ZANKER KOB65962XK User manual
KOB65962XK
User Manual
Oven
Benutzerin‐
formation
Backofen
Contents
Safety information 2
Safety instructions 3
Product description 5
Control panel 5
Before first use 6
Daily use 6
Clock functions 8
Using the accessories 9
Additional functions 9
Hints and tips 10
Care and cleaning 20
Troubleshooting 23
Installation 24
Energy efficiency 25
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read the supplied
instructions. The manufacturer is not responsible for any injuries or damages
that are the result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a safe way and
understand the hazards involved.
•Children between 3 and 8 years of age and persons with very extensive
and complex disabilities shall be kept away unless continuously
supervised.
•Children of less than 3 years of age should be kept away unless
continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it appropriately.
•Keep children and pets away from the appliance when it operates or when
it cools down. Accessible parts are hot.
•If the appliance has a child safety device, it should be activated.
•Children shall not carry out cleaning and user maintenance of the
appliance without supervision.
General Safety
•Only a qualified person must install this appliance and replace the cable.
2
•WARNING: The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating elements.
•Always use oven gloves to remove or put in accessories or ovenware.
•Before carrying out any maintenance, disconnect the appliance from the
power supply.
•Ensure that the appliance is switched off before replacing the lamp to
avoid the possibility of electric shock.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
glass door since they can scratch the surface, which may result in
shattering of the glass.
•If the mains power supply cable is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly qualified persons
to avoid an electrical hazard.
•To remove the shelf supports first pull the front of the shelf support and
then the rear end away from the side walls. Install the shelf supports in the
opposite sequence.
Safety instructions
Installation
Warning! Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instructions supplied with the
appliance.
• Always take care when moving the appliance as it is
heavy. Always use safety gloves and enclosed
footwear.
• Do not pull the appliance by the handle.
• Keep the minimum distance from other appliances
and units.
• Install the appliance in a safe and suitable place that
meets installation requirements.
• The appliance is equipped with an electric cooling
system. It must be operated with the electric power
supply.
Electrical connection
Warning! Risk of fire and electric shock.
• All electrical connections should be made by a
qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the rating plate
are compatible with the electrical ratings of the
mains power supply.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension
cables.
• Make sure not to cause damage to the mains plug
and to the mains cable. Should the mains cable
need to be replaced, this must be carried out by our
Authorised Service Centre.
• Do not let mains cables touch or come near the
appliance door, especially when the door is hot.
• The shock protection of live and insulated parts
must be fastened in such a way that it cannot be
removed without tools.
• Connect the mains plug to the mains socket only at
the end of the installation. Make sure that there is
access to the mains plug after the installation.
• If the mains socket is loose, do not connect the
mains plug.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting
cut-outs, fuses (screw type fuses removed from the
holder), earth leakage trips and contactors.
3
• The electrical installation must have an isolation
device which lets you disconnect the appliance from
the mains at all poles. The isolation device must
have a contact opening width of minimum 3 mm.
• This appliance complies with the E.E.C. Directives.
Use
Warning! Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use only.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not
blocked.
• Do not let the appliance stay unattended during
operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance door while
the appliance is in operation. Hot air can release.
• Do not operate the appliance with wet hands or
when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface or as a
storage surface.
• Open the appliance door carefully. The use of
ingredients with alcohol can cause a mixture of
alcohol and air.
• Do not let sparks or open flames to come in contact
with the appliance when you open the door.
• Do not put flammable products or items that are wet
with flammable products in, near or on the
appliance.
Warning! Risk of damage to the
appliance.
• To prevent damage or discoloration to the enamel:
– do not put aluminium foil directly on the bottom
of cavity of the appliance.
– do not put water directly into the hot appliance.
– do not keep moist dishes and food in the
appliance after you finish the cooking.
– be careful when you remove or install the
accessories.
• Discoloration of the enamel or stainless steel has no
effect on the performance of the appliance.
• Use a deep pan for moist cakes. Fruit juices cause
stains that can be permanent.
• This appliance is for cooking purposes only. It must
not be used for other purposes, for example room
heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a furniture panel
(e.g. a door) make sure the door is never closed
when the appliance is in operation. Heat and
moisture can build up behind a closed furniture
panel and cause subsequent damage to the
appliance, the housing unit or the floor. Do not close
the furniture panel until the appliance has cooled
down completely after use.
Care and cleaning
Warning! Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
• Make sure the appliance is cold. There is the risk
that the glass panels can break.
• Replace immediately the door glass panels when
they are damaged. Contact the Authorised Service
Centre.
• Be careful when you remove the door from the
appliance. The door is heavy!
• Clean regularly the appliance to prevent the
deterioration of the surface material.
• Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use any abrasive
products, abrasive cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the safety
instruction on it's packaging.
• Do not clean the catalytic enamel (if applicable) with
any kind of detergent.
Internal lighting
Warning! Risk of electric shock.
• The type of light bulb or halogen lamp used for this
appliance is for household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect the appliance
from the power supply.
• Only use lamps with the same specifications.
Service
• To repair the appliance contact an Authorised
Service Centre.
• Use original spare parts only.
Disposal
Warning! Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains electrical cable close to the
appliance and dispose of it.
• Remove the door catch to prevent children or pets
from becoming trapped in the appliance.
4
Product description
General overview
8
7
12
11
5
4
1
2
3
4 631 52
9
10
1Control panel
2Knob for the heating functions
3Power lamp / symbol
4Display
5Control knob (for the temperature)
6Temperature indicator / symbol
7Heating element
8Lamp
9Fan
10 Cavity embossment
11 Shelf support, removable
12 Shelf positions
Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Combi pan
For cakes and biscuits. To bake and roast or as a
pan to collect fat.
Control panel
Buttons
Sensor field / Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.
Display
A B C
A. Clock functions
B. Timer
C. Clock function
5
Before first use
Warning! Refer to Safety chapters.
To set the Time of day refer to "Clock
functions" chapter.
Initial Cleaning
Remove all accessories and removable shelf supports
from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories before first use.
Put the accessories and the removable shelf supports
back to their initial position.
Preheating
Preheat the empty oven before first use.
For function: True Fan Cooking PLUS
refer to "Daily use" chapter, Setting the
function: True Fan Cooking PLUS".
1. Set the function .Set the maximum temperature.
2. Let the oven operate for 1 hour.
3. Set the function . Set the maximum
temperature.
4. Let the oven operate for 15 minutes.
5. Set the function . Set the maximum
temperature.
6. Let the oven operate for 15 minutes.
7. Turn off the oven and let it cool down.
Accessories can become hotter than usual. The oven
can emit an odour and smoke. Make sure that the
airflow in the room is sufficient.
Daily use
Warning! Refer to Safety chapters.
Retractable knobs
To use the appliance press the knob. The knob comes
out.
Setting a heating function
1. Turn the knob for the heating functions to select a
heating function.
2. Turn the control knob to select the temperature.
The lamp turns on when the oven operates.
3. To turn off the oven, turn the knob for the heating
functions to the off position.
Heating functions
Oven function Application
Off position
The oven is off.
Light
To turn on the lamp without a
cooking function.
Oven function Application
True Fan +
Steam
To steam dishes. Use this func-
tion to decrease the length of
the cooking time and to pre-
serve the vitamins and nutrients
in the food. Select the function
and set the temperature be-
tween 130 °C to 230 °C.
6
Oven function Application
Moist Fan Bak-
ing
This function is designed to
save energy during cooking.
For the cooking instructions re-
fer to "Hints and tips" chapter,
Moist Fan Baking. The oven
door should be closed during
cooking so that the function is
not interrupted and to ensure
that the oven operates with the
highest energy efficiency possi-
ble. When you use this function,
the temperature in the cavity
may differ from the set temper-
ature. The heating power may
be reduced. For general energy
saving recommendations refer
to "Energy Efficiency" chapter,
Energy Saving.This function
was used to comply with the
energy efficiency class accord-
ing to EN 60350-1.
Bottom Heat
To bake cakes with crispy bot-
tom and to preserve food.
True Fan Cook-
ing
To bake on up to three shelf po-
sitions at the same time and to
dry food.
Set the temperature 20 - 40 °C
lower than for Conventional
Cooking.
Turbo Grilling
To roast larger meat joints or
poultry with bones on one shelf
position. To make gratins and
to brown.
Fast Grilling
To grill flat food in large quanti-
ties and to toast bread.
Pizza Setting
To bake pizza. To make inten-
sive browning and a crispy bot-
tom.
Oven function Application
Conventional
Cooking (Top /
Bottom Heat)
To bake and roast food on one
shelf position.
Setting the function:True Fan Cooking PLUS
This function allows to improve humidity during the
cooking.
Warning! Risk of burns and damage to
the appliance.
Released humidity can cause burns:
• Do not open the oven door when the function works.
• Open the oven door with care after the function
stops.
Refer to “Hints and tips” chapter.
1. Fill the cavity embossment with tap water.
The maximum capacity of the cavity embossment
is 250 ml.
Fill the cavity embossment with water only when
the oven is cold.
Caution! Do not refill the cavity
embossment with water during
cooking or when the oven is hot.
2. Put food in the oven and close the oven door.
3. Set the function: .
4. Turn the control knob to select a temperature.
5. Turn the knob for the heating functions to the off
position to turn off the oven.
6. Remove water from the cavity embossment.
7
Warning! Make sure that the oven
is cold before you remove the
remaining water from the cavity
embossment.
Clock functions
Clock functions table
Clock function Application
TIME OF DAY To set, change or check the time of day.
DURATION To set how long the appliance operates.
END To set when the appliance deactivates.
TIME DELAY To combine DURATION and END function.
MINUTE MINDER To set countdown time. This function has no effect on the operation of the
appliance. You can set the MINUTE MINDER at any time, also when the ap-
pliance is off.
Setting the time. Changing the time
You must set the time before you operate the oven.
The flashes when you connect the appliance to the
electrical supply, when there was a power cut or when
the timer is not set.
Press the or to set the correct time.
After approximately five seconds, the flashing stops and
the display shows the time of day you set.
To change the time of day press again and again
until starts to flash.
Setting the DURATION
1. Set an oven function and temperature.
2. Press again and again until starts to flash.
3. Press or to set the DURATION time.
The display shows .
4. When the time ends, flashes and an acoustic
signal sounds. The appliance deactivates
automatically.
5. Press any button to stop the acoustic signal.
6. Turn the knob for the oven functions and the knob
for the temperature to the off position.
Setting the END
1. Set an oven function and temperature.
2. Press again and again until starts to flash.
3. Press or to set the time.
The display shows .
4. When the time ends, flashes and an acoustic
signal sounds. The appliance deactivates
automatically.
5. Press any button to stop the signal.
6. Turn the knob for the oven functions and the knob
for the temperature to the off position.
Setting the TIME DELAY
1. Set an oven function and temperature.
2. Press again and again until starts to flash.
3. Press or to set the time for DURATION.
4. Press .
5. Press or to set the time for END.
6. Press to confirm.
Appliance turns on automatically later on, works for the
set DURATION time and stops at the set END time. At
the set time an acoustic signal sounds.
7. The appliance deactivates automatically. Press any
button to stop the signal.
8
8. Turn the knob for the oven functions and the knob
for the temperature to the off position.
Setting the MINUTE MINDER
1. Press again and again until starts to flash.
2. Press or to set the necessary time.
The Minute Minder starts automatically after 5 seconds.
3. When the set time ends, an acoustic signal sounds.
Press any button to stop the acoustic signal.
4. Turn the knob for the oven functions and the knob
for the temperature to the off position.
Cancelling the clock functions
1. Press the again and again until the necessary
function indicator starts to flash.
2. Press and hold .
The clock function goes out after some seconds.
Using the accessories
Warning! Refer to Safety chapters.
Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of the shelf
support and make sure that the feet point down.
Deep pan:
Push the deep pan between the guide bars of the shelf
support.
Wire shelf and deep pan together:
Push the deep pan between the guide bars of the shelf
support and the wire shelf on the guide bars above.
Small indentation at the top increase
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the
shelf.
Additional functions
Cooling fan
When the oven operates, the cooling fan turns on
automatically to keep the surfaces of the oven cool. If
you turn off the oven, the cooling fan can continues to
operate until the oven cools down.
9
Safety thermostat
Incorrect operation of the oven or defective components
can cause dangerous overheating. To prevent this, the
oven has a safety thermostat which interrupts the power
supply. The oven turns on again automatically when the
temperature drops.
Hints and tips
Warning! Refer to Safety chapters.
The temperature and baking times in the
tables are guidelines only. They depend
on the recipes and the quality and
quantity of the ingredients used.
Cooking recommendations
The oven has five shelf positions.
Count the shelf positions from the bottom of the oven
floor.
Your oven may bake or roast differently to the oven you
had before. The below tables provide you with the
standard settings for temperature, cooking time and
shelf position.
If you cannot find the settings for a special recipe, look
for the similar one.
The oven has a special system which circulates the air
and constantly recycles the steam. With this system you
can cook in a steamy environment and keep the food
soft inside and crusty outside. It decreases the cooking
time and energy consumption.
Baking cakes
Do not open the oven door before 3/4 of the set cooking
time is up.
If you use two baking trays at the same time, keep one
empty level between them.
Cooking meat and fish
Use a deep pan for very fatty food to prevent the oven
from stains that can be permanent.
Leave the meat for approximately 15 minutes before
carving so that the juice does not seep out.
To prevent too much smoke in the oven during roasting,
add some water into the deep pan. To prevent the
smoke condensation, add water each time after it dries
up.
Cooking times
Cooking times depend on the type of food, its
consistency, and volume.
Initially, monitor the performance when you cook. Find
the best settings (heat setting, cooking time, etc.) for
your cookware, recipes and quantities when you use
this appliance.
True Fan Cooking PLUS
Cakes / pastries / breads
Preheat the empty oven for 5 minutes.
Use the baking tray.
Use the second shelf position.
Food Water in the cavity em-
bossment (ml)
Temperature (°C) Time (min)
Cookies, scones, crois-
sants
100 150 - 180 10 - 20
Focaccia 100 200 - 210 10 - 20
Pizza 100 230 10 - 20
Bread rolls 100 200 20 - 25
Bread 100 180 35 - 40
10
Table of contents
Languages:
Other ZANKER Oven manuals
ZANKER
ZANKER KOB65963XK User manual
ZANKER
ZANKER ZKB 7613 User manual
ZANKER
ZANKER ZKH 7528 User manual
ZANKER
ZANKER KOB25724XK User manual
ZANKER
ZANKER KOB65902XK User manual
ZANKER
ZANKER KOU25723XK User manual
ZANKER
ZANKER KOB25723XK User manual
ZANKER
ZANKER KOU20721XK User manual
ZANKER
ZANKER KOB57602 User manual
ZANKER
ZANKER KOB10401XB User manual
ZANKER
ZANKER KOU10301 User manual
ZANKER
ZANKER KOU25724XK User manual
ZANKER
ZANKER ZKB 7238 Operation manual
ZANKER
ZANKER ZKH 7629 User manual
ZANKER
ZANKER KOU10411XB User manual
ZANKER
ZANKER KOU65902XK User manual
ZANKER
ZANKER KOB57602XK User manual
ZANKER
ZANKER KOB55602 User manual
ZANKER
ZANKER KOU20611 User manual
ZANKER
ZANKER ZKH 7227 User manual
