Zanussi Professional Snack 600 User manual

ZANUSSI

P R O F E S S I O N A L

PASTA COOKERS

SNACK 600

SCPE 350

Supply voltage 400 V, 3N, 50/60

Net weight - kg. 33 35

installed-electric 5

Power - kW

gas 10

Power - kW

N° of wells 1 1

height 290 290

depth 340 340

width 305 305

Usable well dimensions - mm

height 850 850

depth 600 600

width 350 350

External dimensions - mm

Power supply Electric Gas

SCPE350

285758

SCPG350

285772

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION

Ideal for smaller sized catering

establishments: bars, pubs, fast food

outlets, pizzerias and small hotels;

the Snack 600 range of modular

cooking appliances consists of a

series of appliances each with a

depth of 600 mm - in gas and

electric - featuring high power for

fast service whether in table top

situations, where space is at a

premium, or in a complete cooking

installation, using the base units that

can include doors, drawers or

runners for gastronorm containers.

FUNCTIONAL AND

CONSTRUCTION

FEATURES

� Constructed completely in 18/10,

304 AISI stainless steel to guarantee

a hard-wearing performance. The

units include stainless steel height

adjustable feet

� Hygiene guaranteed by rounded

edges, flush fit between units, side

upstands and sealing joints,

completely smooth and easy to

clean surfaces

� Stainless steel pressed well, 15/10

in thickness, for use with 2/3 GN

containers/baskets.

� Overflow and water drain by

means of an overflowpipe

� Well filling by means of an

overflowpipe

� False bottom, to support the

baskets, supplied as standard.

� Baskets are not supplied as

standard and therefore must be

ordered as accessories

� All models comply with the

standards required by the main

international approval bodies and

are H marked.

ELECTRIC MODELS

� Heating via incoloy armoured

steel elements placed under the well

� Thermostatic temperature control

� High limit safety thermostat

GAS MODELS

� Burners placed under the well

� Automatic piezo ignition, flame

failure device and pilot light

� The gas appliances are supplied

for use with natural gas, with LPG

conversion jets supplied as standard.

� Tap valve.

installation diagram: B - Cold water inlet; C - Water

drain

BAAH1 2010-05-28 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

GULLEY WITH JOINING PANEL FOR 600 LINE 285798 285798

GN 2/3 BASKET FOR PASTA COOKER 285796 285796

4 GN 1/6 BASKETS FOR PASTA COOKER 285805 285805

2 GN 1/3 BASKETS FOR PASTA COOKER 285804 285804

SCPE350

285758

SCPG350

285772

ACCESSORIES MODELS

OPTIONAL ACCESSORIES

G - Gas connection 1/2"

EI - Electrical connection 400 V, 3N, 50/60

SCPE350

285758

SCPG350

285772

LEGEND

285758 285772
