• Remove the door catch to prevent

children or pets from becoming

trapped in the drum.

• Dispose of the appliance in

accordance with local requirements

for the disposal of Waste Electrical

and Electronic Equipment (WEEE).

3. INSTALLATION

WARNING!

Refer to Safety chapters.

3.1 Unpacking

WARNING!

Remove all the packaging

and the transit bolts before

installing the appliance.

WARNING!

Use the gloves.

1. Remove the external film. If

necessary, use a cutter.

2. Remove the cardboard top and the

polystyrene packaging materials.

3. Remove the internal film.

4. Open the door and remove the

polystyrene piece from the door seal

and all the items from the drum.

5. Carefully put down the appliance

with the rear side on it.

6. Put the front polystyrene packaging

element on the floor under the

appliance.

Make sure not to

damage the hoses.

ENGLISH 7

7. Remove the polystyrene protection

from the bottom.

8. Pull up the appliance in vertical

position.

9. Remove the power supply cable and

the drain hose from the hose holders.

It is possible to see

water flowing from the

drain hose. This is due to

the testing with water of

the appliance in factory.

10. Remove the three bolts by using the

key supplied with the appliance.

11. Pull out the plastic spacers.

12. Put the plastic caps, that you find in

the user manual bag, in the holes.

We recommend that you

keep the packaging and the

transit bolts for any

movement of the appliance.

3.2 Positioning and levelling

1. Install the appliance on a flat hard

floor.

Make sure that carpets do

not stop the air circulation

below the appliance.

Make sure that the

appliance does not touch

the wall or other units.

2. Loosen or tighten the feet to adjust

the level.

www.aeg.com

WARNING!

Do not put cardboard, wood

or equivalent materials

below the appliance feet to

adjust the level.

The appliance must be level and stable.

A correct adjustment of the

appliance level prevents the

vibration, noise and the

movement of the appliance

when in operation.

When the machine is

installed on a plinth or if a

washer dryer is stacked on

the washing machine, use

the accessories described in

chapter 'Accessories'. Read

carefully the instructions

supplied with the appliance

and with the accessory.

3.3 The inlet hose

1. Connect the water inlet hose to the

back of the appliance.

2. Position it toward left or right

depending on the position of the

water tap.

20O

45O

Make sure that the inlet hose

is not in vertical position.

3. If necessary, loose the ring nut to set

it in the correct position.

4. Connect the water inlet hose to the

cold water tap with 3/4" thread.

CAUTION!

Make sure that there are no

leaks from the couplings.

Do not use an extension

hose if the inlet hose is too

short. Contact the service

centre for the replacement

of the inlet hose.

3.4 Water-stop device

The inlet hose has a water stop device.

This device prevents water leaks in the

hose because of its natural ageing.

The red sector in the window «A» shows

this fault.

ENGLISH 9

If this occurs, close the water tap and

contact the authorized service centre to

replace the hose.

3.5 Water drainage

The drain hose should stay at a height of

not less than 60 cm and not more than

100 cm.

You can extend the drain

hose to maximum 400 cm.

Contact the authorized

service centre for the other

drain hose and the

extension.

It is possible to connect the drain hose in

different ways:

1. Make a U shape with the drain hose

and put it around the plastic hose

guide.

2. On the edge of a sink - Fasten the

guide to the water tap or to the wall.

Make sure that the plastic

guide cannot move when

the appliance drains.

Make sure that the drain

hose end is not immersed in

the water. There may be a

return of dirty water into the

appliance.

3. To a stand pipe with vent-hole -

Insert the drain hose directly into a

drain pipe. Refer to the illustration.

The end of the drain hose

must always be ventilated ,

i.e. the inner diameter of the

drain pipe (min. 38 mm -

min. 1.5") must be larger

than the external diameter

of the drain hose.

4. If the end of the drain hose looks like

this (see the picture), you can push it

directly into the stand pipe.

www.aeg.com

Table of contents

Popular Washer Dryer manuals by other brands

Whirlpool

Whirlpool WFC8090GX Use and care guide and installation instructions

Whirlpool

Whirlpool LTE5243DQ6 User instructions

Bosch

Bosch XQG100-WDU285H00W User manual and installation instructions

montpellier

montpellier MWD7512S Installation and operating instructions

LG FHD0905 T Series owner's manual

Midea

Midea MF200D85B owner's manual

Maytag

Maytag MGT3800XW installation instructions

Siemens

Siemens WD15G440TR Instruction manual and installation instructions

Equator

Equator Clothes Processor EZ1500 owner's manual

Splendide

Splendide WDC7100XCP Specifications

John Lewis

John Lewis JLWD 1408 instruction manual

Ariston

Ariston A1200WD Instruction booklet

Whirlpool

Whirlpool YLTE5243DQ5 installation instructions

Whirlpool

Whirlpool WFCR 75230 Health & safety, use & care and installation guide

ATT

ATT Hammer Jet v1 operating manual

Electrolux

Electrolux EWW8024P5WB user manual

GE GTD42EASJWH owner's manual

LG F2721HVRB owner's manual
