AEG Electrolux 88031K-MN User manual

88031K-MN

User manual Ceramic glass induction

hob

Thank you for choosing one of our high-quality products.

To ensure optimal and regular performance of your appliance please read this

instruction manual carefully. It will enable you to navigate all processes perfectly

and most efficiently. To refer to this manual any time you need to, we recommend

you to keep it in a safe place. And please pass it to any future owner of the appliance.

We wish you much joy with your new appliance.

Contents

Operating Instructions 2

Safety information 2

Description of the appliance 4

Operating the appliance 6

Tips on cooking and frying 11

Cleaning and care 13

What to do if ... 14

Disposal 16

Installation Instructions 16

Safety information 16

Service 18

Warranty 19

Subject to change without notice

Operating Instructions

Safety information

WARNING!

Please comply with these instructions. If you do not, any damage resulting is not covered

by the warranty.

Correct use

• This appliance is not intended for use by children or other persons whose physical, sensory

or mental capabilities or lack of experience and knowledge prevents them from using

the appliance safely without supervision or instruction by a responsible person to ensure

that they can use the appliance safely.

• Do not leave the appliance unattended during operation.

• This appliance should be used only for normal domestic cooking and frying of food.

• The appliance must not be used as a work surface or as a storage surface.

• Additions or modifications to the appliance are not permitted.

• Do not place or store flammable liquids, highly inflammable materials or fusible objects

(e.g. plastic film, plastic, aluminium) on or near the appliance.

Children’s safety

• Small children must be kept away from the appliance.

• Only let bigger children work on the appliance under supervision.

2Contents

• To avoid small children and pets unintentionally switching the appliance on, we recom-

mend activation of the child safety device.

General safety

• The appliance may only be installed and connected by trained, registered service engi-

neers.

• Built-in appliances may only be used after they have built in to suitable built-in units

and work surfaces that meet standards.

• In the event of faults with the appliance or damage to the glass ceramic (cracks, scratches

or splits), the appliance must be switched off and disconnected from the electrical supply,

to prevent the possibility of an electric shock.

• Repairs to the appliance must only be carried out by trained registered service engineers.

Safety during use

• Remove stickers and film from the glass ceramic.

• There is the risk of burns from the appliance if used carelessly.

• Cables from electrical appliances must not touch the hot surface of the appliance or hot

cookware.

• Overheated fats and oils can ignite very quickly. Warning! Fire hazard!

• Switch the cooking zones off after each use.

• Users with implanted pacemakers should keep their upper body at least 30 cm from

induction cooking zones that are switched on.

• Risk of burns! Do not place objects made of metal, such as knives, forks, spoons and

saucepan lids on the cooking surface, as they can get hot.

Safety when cleaning

• For cleaning, the appliance must be switched off and cooled down.

• For safety reasons, the cleaning of the appliance with steam jet or high-pressure cleaning

equipment is not permitted.

How to avoid damage to the appliance

• The glass ceramic can be damaged by objects falling onto it.

• The edge of the glass ceramic can be damaged by being knocked by the cookware.

• Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch the

glass ceramic if pushed across the surface.

• Objects that melt and things that boil over can burn onto the glass ceramic and should

be removed straightaway.

• Do not use the cooking zones with empty cookware or without cookware.

• To avoid damaging cookware and glass ceramics, do not allow saucepans or frying pans

to boil dry.

• The ventilation gap of 5mm between the worktop and front of the unit underneath it

must not be covered.

Safety information 3

Description of the appliance

Cooking surface layout

180 mm

145 mm

210 mm

180 mm

1 2

4 3

1Induction cooking zone 1850 W, with power function 2500 W

2Induction cooking zone 1400 W, with power function 1800 W

3Induction cooking zone 1850 W, with power function 2500 W

4Induction cooking zone 2300 W, with power function 3700 W

5Control Panel

Control panel layout

1 2 3 4

89 7 6 5

1Child lock with display

2Cooking zone indicators - Timer function

3Timer display

4Power function

5Heat setting indicator

6Heat setting selection

7Timer

8STOP+GO with indicator

9On/Off with indicator

4Description of the appliance

Touch Control sensor fields

The appliance is operated using Touch Control sensor fields. Functions are controlled by

touching sensor fields and confirmed by displays and acoustic signals. Only touch the sensor

fields which activate a desired function. Do not cover other sensor fields.

If the control bar is touched for longer than 6 seconds, a signal sounds and the appliance

switches itself off.

Sensor field Function

On / Off Switches appliance on and off

Child lock Locking control panel for children

STOP+GO To switch the Keep Warm setting on/ off

Power Switching the power function on and off

Timer Timer selection

Increase settings To increase Timer time

Reduce settings To reduce Timer time

Displays

Display Description

The cooking zone is switched off

Keep Warm settings Keep Warm / STOP+GO function is switched on

- Heat settings To set heat settings

Auto Warm-up The Auto Warm-up function is switched on

+ digit Fault Malfunction has occurred

Pan detection Cookware is unsuitable or too small or no cookware

has been placed on the cooking zone

Residual heat Cooking zone is still hot

Child safety device Lock/Child safety device is set

Power Power function is switched on

Automatic Switch off Switch off is active

Residual heat indicator

WARNING!

Risk of burns from residual heat. After being switched off, the cooking zones need some

time to cool down. Look at the residual heat indicator .

Residual heat can be used for melting and keeping food warm.

The induction cooking zones create the heat required for cooking directly in the base of

the cookware. The glass ceramic is merely heated by the residual heat of the cookware.

Description of the appliance 5

Operating the appliance

Use the induction cooking zones with suitable cookware.

Switching the appliance on and off

Control panel Display Pilot light

Switch on Touch for 1 second / lights up.

Switch off Touch for 1 second / none goes out.

After switching on, within approx. 10 seconds a heat setting or a function must be set,

otherwise the appliance automatically switches itself off.

Setting the heat setting

Control Panel Display

To set the heat setting Touch the desired heat setting,

if necessary, correct to the left

or to the right

to /

Switch off Touch 0

Locking/unlocking the control panel

The control panel, with the exception of the “On/Off” sensor field, can be locked at any time

in order to prevent the settings being changed e.g. by wiping over the panel with a cloth.

Control panel Display

To switch on Touch (for 4 seconds)

To switch off Touch previously set heat setting

When you switch the appliance off, the locking function is automatically switched off.

Turning the STOP+GO function on and off

The STOP+GO function simultaneously toggles all active cooking zones to keep-warm mode

then back to the heat setting they were at before

Control panel Display

To switch on Touch

To switch off Touch Previous heat setting (not automatic warm-up or power

function)

STOP+GO does not stop timer functions.

STOP+GO controls the entire control panel apart from the sensor field .

6Operating the appliance

Using the automatic warm-up function

All cooking zones are equipped with an automatic warm-up function. When setting a heat

setting using the automatic warm-up function, the cooking zone switches to full power

for a certain amount of time and then automatically switches back to the heat setting set.

Step Control Panel Display

1. Touch

2. Move your finger down

from to select the de-

sired heat setting between

and

/ after 5 seconds . As long as is

displayed, the appliance works at full power. After

the automatic warm up is completed, the heat

setting / is displayed again.

The length of time that the automatic warm up function operates depends on the heat

setting selected.

Heat setting Length of the automatic warm up [min:sec]

0:12

1:21

3:07

4:24

5:51

8:12

10:12

10:36

2:01

2:28

2:52

---

Using the child safety device

The child safety device prevents unintentional use of the appliance.

Switching on the child safety device

Step Control panel Display/Signal

1. Switch on appliance. Do not set a heat setting.

2. Touch for 4 seconds

The child safety device is switched on.

Operating the appliance 7

Switching off the child safety device

Step Control panel Display/Signal

1. Switch on appliance. Do not set a heat setting.

2. Touch for 4 seconds lights up

3. Switch appliance off.

The child safety device is switched off.

The child safety device can only be switched on and off if no heat setting is set.

Overriding the child safety device

The child safety device can be switched off in this way for a single cooking session; it remains

activated afterwards.

Step Control panel Display/Signal

1. Switch appliance on

2. Touch for 4 seconds lights up

Until the appliance is next switched off, it can used as normal. After switching off the appliance,

the child safety device is active again.

After overriding the child safety device, a heat setting or a function must be set within

approx. 10 seconds, otherwise the appliance automatically switches itself off.

Switching the power function on and off

The power function makes more power available to the induction cooking zones, e.g. to

bring a large quantity of water to the boil quickly. The power function is activated for 8

minutes at most. After that the induction cooking zone automatically switches back to heat

setting .

Control panel Display

To switch on Touch

To switch off Touch a heat setting /

8Operating the appliance

Power Management

The cooking zones of the cooking surface have a

maximum power.

The maximum power is reached when the heat

setting 14 has been set for all cooking zones.

Two cooking zones generate a pair (see figure)

and therefore, the power management shares the

maximum available power between these cook-

ing zones.

When the power function is selected for one

cooking zone, the power management makes the

additional power for this cooking zone available

by reducing the power of the corresponding oth-

er cooking zone.

Example: the heat setting 14 is selected on one cooking zone. The power function is

switched on for the corresponding cooking zone. The power function is carried out but the

heat setting 14 of one of the cooking zones and the power function for the other cooking

zone of the pair exceed the maximum power for both at the same time. For this purpose,

the power management reduces the power of the cooking zone that switched on first from

14 to example 5 and the display of this cooking zone changes between 14 and 5 and then

stays at the current possible maximum 5 (If the display changes between 14 and 5 or 14

and 3 or another value depends on the type of appliance and the size of the cooking zone).

Using the timer

Function Condition Outcome after the time has

elapsed

Automatic cut-out a heat setting is set acoustic signal

flashes

Cooking zone switches off

Countdown timer cooking zones not in use acoustic signal

flashes

If just one countdown value is set you can change it only when the appliance is switched

on.

If a heat setting is set on this cooking zone in addition to a countdown timer, the cooking

zone is switched off after the time set has elapsed.

If a cooking zone is switched off, the timer function set is also switched off.

Selecting a cooking zone

Step Control panel Display

1. Touch once Pilot light of the first cooking zone flashes

Operating the appliance 9

Step Control panel Display

2. Touch once Pilot light of the second cooking zone flashes

3. Touch once Pilot light of the third cooking zone flashes

4. Touch once Pilot light of the fourth cooking zone flashes

If other timer functions are set, after a few seconds the shortest remaining time of all the

timer functions is displayed and the corresponding pilot light flashes.

Setting the time

Step Control panel Display

1. Select a cooking zone Pilot light for the cooking zone selected

flashes

2. Touch or

minutes

After a few seconds the pilot light flashes more slowly.

The time is set.

The time counts down.

Switching off the timer function

Step Control panel Display

1. Select a cooking zone Pilot light of cooking zone selected flashes faster

Time remaining is displayed

2. Touch The time remaining counts backwards to

The pilot light goes out.

The Timer function for the selected cooking zone is switched off.

Changing the time

Step Control panel Display

1. Select a cooking zone Pilot light of the selected cooking zone

flashes more quickly

Remaining time is displayed

2. Touch or

minutes

After a few seconds the pilot light flashes more slowly.

The time is set.

The time counts down.

Displaying the time remaining for a cooking zone

Step Control panel field Display

1. Select a cooking zone Pilot light of the cooking zone selected flashes faster

The time remaining is displayed

After a few seconds the pilot light flashes more slowly.

10 Operating the appliance

Table of contents

Other AEG Electrolux Hob manuals

AEG Electrolux

AEG Electrolux HK654070FB User manual

AEG Electrolux

AEG Electrolux HK614010MB User manual

AEG Electrolux

AEG Electrolux 95852 G User manual

AEG Electrolux

AEG Electrolux 61371 M and User manual

AEG Electrolux

AEG Electrolux 78001KF-N User manual

AEG Electrolux

AEG Electrolux 75553G-M User manual

AEG Electrolux

AEG Electrolux 64500G-M User manual

AEG Electrolux

AEG Electrolux 79301 KF-N User manual

AEG Electrolux

AEG Electrolux 6530 DG-M Product guide

AEG Electrolux

AEG Electrolux FM 6520 K-AN User manual

AEG Electrolux

AEG Electrolux 79200 KF-N User manual

AEG Electrolux

AEG Electrolux Gas Hob User manual

AEG Electrolux

AEG Electrolux 76301K-MN User manual

AEG Electrolux

AEG Electrolux 76301KFE-N User manual

AEG Electrolux

AEG Electrolux 68031K-MN User manual

AEG Electrolux

AEG Electrolux 88032K-MN User manual

AEG Electrolux

AEG Electrolux FM 7803K-an User manual

AEG Electrolux

AEG Electrolux 96901KFE-N User manual

AEG Electrolux

AEG Electrolux 96931K-MN User manual

AEG Electrolux

AEG Electrolux 78001KF-N User manual

AEG Electrolux

AEG Electrolux 88101KF-N User manual

AEG Electrolux

AEG Electrolux 96931KFE-N User manual

AEG Electrolux

AEG Electrolux 34942 G User manual

AEG Electrolux

AEG Electrolux 21602 G User manual

Popular Hob manuals by other brands

Siemens

Siemens EX875KYV1E INFORMATION FOR USE

AEG

AEG CERAMIC HOB 6010 K Installation and operating instructions

VALERA

VALERA CT 70A datasheet

Zanussi

Zanussi ZGF 6420 Instruction booklet

Gaggenau

Gaggenau CI 273 use and care manual

G3 Ferrari

G3 Ferrari Energy user manual

Pkm

Pkm IN4B instruction manual

Award

Award H903BG user manual

Zanussi

Zanussi VCH 5005 RZ Instruction booklet

Miele

Miele KM 523 Operating and installation instructions

Hotpoint

Hotpoint IS67V8CCXT/E manual

AEG

AEG HK854870XB user manual

Cookology

Cookology SEP600BK instruction manual

Bauknecht

Bauknecht Hob Instructions for use

Zanussi

Zanussi ZGM 782 Instruction booklet

dipo INDUCTION

dipo INDUCTION DIBK218S quick start guide

Miele

Miele KM 5987 Operating and installation instructions

Miele

Miele KM 360 G installation instructions
