ZyXEL Communications GS-1116A User manual

Benefits

16/24-port Unmanaged

Gigabit Ethernet Switch

gs-1116a

gs-1124a

Cost Advantage Solution for

Gigabit-to-the Desktop

Non-blocking Gigabit wire-speed

forwarding to fly the transmission

Jumbo frame mode support

(up to 10K bytes) to maximize

efficiency of transmission for

giant packets

IEEE802.1p CoS support to

priority transmission according to

packet priority level

IEEE 802.3x Flow control to

optimize transmission by

reducing congestion

2 built-in Dual-personality

(RJ-45 or SFP open slot) interfaces

for flexible deployment

Auto MDI/MDI-X support for

hales-free usage

1U, 19" rack mountable

Cost-effective Solution for Gigabit Migration

ZyXEL GS-1116A/GS-1124A is a 16-port/24-port unmanaged gigabit switch providing a cost-effective

solution to empower“Gigabit to the desktop”connectivity.This brings significant performance

improvement with increased network bandwidth. In addition, the GS-1116A/GS-1124A come with two dual

personality (RJ-45 or SFP open slot) interfaces. It offers flexible connectivity (copper or fiber) to adapt to

different deployment environments.The GS-1116A/GS-1124A is an ideal solution for bandwidth-hungry

applications (such as high resolution digital image transmission, video/audio file streaming/downloading,

server farm connectivity).

Wire-speed Gigabit Engine to Fly the Transmission

With a robust hardware design, the GS-1116A/GS-1124A performs packet forwarding at wire-speed, which

can instantly transfer giant packets without performance degradation. In addition, with the support of

802.3x flow control, the GS-1116A/GS-1124A guarantees smooth transmission by adjusting packet

transmission to reduce congestion.IEEE802.1p CoS allows the GS-1116A/GS-1124A to send packets based

on the priority level to optimize multi-service applications, like VoIP, video conferencing or video streaming.

In addition, the GS-1116A/GS-1124A supports jumbo frame transmission up to 10K bytes to improve

transmission efficiency and network performance.

Hassle-free Installation and Usage

Connectivity can be as easy as connecting to a port on the switch. All the rest of the functions are done

automatically. All ports on the GS-1116A/GS-1124A are Auto MDI/MDIX; that means you don’t need to

check the Ethernet cable type. In addition, auto-negotiation helps adjust link speed intelligently to reach

the best link quality. In other words,there is not hassle of twigging with the switch or pouring over the user

manuals.The GS-1116A/GS-1124A is rack mountable,allowing you to place it in a rack to save precious

office space.

GS-1116A

16-port Unmanaged Gigabit Ethernet Switch

GS-1124A

24-port Unmanaged Gigabit Ethernet Switch

Specifications

Standard Compliance

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100 Base-Tx Ethernet

• IEEE 802.3ab 1000 Base-T Ethernet

• IEEE 802.3z 1000Base-X Ethernet

• IEEE 802.3x Flow control

• IEEE 802.1p Class of service, priority protocols

Performance

• Jumbo Frame support up to 10K bytes

• IEEE 802.1p with 2 priority queues per port for

different types of traffic

• Wire-speed performance

GS-1116A

• 32Gbps non-blocking switching fabric

• Switching Forwarding Rate:

26.8Mpps (1488000pps/1000Base-T or 1000Base-X )

GS-1124A

• 48Gbps non-blocking switching fabric

• Switching Forwarding Rate:

38.7Mpps (1488000pps/1000Base-T or 1000Base-X)

MAC

• 4K MAC entries (GS-1116A/GS-1124A)

Memory Buffer

• GS-1116A: 340kB

• GS-1124A: 500kB

Hardware Specifications

• GS-1116A: 14 x 1000Base-T + 2 x Dual Personality

(RJ-45/SFP slot) GbE Interface

• GS-1124A: 22 x 1000Base-T + 2 x Dual Personality

(RJ-45/SFP slot) GbE Interface

• Support auto-negotiation

• Support auto MDI/MDI-X

Power Requirements

GS-1116A

• Input voltage of AC: 100-240VAC, 50/60Hz

• Max power rating of AC:17.3 Watt

GS-1124A

• Input voltage of AC: 100-240VAC, 50/60Hz

• Max power rating of AC:26.5 Watt

Physical Specifications

GS-1116A

• Dimensions: 440 (W) x 161 (D) x 44 (H) mm

• Weight: 3.0Kg

GS-1124A

• Dimensions: 440 (W) x 161 (D) x 44 (H) mm

• Weight: 3.2Kg

Environmental Specifications

• Operating temperature: 0˚C ~ 45˚C

• Storage temperature: -25˚C ~ 70˚C

• Operating humidity: 10% ~ 90%, non-condensing

Operational Information

Transceiver (Optional)Transceiver (Optional)

SFP-SX

SFP-LX-10

SFP-LHX1310-40

SFP-ZX-80

-17

-20

-23 dBm

-24 dBm

850

1310 n

1550 n

550

550 m

40 km

80 km

300

00 mA

.15 ~ 3.45

Transmission Distance vs.Fiber Cable Specification Operational Ranges

Wavelength

Optical

Receiver

Sensitivity

Connector 62.5um

Multi-Mode Fiber

50um

Multi-Mode Fiber

9/10um

Single-Mode Fiber Supply Voltage Max Current

Model Name

Application DiagramApplication Diagram

Internet

r 1

r 2

Data Center

1000Mbps/Fiber

1000Mbps/Copper

10/100Mbps/Copper

Gigabit Fiber Trunk

Gigabit Copper Trunk

Gigabit to the Desktop

Gigabit to the Server

65-100-112404G 05/06

All other brands, product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.

For more product information, visit us on the web www.ZyXEL.com
