Installation, 2-3

Unpacking

Remove the transit fixings

Levelling

Water connections

Drainage and electrical connections

Technical details

Washer dryer description, 4-5

Control panel

LEDs

Starting and programmes, 6-9

Briefly: how to start a programme

Programmes table

Setting the temperature

Setting the spin speeds

Functions

Drying section

Detergents and laundry, 10

Detergent dispenser

Preparing your laundry

Special items

Precautions and Advice, 11

General safety

Disposal

Saving energy and respecting the environment

Care and Maintenance, 12

Switching off the water or electricity supply

Cleaning

Caring for your appliance door and drum

Checking the water inlet hoses

Fuses

Changing the plug

Troubleshooting, 13-14

Service, 15

Before calling for assistance

Spare parts

English

!Packaging materials are not childrens toys.

Levelling

1. Install the machine on a flat sturdy floor, without

resting it up against walls, cabinets etc.

2. Compensate for any unevenness by tightening or

loosening the adjustable front feet. When adjusting

the feet, use a spirit level to check the machine

stands level, from side to side and from front to

back.

Levelling your appliance correctly will provide it with

stability and avoid any vibrations, noise and shifting

during operation. If it is placed on a fitted or loose

carpet, adjust the feet in such a way as to allow

enough room for ventilation beneath the machine.

Water connection

Connecting the water inlet hose.

Remember that this is a cold-fill machine and the fill

hose fitted to the rear of the machine must be

connected to the cold water supply.

Before making the connections to the water outlet,

allow the water to run freely from the cold water

supply tap until it is perfectly clear.

Screw the cold water fill hose

onto the cold water supply tap

until tight.

Turn the tap on and check for leaks:

tighten if necessary.

!Make sure there are no kinks or bends in the hose.

!The water pressure at the tap must be within the values

indicated in the Technical details table (next page).

!If the water inlet hose is not long enough, contact a

specialist store or an authorised serviceman.

!Always use new hoses.

!Check the water hose at least once a year, replace

any that are cracked as worn hoses could split under

water pressure.

Installation

GB !Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction manual

accompanies the washer dryer to inform the new

owner as to its operation and features.

!Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking

1. Unpack the machine.

2. Check whether the washer dryer has been

damaged during transport. If this is the case, do not

install it and contact your retailer.

Remove the transit fixings

IMPORTANT: Follow these instructions to remove the

TWO transit fixings.

Situated one either side of the

rear panel, BOTH transit bolts

MUST be removed before use.

!Failure to do so may cause

damage to your machine.

It is important the transit bolt and

spacer (see pic) come out intact.

1. Unscrew the bolt using a

13mm spanner.

2. STOP when 3 threads can be

seen.

3. Hold, slide sideways and pull

to remove.

4. For safety, insert one of the

plastic covers (supplied with

your machine) over the hole.

!Repeat steps 1 to 4 to remove

the second transit bolt.

The first wash cycle

Once the appliance has been installed and before you

use it for the first time, run a wash cycle without

detergent and no laundry, setting the 90˚C

programme without a pre-wash cycle.

Models A1600WD, A1400SWD,

A1400WD, A1200WD

59.5cm wide

Dimensions 85cm high

60cm deep

Capacity from 1 to 6kg

Electric voltage 220/240 Volts 50Hz

connections maximum absorbed power:

1700W-2100W

Water maximum pressure 1 MPa (10 bar)

connections minimum pressure 0.05 MPa (0.5 bar)

drum capacity 53 litres

Spin Speed up to 1600 rpm - A1600WD

up to 1400 rpm - A1400SWD,

A1400WD

up to 1200 rpm - A1200WD

Control programme 3

programmes temperature 60˚C

according to

IEC50229 - dry run with a 1kg load followed by

directive a 5kg load for model A1600WD

-dry run with a 2kg load followed by

a 4kg load for models A1400SWD,

A1400WD and A1200WD

This appliance is compliant with the

following European Community

Directives:

- 72/23/CEE of 19/02/73

(Low Voltage) and subsequent amendments.

- 89/336/CEE of 03/05/89 (Electromagnetic

Compatibility) and subsequent amendments.

Drainage connections

A. Connect the drain

hose, without kinking it,

to a draining duct or a

wall drain fixed at a

height between 65 and

100cm from the floor.

Use the curved bracket,

if reqired.

B. Alternatively, place

it over the edge of a

basin, sink or tub,

fastening the hose

supplied to the tap.

!The free end of the hose should not be under water.

!We advise against the use of hose extensions. In

case of absolute need, the extension must have the

same diameter as the original hose and must not

exceed 150cm in length.

Electrical connections

Before plugging the appliance into the mains socket,

make sure that:

●the socket is earthed and in compliance with the

applicable law.

●the socket is able to sustain the appliances

maximum power load indicated in the Technical

Details table (on the right).

●the supply voltage is included within the values

indicated in the Technical Details table (on the

right).

●the socket is compatible with the machines plug.

If this is not the case, replace the socket or the

plug.

!The machine should not be installed in an outdoor

environment, not even when the area is sheltered,

because it may be very dangerous to leave it exposed

to rain and thunderstorms.

!When the machine is installed, the mains socket

must be within easy reach and should be connected

to a suitable electrical supply.

!Do not use extensions or multiple sockets.

!The power supply cable must never be bent or dan-

gerously compressed.

!The power supply cable must only be replaced by

an authorised serviceman.

!The company denies all liability if and when these

norms are not respected.

Technical Details

Installation

Washer Dryer Description

GB Control panel - Models A1600 and A1400

Control panel - Model A1200

TEMPERATURE knob:

To set the temperature or the cold wash cycle (see

Starting and Programmes).

ON/OFF button:

To turn the machine on and off.

START/RESET button:

To start the programme or cancel any incorrect

settings.

ON-OFF/DOOR LOCK LED:

To find out whether the machine is on and if the

appliance door can be opened.

PROGRAMME knob:

To select the programme you require.

The retractable control knob: press the centre of the

knob for it to pop out. The knob stays still during the

cycle.

Detergent dispenser:

To add detergent and fabric softener (see Detergents

and Laundry).

Programme key:

To consult a straightforward chart of the different

programmes available.

PROGRESS INDICATOR LEDs:

To find out which cycle phase is under way.

The corresponding LED for the cycle in progress is

illuminated.

DRYING knob:

A1200 - To set the drying time

A1400 - To set the drying time and single level auto

dry.

A1600 - To set the drying time and 3 level auto drying

(see Starting and Programmes).

FUNCTION buttons:

To select the functions available (see Starting and

Programmes).

When a function is selected, the corresponding

LED is illuminated.

Programme key

Detergent dispenser DRYING

Knob

TEMPERATURE

Knob

PROGRESS INDICATOR

LEDs

PROGRAMME

Knob

ON-OFF/DOOR LOCK

LED

START/RESET

Button

FUNCTION

Buttons ON/OFF

Button

Programme key

Detergent dispenser DRYING

Knob

TEMPERATURE

Knob

PROGRESS INDICATOR

LEDs

PROGRAMME

Knob

ON-OFF/DOOR LOCK

LED

START/RESET

Button

FUNCTION

Buttons ON/OFF

Button

LEDs

PROGRESS INDICATOR LEDs:

These light up to indicate the

progress of the selected

programme.

When the programme is started

the light corresponding to the

first cycle is lit and as the

programme progresses,

successive lights will come on

until the programme finishes.

FUNCTION buttons / LEDs:

When a function is selected, the corresponding

LED is illuminated.

●If the function selected is incompatible with the

programme set, the button will flash and the function

will not be enabled.

●If you set a function that is incompatible with

another function you selected previously, only the

last one selected will be enabled.

ON-OFF/DOOR LOCK LED:

If this LED is on, the appliance door is locked to

prevent it from being opened accidentally; to avoid

any damage. Wait for the LED to flash before you

open the appliance door.

!The rapid flashing of the ON-OFF/DOOR LOCK LED

together with the flashing of at least one other LED

indicates there is an error. Call for Technical

Assistance.

Additional feature - Models A1600WD, A1400SWD

and A1400WD only:

Your machine has a delay timer function and there are

additional markings alongside the LEDs.

DELAY TIMER set:

If the Delay Timer function

has been enabled (see

Starting and

Programmes), once you

start the programme the

LED corresponding to the

delay set will begin to

flash.

As time passes, the

remaining delay will be

displayed and the

corresponding LED will

flash:

Once the set delay is complete, the flashing LED will

turn off and the selected programme will start.

Automatic Rinse hold

●Models A1600 and A1400

Note: If you have selected a synthetic wash

programme, the machine will automatically stop in

the final rinse and the LED will flash, press the

START/RESET button to continue to the end of

the programme (wash programme only).

If drying option has been selected the machine

will complete the programme without any interruption.

●Model A1200

Note: If you have selected a synthetic wash

programme together with the reduced creases

option, the machine will automatically stop in

the final rinse and the LED will flash, press the

START/RESET button to continue to the end of

the programme (wash or wash and dry

programme).

Washer Dryer Description

Starting and Programmes

5. Set the spin speed (see Personalisation).

6. Add the detergent and any fabric softener (see

Detergents and Laundry).

7. Start the programme by pressing the

START/RESET button for at least 2 seconds.

8. When the programme is finished, the

ON-OFF / DOOR LOCK LED will flash to indicate

that the appliance door can now be opened.

Take out your laundry and leave the appliance door

ajar to allow the drum to dry thoroughly. Turn the

machine off by pressing the ON/OFF button , the

ON/OFF / DOOR LOCKED LED will go out.

Briefly: starting a programme

1. Switch the machine on by pressing the ON/OFF

button , for at least 2 seconds. All the LEDs will

light up for a few seconds and the ON-OFF / DOOR

LOCK LED will begin to flash.

2. Load your laundry into the machine and shut the

door.

3. Set the PROGRAMME knob to the programme

required.

4. Set the wash temperature (see Personalisation).

Notes

For the anti-crease function: see Easy Iron (next page). The information contained in the table is purely indicative.

All cycle length times are approximate.

Special programmes

Daily 30' (programme 8 for Synthetics) is designed to wash lightly soiled garments in a short amount of time: it

only lasts 36 minutes and allows you to save on both time and energy. By setting this programme (8 at 36˚C),

you can wash different fabrics together (except for woollen and silk items), with a maximum load of 3kg.

●We recommend the use of liquid detergent.

Programme table

Type of fabric and

degree of soil

Cottons

Synthetics

Description of washing cycleProgrammes Wash

Temperature

Detergent

Pre-

wash Wash

Fabric

softener

Cycle length

(minutes)

Extremely soiled whites

(sheets, tablecloths, etc)

Extremely soiled whites

(sheets, tablecloths, etc)

90˚

60˚

90˚ 155

137

105

40˚

●● ●

Heavily soiled fast colours

(baby linen, etc) 6 50˚ 84

●●

Pre-wash, wash cycle, rinse cycles,

intermediate and final spin cycles.

Wash cycle, rinse cycles, anti-crease

or delicate spin cycle.

Fast colours (all types of

slightly soiled garment) 7 40˚ 70

●● Wash cycle, rinse cycles, anti-crease

or delicate spin cycle.

Delicate colours (all types

of slightly soiled garments 8

30˚ 36

120 (max.)

180 (max.)

●● Wash cycle, rinse cycles and delicate

spin cycle.

Synthetic - Drying

Delicate

Wool 10 40˚ 38

●● Wash cycle, rinse cycles, and delicate

spin cycle.

Very delicate fabrics

(curtains, silk, viscose, etc)

Rinse

Delicate rinse cycle

Spin cycle

Delicate spin cycle

Draining

11 30˚ 54

●● Wash cycle, rinse cycles, anti-crease

or draining cycle.

Rinse cycles and spin cycle.

●

Rinse cycles, anti-crease or draining.

●

Draining and heavy duty spin cycle.

Draining and delicate spin cycle.

Draining

Wash cycle, rinse cycles, intermediate

and final spin cycles.

High Heat drying programme - A1600.

High Heat drying programme - A1400/A1200.

Wash cycle, rinse cycles, intermediate

and final spin cycles.

Wash cycle, rinse cycles, intermediate

and final spin cycles.

Heavily soiled whites

and fast colours

Heavily soiled whites

and non-fast colours

Cotton - Drying

PARTIAL PROGRAMMES

120 (max.)

180 (max.)

Low Heat drying programme - A1600.

Low Heat drying programme - A1400/A1200.

Functions

To enable a function:

1. press the button corresponding to the desired

function, according to the table below.

2. the function is enabled when the corresponding

LED is illuminated.

●The rapid flashing of the button indicates that the

corresponding function cannot be selected for the

programme set.

Setting the temperature

Turn the TEMPERATURE knob to set the wash

temperature (see Programme table).

The temperature can be lowered, or even set to cold

wash .

Setting the spin speed

Models A1600 and A1400 only:

Use the ‘Reduced Spin’ Option button, to reduce

programme spin speed to 1000rpm (cottons

programmes).

The maximum spin speeds for each programme are

as follows:

Programmes Maximum spin speed

Cottons 1600rpm - Model A1600WD

1400rpm - Models A1400SWD

and A1400WD

1200rpm - Model A1200WD

Synthetics 800rpm

Wool 600rpm

Silk no

Personalisation

Function Effect Comments Enabled with

programmes

All programmes

(Models

A1600WD,

A1400SWD and

A1400WD only)

Delay Timer

Delays the start

of the wash by

up to 9 hours.

Press the button repeatedly until the LED corresponding to the

desired delay is turned on.

The fifth time the button is pressed, the function will be disabled.

N.B.: Once you have pressed the START/RESET button, the

delay can only be decreased if you wish to modify it.

1, 2, 3, 6, 7.

Super Wash

Allows for an

impeccable wash,

visibly whiter than

a standard Class

Awash.

This function is incompatible with the RAPID function.

1, 2, 3, 6, 7.

Rapid

Cuts the duration

of the wash cycle

by 30%.

This function is incompatible with the SUPER WASH function.

All programmes

except for 1, 2,

4, 8, 9, 10 and

Draining

(Model

A1200WD only)

Easy Iron

This option

reduces the

amount of

creasing on

fabrics, making

them easy to iron.

When this function is set, programmes 6, 7, 11 and Delicate

rinse will end with the laundry left to soak (Anti-crease) and the

Rinse cycle phase LED will flash.

- to conclude the cycle, press the START/RESET button.

- to run the draining cycle alone, set the knob to the relative

symbol and press the START/RESET button.

1, 2, 3, 4

(Models

A1600WD,

A1400SWD and

A1400WD only)

Reduced Spin

Reduces the final

spin speed to

1000rpm

Reduces the final spin speed on cotton programmes.

1, 2, 3, 4, 6, 7.

(Model

A1200WD only)

Extra Rinse

Adds one extra

rinse cycle. Remember - you will use more water than with a standard

cycle.

Drying Section

GB !If your machine is not permanently plumbed in, turn

on the cold water supply and hook the drain hose

over the sink to enable the condensing action to work.

!The dryer is intended for use only where water is

used for the cleaning process.

!Be careful not to touch the drum at the top as this

area does get hot during drying.

!On no account should liquid fabric conditioner be

added during the drying process.

!Misuse of the dryer may create a fire hazard.

Drying programmes

Independent drying programme:

1. Remove the wet laundry and in drum dosing ball (if

used) until the correct ‘Drying Weight Load’ (see

table below) is left in the drum. Close the door until

it clicks shut.

2. Select a drying programme (see Programmes):

- 5 High Heat for cottons or

- 9 Low Heat for synthetics

3. Set the required dry time or sensor dry option.

(Sensor dry option only available on Models A1600

and A1400).

4. When all selections have been made press the

START/RESET button.

Timed dry:

Select from the following times:

A1600 0 - 30 - 60 - 90 - 120 minutes

A1400 0 - 30 - 60 - 90 - 120 - 150 - 180 minutes

A1200 0 - 30 - 60 - 90 - 120 - 140 - 160 - 180 minutes

Sensor dry (Models A1600 and A1400 only):

A1600 Select sensor dry level from:

‘Cupboard dry’

‘Hanger dry’

‘Iron dry’

A1400 Select sensor dry level, ‘Hanger dry’.

Programme Heat Setting Fabric Maximum Drying Weight load

Drying heat:

High Cottons

Synthetics

Low

5kg (Model A1600)

4kg (Models A1400 and A1200)

3kg

Important information:

A 20 minute ‘cool tumble’ is included at the end

of drying, allowing fabrics to cool down, minimising

creasing.

A spin cycle may be carried out during drying if

you have set a cotton programme.

The sensor dry function can be used on either the

cotton (HIGH heat) or synthetic (LOW heat)

programmes (Models A1600 and A1400 only).

Your machine is fitted with a revolutionary self-

clean filter, which will flush with water during

drying.

Drycare tips

Items not suitable for tumble drying:

●

Garments with the ITCL code - .

●

Woollens.

●

Large, bulky items eg. quilts, bedspreads,

pillows etc... expand when dry, preventing air

flow through the appliance.

●

Items containing plastic film, foam rubber or

rubber like materials eg. pillows, cushions, PVC

rainwear or inflammable articles which contain

inflammable substances eg. towels contaminated

with hair lacquer.

●

Fibreglass (eg. some types of curtains).

●

Items which have been dry cleaned.

A typical wash and dry programme:

1. Sort your laundry into groups with the same wash

and dry care labels.

2. Load the machine, making sure that items are not

trapped in the door. Close the door by pushing it

until it clicks.

3. Add detergent and fabric conditioner (if required), to

the dispenser drawer. Refer to the detergent

manufacturer’s dosage instructions.

4. Switch the machine on by pressing the ON/OFF

button. The ON-OFF/DOOR LOCKED LED will

illuminate.

5. Select desired wash programme (see Programmes).

6. Select any optional wash feature(s) that you may

require by pressing the appropriate button(s) (see

Function chart). The corresponding LED will

illuminate to show what you have chosen.

7. Select either the ‘Timed’ or ‘Sensor’ dry option you

require (Sensor dry is only available on Models

A1600 and A1400).

8. Press the START/RESET button to begin the

programme.

- During the programme status lights will illuminate

to indicate what stage in the cyle the programme

has reached.

9. When the programme has finished the

ON-OFF / DOOR LOCK LED will flash to indicate

that the appliance door can now be opened.

Take out your laundry and leave the appliance

door ajar to allow the drum to dry thoroughly. Turn

the machine off by pressing the ON/OFF button ,

the ON/OFF / DOOR LOCKED LED will go out.

Drying Section

Detergent dispenser

!Do not put any items into the drawer, other than

detergents designed to be released from the drawer,

as they may cause damage or blockage.

1. Pre-wash detergent

compartment.

Maximum 200ml powder

or 100ml liquid

2. Main wash detergent

compartment.

Maximum 400ml powder

or 200ml liquid

3. Fabric conditioner

compartment.

Maximum 120ml

Dispensing powder detergent

To achieve the best wash results the maunfacturer’s

recommended amount of detergent should be measured

and added to the main detergent compartment.

Dispensing liquid detergent

We recommend the use of a detergent dosing ball, as

provided by your detergent manufacturer.

Adding fabric conditioner

Pour the recommended amount of fabric conditioner

into the compartment. Do not exceed the maximum fill

line.

Maximum load size

●Divide your laundry according to:

- the type of fabric/the symbol on the label.

- the colours: separate coloured garments from

whites.

●Empty all pockets and check for loose buttons.

●Do not exceed the weight limits stated below,

which refer to the weight when dry:

Sturdy fabrics: max 6kg

Synthetic fabrics: max 3kg

Delicate fabrics: max 3kg

Wool: max 1.5kg

!DO NOT overload the machine as this could result in

reduced performance.

How much does your laundry weigh?

1 sheet 400-500g

1 pillow case 150-200g

1 tablecloth 400-500g

1 bathrobe 900-1200g

1 towel 150-250g

Special items

Curtains: fold curtains and place them in a pillow

case or mesh bag. Wash them separately without

exceeding half the appliance load. Use programme

11 which excludes the spin cycle automatically.

Quilted coats and windbreakers: if they are padded

with goose or duck down, they can be machine-

washed. Turn the garments inside out and load a

maximum of 2-3kg, repeating the rinse cycle once or

twice, using the delicate spin cycle.

Trainers: remove any mud. They can be washed

together with jeans and other tough garments, but not

with whites.

Wool: for best results, use a specific detergent, taking

care not to exceed a load of 1.5kg.

Detergents and Laundry

This manual suits for next models

Table of contents

Other Ariston Washer Dryer manuals

Ariston

Ariston AQUALTIS AQM9D 29 U User manual

Ariston

Ariston AQUALTIS AQM9D 29 U User manual

Ariston

Ariston Margherita AWD 12 User manual

Ariston

Ariston AWD 129 User manual

Ariston

Ariston MARGHERITA User manual

Ariston

Ariston ARWDF 129 User manual

Ariston

Ariston RDPD 107407 User manual

Ariston

Ariston AL 128 DS User manual

Ariston

Ariston AW122 Guide

Ariston

Ariston AQGMD 129/A User manual

Ariston

Ariston fgd9620 User manual

Ariston

Ariston CAWD 125 User manual

Ariston

Ariston Margherita AWD 12 User manual

Ariston

Ariston WDG 8629 User manual

Ariston

Ariston AML 119 User manual

Ariston

Ariston AQD1170D 49 User manual

Ariston

Ariston AML 129 User manual

Ariston

Ariston AWD 121 User manual

Ariston

Ariston AW122 Guide

Ariston

Ariston AML 125 User manual

Ariston

Ariston AWD 1200 Instructions for and use User manual

Ariston

Ariston AWD 121 NA User manual

Ariston

Ariston BHWD 125 User manual

Ariston

Ariston AML 125 User manual

Popular Washer Dryer manuals by other brands

Whirlpool

Whirlpool WFC8090GX Use and care guide and installation instructions

Whirlpool

Whirlpool LTE5243DQ6 User instructions

Bosch

Bosch XQG100-WDU285H00W User manual and installation instructions

montpellier

montpellier MWD7512S Installation and operating instructions

LG FHD0905 T Series owner's manual

Midea

Midea MF200D85B owner's manual

Maytag

Maytag MGT3800XW installation instructions

Siemens

Siemens WD15G440TR Instruction manual and installation instructions

Equator

Equator Clothes Processor EZ1500 owner's manual

Splendide

Splendide WDC7100XCP Specifications

John Lewis

John Lewis JLWD 1408 instruction manual

Whirlpool

Whirlpool YLTE5243DQ5 installation instructions

Whirlpool

Whirlpool WFCR 75230 Health & safety, use & care and installation guide

ATT

ATT Hammer Jet v1 operating manual

AEG

AEG LAVAMAT 63742 VI Instruction booklet

Electrolux

Electrolux EWW8024P5WB user manual

GE GTD42EASJWH owner's manual

LG F2721HVRB owner's manual
