ADF Web HD67B19-B2 User manual

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 1 of 35

User Manual

Revision 1.

English

OPC UA Client / MQTT - Converter

(Order Code: HD67B19-B2)

for Website information:

http://www.adfweb.com/?Product=HD67B19

for Price information:

http://www.adfweb.com/?Price=HD67B19-B2

Benefits and Main Features:

Triple electrical isolation

Power Supply 18…35V DC and 8…24 V AC

Temperature range: -4 °C/+85°C (-4 °F/+185°F)

For others OPC UA Client devices, see also the following links:

OPC UA Client from/to …

www.adfweb.com?Product=HD67B 8 (Serial)

www.adfweb.com?Product=HD67B 9 (Modbus Slave)

www.adfweb.com?Product=HD67B1 (Modbus TCP Slave)

www.adfweb.com?Product=HD67B11 (Ba net Slave)

www.adfweb.com?Product=HD67B12 (CAN)

www.adfweb.com?Product=HD67B13 (CANopen)

www.adfweb.com?Product=HD67B14 (Devi eNet Slave)

www.adfweb.com?Product=HD67B15 (DMX)

www.adfweb.com?Product=HD67B16 (EtherNet/IP Slave)

www.adfweb.com?Product=HD67B17 (J1939)

www.adfweb.com?Product=HD67B18 (KNX)

www.adfweb.com?Product=HD67B2 (NMEA0183)

www.adfweb.com?Product=HD67B21 (NMEA2000)

www.adfweb.com?Product=HD67B22 (PROFINET)

www.adfweb.com?Product=HD67B23 (SNMP Agent)

Do you have an your customer protocol?

See the following links:

www.adfweb.com?Product=HD67 3

Do you need to choose a device? do you want help?

Ask it to the following link:

www.adfweb.com?Cmd=helpme

User Manual

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 2 of 35

INDEX:

Page

INDEX 2

UPDATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAMPLE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

POWER SUPPLY 7

FUNCTION MODES 8

LEDS 9

ETHERNET 1

USE OF COMPOSITOR SW67B19 11

NEW PROJECT / OPEN PROJECT 12

SOFTWARE OPTIONS 13

SET COMMUNICATION 15

OPC UA ACCESS 21

MQTT SET TOPIC 27

UPDATE DEVICE 29

TEMPLATE STRING: DEFINITION OF MQTT PAYLOAD

MECHANICAL DIMENSIONS 32

ORDERING INFORMATIONS 33

ACCESSORIES 33

DISCLAIMER 34

OTHER REGULATIONS AND STANDARDS 34

WARRANTIES AND TECHNICAL SUPPORT 35

RETURN POLICY 35

Pagina 2 di 35

UPDATED DOCUMENTATION:

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document.

With this “Document Code” go to web page www.adfweb.com/download/

and search for the corresponding code on the page. Click on the proper

“Document Code” and download the updates.

REVISION LIST:

Revision

Date Author

Chapter

Des ription

1. 13/ 3/2 19 Tf All First release version

WARNING:

ADFweb.com reserves the right to change information in this manual about

our product without warning.

ADFweb.com is not responsible for any error this manual may contain.

TRADEMARKS:

All trademarks mentioned in this document belong to their respective

owners.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 3 of 35

SECURITY ALERT:

ENERAL

NFORMATION

To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and

safety regulation are required for each individual application. The same applies also when using accessories.

NTENDED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.

independent limit switches, mechanical interlocks, etc.).

UALIFIED

ERSONNEL

The device can be used only by qualified personnel, strictly in accordance with the specifications.

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and

who have appropriate qualifications for their job.

ESIDUAL

ISKS

The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and

operated by untrained personnel. These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or

death and / or the possibility of damage.

CONFORMITY

The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 4 of 35

EXAMPLE OF CONNECTION:

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 5 of 35

Figure

: Connecti

on scheme for HD67

CONNECTION SCHEME:

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 6 of 35

CHARACTERISTICS:

The HD67B19-B2 is a OPC UA Client / MQTT Slave converter.

It allows the following characteristics:

Up to 15 bytes in reading and 15 bytes in writing;

Two-directional information between MQTT and OPC UA;

Mountable on 35mm Rail DIN;

Wide power supply input range: 8…24V AC or 12…35V DC;

Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].

CONFIGURATION:

You need Compositor SW67B19 software on your PC in order to perform the following:

Define the parameter of the OPC UA;

Define the parameter of the MQTT;

Define the list of OPC UA servers connected to the converter;

Update the device.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 7 of 35

POWER SUPPLY:

The devices can be powered between a wide range of tensions. For more details see the two tables below.

VAC

VDC

Vmin Vmax Vmin Vmax

HD67B19-B2 8V 24V 12V 35V

Consumption at 24V DC:

Devi e W/VA

HD67B19-B2 4

Caution: Not reverse the polarity power

HD67B19-B2

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 8 of 35

FUNCTION MODES:

The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:

The first, with Dip1 in Off position (factory setting), is used for the normal working of the device.

The second, with Dip1 in On position, is used for upload the Project/Firmware.

For the operations to follow for the updating (see ‘UPDATE DEVICE’ section).

According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 9 of 35

****LEDS:

The device has got six LEDs that are used to give information of the functioning status.

The various meanings of the LEDs are described in the table below.

LED Normal Mode Boot Mode

1: Device State (green) Blinks slowly (~1Hz) Blinks qui kly: Boot state

Blinks very slowly (~0.5Hz): update in progress

2: OPC UA comm. (yellow) Flashing: OPC UA response

OFF: No OPC UA response

Blinks qui kly: Boot state

Blinks very slowly (~0.5Hz): update in progress

3: MQTT comm. (yellow) Flashing: MQTT communication

OFF: No MQTT communication

Blinks qui kly: Boot state

Blinks very slowly (~0.5Hz): update in progress

4: Error state (yellow) ON: OPC UA and/or MQTT not connected

OFF: No errors

Blinks qui kly: Boot state

Blinks very slowly (~0.5Hz): update in progress

5: Link Ethernet (green) ON: Ethernet cable connected

OFF: Ethernet cable disconnected

ON: Ethernet cable connected

OFF: Ethernet cable disconnected

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

OPC UA Client /

MQTT

Document code: MN67B19_ENG Revision 1. Page 1 of 35

ETHERNET:

The Ethernet connection must be made using Connector3 of HD67B19-B2 with at least a Category 5E cable. The maximum length of the

cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the

device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a

cross cable.
