ADTRAN TSU LT User manual

TSU LT P/N 1202060L2/1202060L4

For more detailed documentation, visit us online at www.adtran.com

NETWORK CONNECTION PINOUT

Pin Name Description

1 R1 RXDATA Receive data from the Network - Ring

2 T1 RXDATA Receive data from the Network - Tip

3, 6, 7, 8 UNUSED n/a

4 R TXDATA Transmit data towards the Network - Ring

5 T TXDATA Transmit data towards the Network - Tip

INSTALLATION INFORMATION

• An eight-position modular jack (labeled NETWORK) is provided to

connect to the network T1 circuit. The pinout is provided on this Quick

Start Guide. See Chapter 2, Installation, of the TSU LT User Manual for

more information.

• The rear panel contains a single V.35 (V.11 for P/N 1202060L4)

interface for connecting to DTE equipment. The pinouts for these

interfaces are provided on this Quick Start Guide.

• When shipped from the factory, the TSU LT is uninitialized and set to

factory default conditions. At the first application of power, the unit will

automatically execute self-tests followed by an initialization sequence.

• The TSU LT can be configured and controlled using the local front panel

of the unit, by a direct or remote serial connection via the control port, or

by ADTRAN’s PC-based management software package,

T-WATCH PRO. A limited menu tree is provided on the back of this

sheet. For more detailed menu information, refer to the TSU LT User

Manual.

• Additional information can be found on the product CD which contains

the TSU LT User Manual, FAQs, Data Sheets, Applications, and White

Papers.

REAR PANEL DESCRIPTIONS

Network Connector Connection to T1 circuit

Test Interface

(P/N 1202060L2 only)

Bantam jacks provided for monitoring

and testing of a T1 circuit

Control Chain-In/Chain-Out Connection to a VT100 terminal

V.35 Connector (P/N 1202060L2)

V.11 Connector (P/N 1202060L4)

High-speed DTE interface

Power Switch Turns power to the TSU on or off

220 VAC Connection Power cord connection for a reliably

grounded 220 VAC, 60 Hz power source

TSU LT P/N 1202060L2/1202060L4

MENU TREE - OVERVIEW

1) NI PERF RPRTS

1) STATUS 2) CURR ERR/ALM

3) ERR/ALM HIST

1) NETWORK (NI)

2) CONFIG 2) UNIT

MAIN MENU 3) PORT

1) TIME/DATE

2) SOFTWARE REV

3) UTIL 3) REINIT UNIT

4) ADDRESS

5) SET PASSCODE

6) FACT RESTORE

1) NETWORK TESTS

4) TEST 2) RUN SELF–TEST

3) PORT TESTS

V.35 CONNECTOR PINOUT

Pin CCITT Description

A 101 Protective ground (PG)

B 102 Signal ground (SG)

C 105 Request to send (RTS) from DTE

D 106 Clear to send (CTS) to DTE

E 107 Data set ready (DSR) to DTE

F 109 Received line signal detector (DCD)

to DTE

H — Data terminal ready (DTR) from

DTE

J — Ring indicator (RI)

L — Local loopback (LL)

N — Remote loopback (RL)

R 104 Received data (RD-A) to DTE

T 104 Received data (RD-B) to DTE

V 115 RX clock (RC-A) to DTE

X 115 RX clock (RC-B) to DTE

P 103 Transmitted data (TD-A) from DTE

S 103 Transmitted data (TD-B) from DTE

Y 114 TX clock (TC-A)

AA 114 TX clock (TC-B)

U 113 External TX clock (ETC-A) from

DTE

W 113 External TX clock (ETC-B) from

DTE

NN&K — Test mode (TM) to DTE

V.11 CONNECTOR PINOUT

Pin A Pin B Description

Shield

(SI) Signalling Rate Indicator

(SD) Send Data

(ST) Send Timing

(RD) Receive Data

(RS) Request to Send

(RT) Receive Timing

(CS) Clear to Send

11 29

(LL) Local loopback

(DM) Data Mode

12* 30* (TR) Terminal Ready

13 31 (RR) Receiver Ready

15*

(RL) Remote Loopback

(IC) Incoming Call

16*

17 35

(SR) Signaling Rate Selector

(TT) Terminal Timing

(TM) Test Mode

(SG) Signal Ground

20*

28*

(RC) Receive Common

(IS) Terminal in Service

32*

33*

(SS) Select Standby

(SQ) Signal Quality

34*

36*

37*

(NS) New Signal

(SB) Standby Indicator

(SC) Send Common

Note: Pins 3 and 21 are undefined.

* Indicates pins not being used

Compliance

Double pole/neutral fusing.

The socket-outlet shall be

installed near the equipment

and shall be easily accessible.
