Ace Professional Media Server LHD LIMITED II User manual
ACE
Connecting you to the new digital world
LHD LIMIT
ED II
Professional Media Server
S P E C I F I C A T I O N S
Intel® Viiv™ Technology Certified
Intel® Core2™Duo Processor
4 TV Tuners including Dual HDTV Tuners
Beautiful Tabletop or 4U Rackmount quiet
brushed aluminum chassis, Silver or Black
Integrated 7” LCD Touchscreen
Gigabit Ethernet Port & 802.11A/B/G WI-FI
Optional Ace® Powerworks™ Storage
Servers from 1/2 to 36 Terabytes available
High Performance ISF®Certified Video
using ATI® Radeon® X1K™ Technology
Nationwide on-site support available
Dolby® Master Studio™Certified Audio -
24 Bit/192KHz with 8 HD Channels
Up to 4 Terabytes of raid-based redundant
storage with Acronis® Imaging software
Single or Dual Rewritable DVD-RW Drives
with Lightscribe and HD-DVD/Blu-Ray Options
Fully Microsoft®Vista®Ready System
Logitech®Bluetooth DiNuvo or Laser
Desktop with Harmony®Remote Control
Firewire and USB 2.0 Connectivity Built-In
with Bluetooth Optional
Anti-Vibration and Acoustically Dampened
to reduce ambient noise from the system
1425 East Algonquin Road
Arlington Heights, IL 60005
Call Toll-Free (877) ACE-COMP
Sales@acecomputers.com
www.acedigitalhome.com
™
Technical Specications
ACE LHD™ Limited II
Processors
Intel® Core2™Duo
Chipset
Intel® 975X, Intel® ICH7DH-
Certied for Intel ViiV® Technology.
Chassis:
Black or Silver Aluminum with integrated 7” LCD Touchscreen for front
display and local console selections (Black not available at time of
submission)
Dimensions: 16.73”x 16.73” x 6.69” - (4U Rackmount); Weight:
Approx 25 lbs
Operating System
Microsoft® Windows® XP Media Center Edition 2005 with High Denition
Television and all recent updates. Also compatible with major home
control software like Lifeware®
Television Tuners
NTSC - Dual Cable & Satellite Ready Tuners w/ full hardware MPEG-
2 compression, a 3D comb lter, and advanced noise reduction for
advanced Personal Video Recorder capabilities, Independent Inputs
(S-Video, RF, RCA Audio Jacks)
ATSC - Dual HDTV Tuner able to receive Free Over the Air High Denition
Television Broadcasts in North America.
FM Tuner
Stereo FM Terrestrial Radio
Audio
Dolby Master Studio Certied - Intel High Denition Audio 8-channel
CODEC - 5.1 / 6.1 / 7.1 Digital Surround Sound – Dolby Labs Certied
- 192KHz/24-bit audio output and S/PDIF out interface, Jack-sensing
feature, retasking functions and multi-streaming technology that
simultaneously sends different audio streams to different audio zones-
Two Channel Audio Inputs in front and in rear
Storage -Internal:
Up to six 3.5” SATA Enterprise Grade Hard Drives; Total of 4.5TB Internal
Data Storage (RAID5) – Dual SATA RAID Controllers Present, Can run
RAID 0,1,5,10 and 50 if desired. System also comes with Acronis®
backup software and can designate drives as hidden partitions for
automatic regular scheduled backup for media. Maximum of 3.75TB
RAID5 Redundant internal storage.
External:
1 Drive Bay for External Removable Archival Storage – Ships with 1
– 750GB Removable Drive and Acronis® Backup software with automatic
backupsSupports USB 2.0 and IEEE1394 (Firewire) external storage
Network: Out of the box support for the Ace Powerworks Storage Server
family of A/V Storage Servers; Add up to 36 Terabytes of Networked
Storage in one box, with native support for Microsoft Media Center
2005
Graphics
PCI Express x16
ATI X1600XL 256-bit, 16.0GB/sec. Memory Bandwidth, 16 Rendering
Pipelines, 520 Engine Speed, Dual Integrated 10 bit per channel 400MHz
DACs, Quad-Channel GDDR3 memory, DVD and HDTV-ready MPEG-2
decoding up to 1920x1080i resolutions.
Lossless Color Compression (up to 6:1) at all resolutions, including
widescreen HDTV resolutions, Integrated HDTV Encoder, Advanced
adaptive de-interlacing, WMV9 decode acceleration, OpenGL® 2.0
Optimizations and Support, Microsoft® DirectX® 9.0 Shader Model 3.0
Support, Maximum 3D Resolution: 16.7M colors at 2048x1536.
Outputs: HDMI, DVI, VGA, Composite, S-Video, Component Video is
optional
ISF Certied - tested and veried to meet a superior level of technical
performance, and the approval of the most discerning eye and ear.
Optical Disk Drive
Multi Format DVD & CD Recorder with Lightscribe Technology, Blue-
Ray/HD-DVD Technology Ready
16x Speed DVD-R Writing, 4x Speed DVD-RW Writing, 16x Speed DVD+R
Writing, 4x Speed DVD+RW Writing, 24x Speed CD-R Writing, 10x Speed
CD-RW Writing, 24x Speed CD-ROM Reading, 16x Speed DVD-ROM
Reading, Buffer Under Run Protection, DVD MULTI Read/Write Support
Memory
2GB DDR2 PC5300 Memory Standard ; 4GB maximum - Dual channel
memory architecture - 4 x 184-pin DIMM sockets
Networking
10/100/1000 Base-T Gigabit Ethernet LAN via PCI Express and Wireless
802.11A/B/G
Input Devices
Logitech® Laser Desktop- Bluetooth Keyboard and Mouse with Bluetooth
Remote - Logitech Harmony™ Series
Expansion Ports
USB 2.0:
2 x Front Panel, 4x Rear Panel
IEEE1394 (Firewire):
1x Front Panel, 1x Rear Panel
Power
600 Watt Modular Power Supply w/ over power protection, 230 Volt /
optional 115 Volt.
Intel Certied Rounded Heat Sink Design
Mounting:
Anti-Vibration and Anti-Sound Design – Ace Proprietary Cooling
System
GS-35F-0332M
1425 East Algonquin Road
Arlington Heights, IL 60005
(847) 952-6900 * (847) 952-6901 FAX
(877) ACE-COMP * www.acecomputers.com
Our 23rd year of Excellence
1983 - 2006
MEMBER
ACE
Over 20 years of Systems Manufacturing
Experience in the IT INdustry
*Ranked #12 Largest US Computer
Systems Manufacturer by CRN Magazine,
*#1 in Storage Servers by CRN Magazine
*Member of VARBusiness TOP 500
Largest IT Resellers in the US
*GSA Schedule GS-35F-0332M
*Multiple State and Educational
Contracting Vehicles Available
Member
877-ACE COMP
www.acedigitalhome.com
