Zanussi T 613 User manual

ZANUSSIANUSSI

ANUSSIANUSSI

ANUSSI

INSTRUCTIONS MANUAL

WASHING MACHINE

T 613

CONTENTS

For the user

Safety instructions 23/24

Description of the appliance 25

Use of your appliance 26

Operating instructions 27/28

Programme chart 29/30

Hints & Tips 31-33

Cleaning and maintenance 34

If something doesn't work 35/36

Service 37

For the installer

Technical information 38

Installation

Unpacking 38

Installation 39

Levelling 39

Moving of the appliance 39

Water connection 40

Electrical connection 40

Guide to use the instruction

The following symbols will be found in the text to guid you

throughout the instructions :

Safety instructions

Hints and tips

Environmental information

You must read the whole of this instruction book

before you use the appliance. Follow the advice

carefully. Keep the book for future reference. If

you sell or give away the appliance, make sure

that the book is passed to the new owner.

The following warnings are provided in the interest

of overall safety. You must read them before the

appliance is installed or used.

Use

This appliance is designed to be used by

adults. Children should not be allowed to touch

the controls or play with the product.

It is dangerous to modify the specifications of

this appliance in any way.

Always unplug the appliance and turn off the

water after use.

Only wash fabrics with are designed to be

machine washed. If in doubt, follow the instruc-

tions you find on the label of the item itself.

Place small metal rings or edged plastic rings

in a net or bag.

Make sure that all pockets are empty. Hard,

sharp objects such as coins, safety pins, nails,

screwsorstonescancauseextensivedamage.

Do not machine wash fabrics which are

saturated with petroleum products. If volatile

cleaning fluids have been used, make sure

that they are thoroughly removed from the

fabrics before they are placed in the appliance.

Small and delicate objects (e.g. baby socks,

stockings) can be easily washed inside a small

pillowcase with a zip fastener or in larger

socks.

Use only the recommended quantities of fabric

conditioner.

Beforecleaning,careandmaintenance,ensure

that the machine is unplugged.

Installation

Any electrical work required to install this

appliance should be carried out by a qualified

electrician or competent person.

Any plumbing work required to install this

appliance should be cariied out by a qualified

plumber or competent person.

Make sure that the appliance does not stand

on its electrical supply cable.

This appliance is heavy. Care should be taken

when moving it.

Allpackagingandtransitboltsmustberemoved

before the appliance is used. Serious damage

may occur if this is not done.

If your washing machine is in a room subject to

temperatures below freezing, the water must

be removed from the machine. So, the danger

of freezing should be expected.

SAFETY INSTRUCTIONS

Read all instructions before using

the appliance and save them for

future reference.

Safeties

Lid : your washing machine is equipped with

asafety avoidingtheswitching oftheappliance

when the flapdoors of the drum are opened ;

the closure of the lid is so impossible. An

electromechanic safety prohibits the opening

of the lid when the washing machine works and

2 minutes after the end of the programme.

Washing motor : in case of mechanic

overloading, overvoltage, a thermic safety

protects automatically the motor.

Heating : the heating can only begin when

the water quantity necessary for the washing

is in the tub. This safety is useful when there is

a water break-up or if you forget to open the

water inlet hose.

Anti-balanced system : This safety allows to

the appliance to keep a perfect stability during

the intermediary spinnings and during the final

spinning. If you notice that your laundry is not

spinned enough, the anti-balanced system has

then detected a bad distribution of the laundry

during the final spinning ; so it is adviced to

realize a new spinning taking care to unpack

handly the laundry before.

Environmental information

All materials marked by the symbol are

biodegradable. They can be disposed of without

danger or burnt in rubbish incinerators.

In order to realize water and energy savings and

to act in an environmentally conscious manner,

we advice to follow the below instructions :

Use if possible the appliance with full loads

instead of partial loads. Take care to do not

overload the drum.

Use only the programmes with prewash for very

soiled laundry.

Savings on detergent and for the environment

may also be achieved if with medium to hard

water you add sufficient detergent for soft water

andthenaddseparatelyasoftener.Thisrelieves

our waters of a certain amount of chemicals.

When disposing of the machine in a proper

manner, destroy the door lock and cut off the

power supply cord.

DESCRIPTION OF THE APPLIANCE

Detergent dispenser

Symbols

() Washing powder for programmes with

pre-wash (1).

() Washing powder or liquid detergent for

the main wash (2).

() Bleach compartment (3).

() Liquid additives (fabric softener and

conditioner...) (4).

5 Softener overflow

Control panel

Lid

Handle for

opening lid

Trap door for

lint filter

Programme selector

Control lamp

Pushbuttons

Temperature selector

123

USE OF YOUR APPLIANCE

The control panel

1 ON/OFF pushbutton " "

Presstheon/offpushbutton,theprogrammestarts

: the control lamp lights on.

2 Control lamp

The control lamp lights on when the appliance is

working (on/off pushbutton " " pressed). It lights

off when the cycle is finished (programme selector

on a stop position "I").

3 Half load pushbutton " "

This pushbutton allows to wash small quantity of

linen not much soiled (2,5 kg) only on the cotton

programmes.

4 Rinse hold pushbutton " "

Press this button to leave the water in the drum

after the wash cycle is completed. This works on

all the washing programmes. The clothes are left

suspended in water after the final rinse to prevent

the formation of creases.

Never turn the programme selector when the appliance is working.

12634 5

5 Programme selector

It enables to select the most adapted programme

to the nature and degrees of soil of your laundry.

Turn the programme selector clockwise to select

the chosen programme.

The programme selector indicates each pro-

gramme phase as it takes place.

At the end of the programme, the appliance stops

automatically on a stop position "I" for all the

programmes or on a rinse hold position " " if the

rinse hold pushbutton is selected.

Never turn the programme selector anticlockwise.

6 Temperature selector

Itenables to choose the mostadaptedtemperature

between cold ( ) and 90°C.

Choose the temperature which corresponds to the

chosen programme, with the help of the indica-

tions or the programme table, according to the

fibers and the fastness of the colours.

OPERATING INSTRUCTIONS

1. Place the laundry in the drum

lift up the lid of the machine.

open the drum with your two hands by pressing

the button Aand the two flapdoors till they

disengage.

introduce the laundry into the drum ; close the

drum and the lid of the machine.

Be careful : before closing the lid of your machine,

make sure that the drum flapdoors are correctly

closed :

the two flapdoors fastened,

the button Apressed out.

2. Measure out the detergent

Measure out the amount of detergent

recommended by the manufacturer in the main

wash compartment ( ).

If you wish to carry out a prewash, pour the amount

required into the prewash compartment ( ).

3. Add the bleach agent, if required

You may use a bleach agent on cotton program-

mes.However,makesure thatthefabricwithstands

the treatment. Bleach is automatically washed

down into the drum. Pour 1/4 to 1 glass of 12° chl

bleach into compartment marked ( ) before

switching the machine on.

4. Add the fabric softener

Pourthe softener, if required, intothecompartment

marked ( ). Do not exceed the MAX level.

Your washing machine has been conceived in

order to save water and detergent products.

Pleasetake carethefillinglevelof thedetergent

productsdo not exceed the MAXmarkslocated

near the display window of your detergent

dispenser.

5. Press the half load pushbutton

"" and/or the rinse hold

pushbutton " "if required.

Powder detergent

Compartment

(prewash)

Compartment

(wash)

Before using your washing machine for the first time, we recommend that you do a preliminary wash with

the machine empty, as a precaution to clean the drum, tank and the product box.

1. Pour a dose of detergent in the “washing” detergent dispenser

2. Select the program B 90°C.

3. Press the on/off pushbutton " ".

Liquid detergent

only compartment

6. Select the temperature

Choose the temperature which corresponds to the

chosen programme, with the help of the indica-

tions or the programme table, according to the

fibers and the fastness of the colours.

7. Select the programme

Choose the programme according to the nature

and the degree of soil of the laundry.

Turn the programme selector clockwise to select

the chosen programme.

8. Starting of the programme

The on/off pushbutton " " enables to switch on

your machine. The control lamp lights on and the

programme begins.

9. At the end of the programme

When the selected programme is over, the ma-

chine stops automatically. The timer knob stops

on the position "I" for all the programmes and the

control lamp lights off.

If the rinse hold pushbutton " " is selected, the

washing programmes (cotton or synthetics) end

by a rinse hold in order to avoid the formation of

creases. The control lamp keeps lighted on.

You can finish these programmes by a spinning

(by releasing the rinse hold pushbutton) or by a

draining (by depressing the on/off pushbutton " "

and by choosing the programme P).

After each wash, depress the on/off pushbutton

"". Press off the other pushbuttons if necessary;

unplug the machine from the wall socket ; turn off

the water tap.

After each wash cycle, we recommend that the lid

and drum are left open after use to air the drum

and prevent mould and stagnant smells forming.

PROGRAMMES CHART

Programmes for cotton/linen

Maximum load : 5,0 kg (cotton)

semmargorP emmargorP

snoitpircsed

serutarepmeT

C° snoitpircseD elcycehtfo

*snoitpmusnoC

retaW )l( ygrenE )hWk( emiT )nim(

+etihW °09-°06

°04othsawerP °09-°06othsaW sgnisnir3 gninnipS

573,2051

etihW °09-°03

°09-°03othsaW sgnisnir3 gninnipS

560,2031

emmargorpkciuQ

)gk5,2:daolxam(

°04-°03

°04-°03othsaW sgnisnir3 gninnipstrohS

7455,056

sgnisniR

sgnisnir4 gninnipS

062,005

gninnipS

gninnipS mpr056

040,001

(*)Theseconsumptionsgiven(withthehightesttemperature)intheabovetableareprovidedasaguide

andmayvarydependingonthewatersupplytemperatureandpressure,andyourelectricitypowersupply

mains voltage.

When the selected programme is over, the washing machine stops automatically. The timer knob stops

on the position "I". The control lamps lights off.

If the rinse hold pushbutton " " is selected, the washing programmes end by a rinse hold in order to

prevent the formation of creases. The control lamp keeps lighted. You can finish these programmes by

aspinning (by releasingthe rinseholdpushbutton)orbyadraining(bydepressing theon/off pushbutton

"" and by choosing the programme P).

BE CAREFUL :

THE LID CAN ONLY BE OPENED 90 SECONDS AFTER THE MACHINE HAS STOPPED.

Programmes for synthetics/delicates/wool

Maximum loads : 2,5 kg (synthetics), 1 kg (wool).

(*)Theseconsumptionsgiven(withthehightesttemperature)intheabovetableareprovidedasaguide

andmayvarydependingonthewatersupplytemperatureandpressure,andyourelectricitypowersupply

mains voltage.

When the selected programme is over, the washing machine stops automatically. The timer knob stops

on the position "I". The control lamp lights off.

If the rinse hold pushbutton " " is selected, the washing programmes end by a rinse hold in order to

prevent the formation of creases. The control lamp keeps lighted. You can finish these programmes by

aspinning (by releasingthe rinseholdpushbutton)orbyadraining(bydepressing theon/off pushbutton

"" and by choosing the programme P).

BE CAREFUL :

THE LID CAN ONLY BE OPENED 90 SECONDS AFTER THE MACHINE HAS STOPPED.

semmargorP emmargorP snoitpircsed serutarepmeT C°snoitpircseD elcycehtfo

*snoitpmusnoC

retaW )l( ygrenE )hWk( emiT )nim(

+scitehtnyS °06-°04

°04othsawerP °06-°04othsaW sgnisnir3 gninnipstrohS

062,159

scitehtnyS °06-°04

°06-°04othsaW sgnisnir3 gninnipstrohS

740,108

emmargorpkciuQ °04-°03

°06-°03othsaW sgnisnir3 gninnipstrohS

7455,056

etacileD °04-°03

°04-°03othsaW sgnisnir3 gninnipstrohS

7455,055

looW °04-

°04-othsaW sgnisnir3 gninnipstrohS

545,005

sgnisniR

sgnisnir3 gninnipstrohS

3340,052

gninnipstrohS

020,08

niarD

004

Other manuals for T 613

Table of contents

Other Zanussi Washer manuals

Zanussi

Zanussi ZWF 1210W User manual

Zanussi

Zanussi FLS 896 V Quick guide

Zanussi

Zanussi ZWGB 7140 AS User manual

Zanussi

Zanussi ZWQ 7100 SO User manual

Zanussi

Zanussi ZWF844B3PW User manual

Zanussi

Zanussi FL 726 CN User manual

Zanussi

Zanussi FL 1281 User manual

Zanussi

Zanussi ZWF 14380 S User manual

Zanussi

Zanussi TSE1062V User manual

Zanussi

Zanussi TA522 User manual

Zanussi

Zanussi FA831E User manual

Zanussi

Zanussi TL1033 Operating and safety instructions

Zanussi

Zanussi ZT 1082 User manual

Zanussi

Zanussi ZWF 91483W User manual

Zanussi

Zanussi ZWF 01280W User manual

Zanussi

Zanussi ZWQ71265CE User manual

Zanussi

Zanussi ZT938 Operating and safety instructions

Zanussi

Zanussi ZWF 1840 W Operation manual

Zanussi

Zanussi ZWF 16281 W User manual

Zanussi

Zanussi ZWF 1221 G User manual

Zanussi

Zanussi TLS592C User manual

Zanussi

Zanussi ZF 623 User manual

Zanussi

Zanussi ZW7F3946LS User manual

Zanussi

Zanussi FL 884 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
