Zanussi FLD 1200 User manual

LAVADORA

WASHING

MACHINE

FLD 1000 - FLD 1200

MANUAL DE USO

USER MANUAL

124970870 GB

124970870.qxd 6/27/01 11:00 PM Pagina 1 (Nero/Process Black pellicola)

ENGLISH

Dear customer,

Please read these operating instructions carefully

and pay particular attention to the safety notes

indicated in the first pages. We recommend that you

keep this instruction booklet for future reference and

pass it on to any future owners.

Transport damages

When unpacking the appliance, check that it is not

damaged. If in doubt, do not use it and contact the

Service Centre.

The symbols you will see on some paragraphs of this booklet have the following meaning:

The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly

important for your safety or correct functioning of the appliance.

The information marked with this symbol provides additional instructions and practical tips on the use of

the appliance.

Tips and information about economical and ecological use of the machine are marked with this symbol.

Our contribution to the protection of the

environment: we use recycled paper.

124970870.qxd 6/27/01 11:00 PM Pagina 23 (Nero/Process Black pellicola)

Maintenance 40

Bodywork 40

Detergent dispenser drawer 40

Drain filter 40

Water inlet filter 40

Emergency emptying out 41

Frost precautions 41

Something not working? 42-43

Warnings 25-26

Disposal 26

Tips for environmental protection 26

Technical specifications 27

Installation 28

Unpacking 28

Positioning 28

Water inlet 28

Water drainage 29

Electrical connection 29

Door reversal 30

Your new washing machine 31

Description of the appliance 31

Detergent dispenser drawer 31

Use 32

Control panel 32

Controls 32

Washing hints 33

Sorting the laundry 33

Temperatures 33

Before loading the laundry 33

Maximum loads 33

Laundry weights 33

Removing stains 33

Detergents and additives 34

International wash code symbols 35

Operating sequence 36-37

Washing programmes 38-39

Contents

124970870.qxd 6/27/01 11:00 PM Pagina 24 (Nero/Process Black pellicola)

ENGLISH

Installation

•All internal packing must be removed before using

the appliance. Serious damage may be caused to

the machine or adjacent furniture if the protective

transit devices are not removed or are not

completely removed. Refer to the relevant

paragraph in the instruction book.

•Any electrical work required to install this appliance

must be carried out by a qualified electrician.

•Any plumbing work required to install this

appliance must be carried out by a qualified

plumber.

•After having installed the machine, check that it is

not standing on its electrical supply cable.

•If the appliance is placed on a carpeted floor,

ensure that air can circulate freely between the feet

and the floor.

Use

•This appliance is designed for domestic use. It

must not be used for purposes other than those for

which it was designed.

•Only wash fabrics which are designed to be

machine washed. Follow the instructions on each

garment label.

•Do not overload the appliance. Follow the

instructions in the instruction book.

•Make sure that all pockets are empty. Objects such

as coins, safety pins, pins and screws can cause

extensive damage.

•Do not machine wash garments saturated with

petroleum, methylated spirits, trichlorethylene, etc.

If such fluids have been used to remove stains

prior to washing, wait until they have completely

evaporated from the fabric before placing garments

in the appliance.

•Place small items such as socks, belts, etc. in a

cloth bag or pillowcase to prevent them getting

trapped between the drum and the tub.

•Use only the recommended quantities of fabric

softener. An excessive amount could damage the

laundry.

Warnings

•Leave the porthole door slightly ajar when the

appliance is not in use. This preserves the door

seal and prevents the formation of musty smells.

•Always check that water has emptied out before

opening the door. If not, drain the water following

the instructions in the instruction book.

•Always unplug the appliance and shut the water

tap after use.

General safety

•Repairs to the machine must be carried out only by

qualified personnel. Repairs carried out by

inexperienced persons could cause serious

danger. Contact your local Service Centre.

•Never pull the power supply cable to remove the

plug from the socket; always take hold of the plug

itself.

•During high temperature wash programmes the

door glass may get hot. Do not touch it!

The following warnings are provided in the interests of overall safety. You must read them carefully before

installing or using the appliance.

124970870.qxd 6/27/01 11:00 PM Pagina 25 (Nero/Process Black pellicola)

Disposal

Tips for environmental protection

Packaging materials

The materials marked with the symbol are

recyclable.

>PE<=polyethylene

>PS<=polystyrene

>PP<=polypropylene

This means that they can be recycled by disposing of

them properly in appropriate collection containers.

Machine

Use authorised disposal sites for your old appliance.

Help to keep your country tidy!

To save water, energy and to help protect the

environment, we recommend that you follow these

tips:

•Normally soiled laundry may be washed without

prewashing in order to save detergent, water and

time (the environment is protected too!).

•The machine works more economically if it is fully

loaded.

•With adequate pre-treatment, stains and limited

soiling can be removed; the laundry can then be

washed at a lower temperature.

•Measure out detergent according to the water

hardness, the degree of soiling and the quantity of

laundry being washed.

Child safety

•Children are often not aware of how dangerous

electrical appliances can be. When the machine is

working, children should be carefully supervised

and not be allowed to play with the appliance.

•The packaging components (e.g. plastic film,

polystyrene) can be dangerous to children - danger

of suffocation! Keep them out of children’s reach.

•Keep all detergents in a safe place out of children’s

reach.

•Make sure that children or pets do not climb into

the drum.

•When the appliance is to be scrapped, cut off the

electrical supply cable and destroy the plug with

the remaining cable. Disable the door catch in

order to prevent children from becoming trapped

inside while playing.

124970870.qxd 6/27/01 11:00 PM Pagina 26 (Nero/Process Black pellicola)

ENGLISH

DIMENSIONS Height 85 cm

Width 60 cm

Depth 60 cm

MAXIMUM LOAD Cotton 5 kg

Synthetics 2 kg

Delicates 2 kg

Woollens 1 kg

SPIN SPEED 1000 rpm max. (FLD 1000)

1200 rpm max. (FLD 1200)

POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz

TOTAL POWER ABSORBED 2200 W

MINIMUM FUSE PROTECTION 10 A

WATER PRESSURE Minimum 50 kPa

Maximum 800 kPa

This appliance complies with the following EEC Directives:

73/23/EEC of 19/02/73 relating to low voltage

89/336/EEC of 03/05/89 relating to electromagnetic compatibility.

Technical specifications

124970870.qxd 6/27/01 11:00 PM Pagina 27 (Nero/Process Black pellicola)

Unpacking

All transit bolts and packing must be removed

before using the appliance.

You are advised to keep all transit devices so that

they can be refitted if the machine ever has to be

transported again.

1. Using a spanner, unscrew and remove the rear

right-hand bolt and lay the machine on its back,

taking care not to squash the hoses. This can be

avoided by placing one of the corner packing

pieces between the machine and the floor.

2. Remove the polystyrene block from the bottom of

the machine and release the two plastic bags.

3. Carefully remove the right-hand bag (1) then the

left-hand bag (2) by pulling them towards the

centre of the machine.

4. Set the machine upright and remove the two

remaining bolts from the back.

5. Pull out the three plastic spacers from the holes

into which the bolts were fitted.

6. Plug the open holes with the plugs which you will

find at the back of the appliance.

P0020

P0256

P1066

P1068

P0255

Positioning

Install the machine on a flat hard floor.

Make sure that air circulation around the machine is

not impeded by carpets, rugs etc. Check that the

machine does not touch the wall or other kitchen

units.

Carefully level by screwing the adjustable feet in or

out. Never place cardboard, wood or similar

materials under the machine to compensate for any

unevenness in the floor.

Water inlet

Connect the water inlet hose to a tap with a 3/4"

thread.

The other end of the inlet hose which connects to the

machine can be turned in any direction. Simply

loosen the fitting, rotate the hose and retighten the

fitting, making sure there are no water leaks.

The inlet hose must not be lengthened. If it is too

short and you do not wish to move the tap, you will

have to purchase a new, longer hose specially

designed for this type of use.

P0021

P1088

P1051

Installation

124970870.qxd 6/27/01 11:00 PM Pagina 28 (Nero/Process Black pellicola)

ENGLISH

Water drainage

The end of the drain hose can be positioned in three

ways:

Hooked over the edge of a sink using the plastic

hose guide supplied with the machine. In this

case, make sure the end cannot come unhooked

when the machine is emptying.

This could be done by tying it to the tap with a piece

of string or attaching it to the wall.

In a sink drain pipe branch. This branch must be

above the trap so that the bend is at least 60 cm

above the ground.

Directly into a drain pipe at a height of not less

than 60 cm and not more than 90 cm.

The end of the drain hose must always be

ventilated, i.e. the inside diameter of the drain pipe

must be larger than the outside diameter of the drain

hose.

The drain hose must not be kinked. Run it along the

floor; only the part near the drainage point must be

raised.

P0023

P0022

Electrical connection

This machine is designed to operate on a 220-230 V,

single-phase, 50 Hz supply.

Check that your domestic electrical installation can

take the maximum load required (2.2 kW), also

taking into account any other appliances in use.

Connect the machine to an earthed socket.

The manufacturer declines any responsibility

for damage or injury through failure to comply

with the above safety precaution.

Should the appliance power supply cable

need to be replaced, this should be carried

out by our Service Centre.

Important!

When the appliance is installed the power supply

cable must be easily accessible.

124970870.qxd 6/27/01 11:00 PM Pagina 29 (Nero/Process Black pellicola)

Door reversal

The opening direction of the outer door on this

washing machine can be reversed. To carry out this

operation, proceed as follows:

1) Disengage the end of the opening stop (1)

from the door and turn it through 90°to

remove it from its seat (Fig. A).

2) Using a screwdriver, turn plastic plug (2)

through 90°to remove it from its seat (Fig. A).

3 ) Fit plug (2) in the hole left free by opening stop

(1 ) and turn it through 90°to lock it into place

(Fig. B).

4) Fit opening stop (1) into the hole from which

plug (2) was removed and turn it through 90°,

making sure that the latching tooth is facing

towards the right (Fig. B).

5) Remove the door by unscrewing the screws

securing it to the bottom hinge (3 - Fig. A).

6) Unscrew the two plastic screws (4 - Fig. A)

and fit them on the opposite side (4 - Fig. B).

7) Remove the catch hook (5 - Fig. A) by

inserting a screwdriver into the upper hole and

pushing downwards.

8) Remove plate (6) by inserting a screwdriver

into the bottom hole and pushing upwards

(Fig. A).

9) Refit the catch hook (5) and plate (6) on the

opposite sides.(Fig. B).

10) Remove the door catch (7) and plate (8) as

explained in paragraph 7.

11) Turn the door through 180°.

12) Refit the door catch (7) and plate (8), reversing

their position and pressing firmly to engage

the hook (Fig. B).

13) Fit the door onto the washing machine. Insert

the top pin first, then the bottom pin into the

hinge (3 - Fig. B); finally screw the hinge onto

the washing machine.

14) Check that the door is aligned with the

appliance. To do this, loosen screw (9 - Fig. B)

by a couple of turns and re-tighten when

alignment is correct.

15) Fit the flexible end of the door opening stop

into the location provided in the door (1 - Fig.

B).

Fitting a door panel

The door of this washing machine has mouldings to

allow fitting of a decorative panel (stainless steel

sheet, laminated plastic, wood, etc.) to match with

the existing kitchen units.

The dimensions of the panel must be as follows:

Width 588 mm

Height 588 mm

Maximum thickness 4 mm

To fit the panel, remove the moulding by unscrewing

its fixing screws. Position the panel, then refit the

moulding, making sure that it comes into contact with

and firmly clamps the panel.

P0535

P0534

391

124970870.qxd 6/27/01 11:00 PM Pagina 30 (Nero/Process Black pellicola)

ENGLISH

This new machine meets all modern requirements for effective treatment of laundry with low water, energy and

detergent consumption.

•The temperature selector dial will allow you to choose the most suitable temperature for your laundry.

•The automatic cooling of the washing water from 90°to 60°C before draining will prevent old drain pipes

from being deformed.

•The balance control device ensures the machine is stable during the spin.

1 Detergent dispenser drawer

2 Programme chart

3 Control panel

4 Door handle

5 Drain filter

6 Adjustable feet

Detergent dispenser drawer

Prewash

Main wash

Fabric softener, starch

Bleaching agent

Your new washing machine

Description of the appliance

P0446

124970870.qxd 6/27/01 11:00 PM Pagina 31 (Nero/Process Black pellicola)

Table of contents

Other Zanussi Washer manuals

Zanussi

Zanussi F1003 W User manual

Zanussi

Zanussi ZE 2002 iS Assembly instructions

Zanussi

Zanussi TL1004V User manual

Zanussi

Zanussi Z814W85BI User manual

Zanussi

Zanussi FLS874CN User manual

Zanussi

Zanussi ZWG 3162 User manual

Zanussi

Zanussi ZWG580E User manual

Zanussi

Zanussi ZWF 12380W User manual

Zanussi

Zanussi FLD684 Quick guide

Zanussi

Zanussi TL1000 User manual

Zanussi

Zanussi ZWI 71000 WA User manual

Zanussi

Zanussi TL552C User manual

Zanussi

Zanussi Z929T Operating and safety instructions

Zanussi

Zanussi ZI959T Operating and safety instructions

Zanussi

Zanussi ZFL850 Operating and safety instructions

Zanussi

Zanussi FLS472C User manual

Zanussi

Zanussi DL4 Assembly instructions

Zanussi

Zanussi RW 801 Assembly instructions

Zanussi

Zanussi F503 User manual

Zanussi

Zanussi ZWF2105W2 User manual

Zanussi

Zanussi F805N User manual

Zanussi

Zanussi ZWX 1505 W User manual

Zanussi

Zanussi FJ1224/A User manual

Zanussi

Zanussi ZJ 124 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
