Zte ZXHN H368C User manual
ZXHN H368C
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: (86) 755 26771900
Fax: (86) 755 26770801
URL: http://ensupport.zte.com.cn
E-mail: [email protected]
ZXHN H368C
User’sManual
Document version: 2012-06-22 R1.0
Copyright 2012 ZTE Corporation
All rights reserved.
No part of this documentation may be excerpted, reproduced,
translated, annotated or duplicated, in any form or by any
means without the prior written permission of ZTE
Corporation.
ZTE CORPORATION reserves the right to modify this manual
for product upgrade or other causes without notifying users in
advance.
i
Limited warranty
ZTE warrants that, for one year from the date of delivery by ZTE to
purchaser's designated carrier, the Equipment will remain free from
defects in design, material and workmanship under normal use and
service and will conform in all material respects to the applicable
specifications set forth in purchase order or agreement; ZTE does not
warrant that operation of the Equipment will be error-free or
uninterrupted.
In accordance with ZTE's standard, warranty terms, ZTE shall, at its
option, repair or replace any defective or nonconforming item, provided
that (a) purchaser/End User gives ZTE written notice of the defect or
nonconformity within the warranty period specified above promptly after
Reseller is notified by the End User of the same; and (b) End User
returns the defective item at its expense to ZTE’s nominated Customer
Service Department in accordance with ZTE’s standard parts exchange
procedures.
This warranty does not apply to defects or errors in the Equipment
caused by:(a) reasonable abrasion of equipments; (b)End User’s failure
to follow ZTE’s installation, operation or maintenance instructions or
procedures; (c) End User’s mishandling, misuse, negligence, or
improper installation, deinstallation, storage, servicing or operation of
the Equipment; (d) modifications or repairs not made by ZTE or a
ZTE-certified individual;(e) power failures, surges, fire, flood, accident,
actions of third parties or other events outside ZTE’s reasonable control.
(f) usage of products of third Parties, or usage conjunction with third
parties provided that such defects is due to the conjunction;(g) any
other cause beyond the range of normal usage for equipments. End
User shall assure that Equipment is installed and maintained by ZTE or
ZXHN H368C User’sManual
ii
ZTE-certified individuals in accordance with ZTE’s certification
procedures; provided that if End User causes or permits services to be
provided by individuals who are not ZTE-certified, the Warranty shall be
void as to all Equipment serviced in breach of this sentence. End User
shall have no right to reject, return, or receive a refund for any
Equipment from ZTE. Any item repaired or replaced by ZTE shall
continue to be warranted for the longer of the remainder of the original
warranty period or 90 days from the date the repaired or replaced part
is delivered to the carrier.
THIS WARRANTY (1) IS END USER'S SOLE REMEDY AND ZTE’S
SOLE LIABILITY FOR DEFECTIVE OR NONCONFORMING ITEMS ,
AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,
IMPLIED OR STATUTORY, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, UNLESS OTHERWISE REQUIRED
UNDER THE MANDATORY PROVISIONS OF THE CHINESE LAW,
AND (2) IS BETWEEN ZTE AND END USER (AS THE ORIGINAL
PURCHASER FOR END USE) AND MAY NOT BE TRANSFERRED
OR ASSIGNED, BY OPERATION OF LAW OR OTHERWISE,
WITHOUT ZTE’S PRIOR WRITTEN CONSENT.
Limitation of Liability
ZTE SHALL NOT BE LIABLE FOR ANY LOSS OF PROFITS OR
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM OR ARISING OUT OF OR IN CONNECTION
WITH USING OF THIS PRODUCT, WHETHER OR NOT ZTE HAD
BEEN ADVISED, KNEW OR SHOULD HAVE KNOWN OF THE
POSSIBILITY OF SUCH DAMAGES, INCLUDING, BUT NOT LIMITED
TO, LOST PROFITS, COST OF CAPITAL, COST OF SUBSTITUTE
FACILITIES OR EQUIPMENT, ANY DOWNTIME COSTS OR CLAIMS
ZXHN H368C User’s Manual
iii
OF END USERS. THE LIABILITY OF EACH PARTY UNDER THIS
AGREEMENT, WHETHER ARISING OUT OF BREACH OF
CONTRACT (INCLUDING BUT NOT LIMITED TO BREACH OF
WARRANTY) OR TORT (INCLUDING BUT NOT LIMITED TO
NEGLIGENCE AND STRICT LIABILITY) OR UNDER AN
INDEMNIFICATION PROVISION SHALL IN NO EVENT EXCEED THE
AGGREGATE AMOUNT BENIFITED BY ZTE IN THE PRODUCTS
FROM WHICH SUCH LOSS OR DAMAGE DIRECTLY AROSE.
Confidentiality
End User agrees that End User will receive confidential or
proprietary information (“Confidential Information”) in connection
with the purchase and deployment of ZTE Equipment. End User
will not disclose ZTE’s Confidential Information, will use it only
for purposes for which it was disclosed, and must treat it with the
same degree of care as it does its own similar information, but with
no less than reasonable care. End User agrees that the terms herein,
the Equipment and all ZTE documentation is ZTE Confidential
Information.
Contents
Chapter 1 Safety Guidance............................................................1
1.1 Safety Check......................................................................................... 1
1.2 Safety Cautions..................................................................................... 1
Chapter 2 Overview .......................................................................3
2.1 Features................................................................................................. 3
2.2 Product Specifications.......................................................................... 3
2.3 Package Check...................................................................................... 4
2.4 System Requirement............................................................................. 5
Chapter 3 Installation Preparation...............................................6
3.1 Hardware Description........................................................................... 6
3.2 Hardware Connection........................................................................... 9
Appendix A FAQs.........................................................................12
1
Chapter 1 Safety Guidance
1.1 Safety Check
Before installing the VDSL2 equipment, check all the below listed items:
1 Electric safety
Ensure no inflammable, conductive or moist objects and no
ageing-cables around the equipment. Place all electrical appliances
safely.
2 Equipment position
Install the equipment in a ventilated environment avoid of any electric
devices nearby.
Place the equipment on a stable and flat surface.
The equipment must be protected from sunshine. It must be kept away
from electro-magnet interference.
The equipment must be protected from heat and water sources.
Ensure the power supply is available. The fluctuation range of input
voltage should be in the range of ±10%. Do not share the power
socket with other electrical devices.
1.2 Safety Cautions
Please pay attention to the following cautions:
Read the user’s manual carefully before using the equipment.
Note all Cautions in the user’s manual and product guide.
Do not use any accessory or components that are not belonging to the
equipment.
ZXHN H368C User’sManual
2
Use the power adapter, which is provided in the package.
Connect the phone with the VDSL2 line directly, and lead the line out
from the phone interface of the splitter.
Do not place any object on the equipment.
The equipment must be kept dry and clean. Ensure the equipment
environment has ventilation and rainproof capability.
To protect the equipment against lightning and thunderstorm, please
remove the power plug and all connection cables.
Use a soft and dry cloth to clean the equipment. Ensure the equipment
is power OFF before cleaning.
Power OFF the idle equipment.
Keep the ventilation-hole clean and unblocked. Otherwise, it may
cause short circuit, fire or damage the equipment. Do not spray liquid
on the equipment surface.
Do not open the equipment especially in power ON state.
Confirm the power is OFF before plugging/unplugging the power.
Keep all components and accessories of the equipment away from the
children.
Note:
Please read the above safety guidance carefully before equipment use. Users
should assume responsibilities for any accidents due to incompliance with the
above instructions.
3
Chapter 2 Overview
The ZXHN H368C is a VDSL gateway, which provides high-speed VDSL
Internet access. It is designed with triple WAN function: VDSL, ADSL, and
Gigabyte WAN. The ZXHN H368C also features a built-in 802.11n WLAN
and an embedded MoCA for multimedia over coaxial cable. In addition, the
ZXHN H368C has a USB interface for file sharing and printer server.
2.1 Features
The ZXHN H368C is a VDSL2 MODEM. It supports the following features:
ITU-T G.993.2 VDSL2 standard and ITU-T G.992.5 DSL2+ standard.
It supports WLAN with high-speed data transfer rates up to 300 Mbps,
compatible with IEEE 802.11b/g/n, 2.4 GHz compliant equipment.
It supports IEEE802.3 and IEEE802.3u.
It supports speed auto-negotiation.
It supports Half duplex/Full duplex.
It supports user-friendly GUI for web configuration.
It supports IPSec for virtual private network (VPN).
It supports parental control function to restrict children usage.
It supports self-learning bridge (IEEE 802.1D Transparent Bridging).
It supports virtual server, IP filter, and demilitarized military zone (DMZ)
host.
It supports USB 2.0 host.
2.2 Product Specifications
Environmental requirements
ZXHN H368C User’sManual
4
Environmental temperature: -5°C-45°C (23 °F-113°F)
Humidity: 5% - 95% (non-condensing)
Power specification
Power adapter: Input: AC 100-240V, 50/60 Hz
Output: DC 12V, 1.5A
Certification
FCC
UL
WiFi
2.3 Package Check
ZXHN H368C 1
Micro Filter 1
Power Adapter 1
RJ-11 telephone cable 2
RJ-45 Ethernet cable 1
User’sManual&QualityWarrantyCard 1
CertificateofQuality 1
Note: for your information only, please refer to the actual product.
Caution: to reduce the risk of fire, use only NO.26AWG or larger (e.g.,
24AWG) UL Listed or CSACertified Telecommunication Line Cord.
Note:
Please use a power adapter that matches the ZXHN H368C package.
