Adaptec SlimSCSI 1450 User manual

User’s Guide

SLIMSCSI 1450 ADAPTER

Adaptec, Inc.

691 South Milpitas Boulevard

Milpitas, CA 95035

Adaptec logo are trademarks of Adaptec,

Inc. which may be registered in some

jurisdictions.

Printed in Singapore

STOCK NO.: 511607-00, Rev. B BKB 12/97

▼ ▼ ▼ ▼ SlimSCSI 1450 Adapter

User’s Guide

iii

▼ ▼ ▼ ▼ Contents

Introduction 1

Contents of Kit 1

System Requirements 1

Installing the SlimSCSI 1450 2

Updating the Windows 95 Miniport Driver 5

Using the SlimSCSI 1450 6

Hot Plugging 6

Formatting Removable Media 7

Understanding SCSI 8

SCSI IDs 8

Terminating the SCSI Bus 9

SCSI Connector Types 9

Troubleshooting 10

General Hardware Troubleshooting 10

Windows 95 Troubleshooting 11

Contacting Adaptec 15

Electronic Support 15

Technical and Product Support 16

Sales and Ordering Information 16

Introduction

Congratulations on your purchase of Adaptec’s SlimSCSI®1450,

which is designed specifically for use with Microsoft Windows®95.

The SlimSCSI 1450 allows you to connect up to three SCSI devices to

your portable PC, including Zip drives and other kinds of remov-

able media drives.

Contents of Kit

■SlimSCSI 1450 PC Card-to-SCSI Adapter, with permanently

attached 50-pin high-density cable

■Windows 95 driver diskette

■SlimSCSI 1450 User’s Guide

■50-pin-to-DB25 converter

■Registration card

System Requirements

■Portable PC with a PC Card Type II, Type III, or Toshiba

Type IV slot

■Microsoft Windows 95

SlimSCSI 1450 Adapter User’s Guide

Installing the SlimSCSI 1450

Follow these steps to install the SlimSCSI 1450 and connect your

SCSI devices to it:

Remove the SlimSCSI 1450 from its packaging.

Plug the 50-pin connector into the first (or only) SCSI device, as

shown below. Make sure the SCSI device is not powered.

If the SCSI device has a DB25 (25-pin) connector, attach the

50-pin-to-DB25 converter, as shown below, and plug it into the

connector on the device.

SCSI Connector SCSI Device

Terminator

50-pin-to-25-pin

Converter

Installing the SlimSCSI 1450

(Optional) Connect up to two additional SCSI devices by daisy-

chaining them to the first device, as shown below:

Be sure that each SCSI device has a unique SCSI ID ranging

from 0 to 6. If any two devices have the same ID, change the

SCSI ID of one device. This is usually done by changing a

switch on the back of the device. (For more information, see

SCSI IDs on page 8.)

The diagram below shows a typical SCSI device with a select-

able SCSI ID switch:

Terminate the last (or only) SCSI device connected to the

SlimSCSI 1450. Read the device documentation if you are not

sure how to terminate the device, or refer to Terminating the

SCSI Bus on page 9.

SCSI Devices

Terminator

SlimSCSI 1450 Adapter User’s Guide

Be sure that at least one external SCSI device provides SCSI

bus termination power or that the last device on the bus sup-

plies termination power to itself. Read the device documenta-

tion if you are not sure whether the SCSI device provides

termination power.

Connect all power cables to the SCSI device(s). Then power up

the device(s).

Insert the SlimSCSI 1450 into one of your portable PC’s

PC Card slots, as shown below:

Power up your portable PC.

This completes the physical installation of your SlimSCSI 1450 and

SCSI devices. Next, you need to update the SlimSCSI Windows 95

miniport driver.

SlimSCSI Adapter

PCMCIA Type II or Type III Slot

(or Toshiba Type IV Slot)
