Xtreme Power Conversion XVT 600VA Guide

XSTi Standby UPS

400VA, 600VA, 800VA Models

User & Installaon Manual

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 2

Uninterrupble Power Supply

Table of Contents

Package Contents........................................................................................ 3

Product Introducon................................................................................... 3

Product Overview........................................................................................ 3

Installaon & Inial Startup.........................................................................4

Indicators & Alarm Condions......................................................................5

Troubleshoong...........................................................................................6

Specicaons...............................................................................................7

Obtaining Service.........................................................................................8

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 3

Uninterrupble Power Supply

Package Contents

You should be receiving the following items inside the package:

• UPS Unit

• User Manual

• Local Monitoring Soware CD - XSTi-600/800 models

• USB cable - XSTi-600/800 models

Product Introducon

Thank you for selecng this uninterrupble power supply (UPS). It provides you with protecon for connected

equipment. Please read this manual before installing the XSTi Series UPS models XSTi-400, XSTi-600, and XSTi-800

as it provides important informaon that should be followed during installaon and maintenance of the UPS and

baeries, allowing you to correctly set up your system for the maximum safety and performance. Included is infor-

maon on customer support and service, if it is required. If you experience a problem with the UPS, please refer to

the Troubleshoong secon in this manual to correct the problem. If the problem is not corrected, please collect

informaon so that the Technical Support personnel can more eecvely assist you.

Product Overview

The XSTi Series UPS provides comprehensive protecon in a small and economical package. This UPS is compact,

oering greater power. The XSTi has been designed with a microprocessor to guarantee high reliability, and pro-

vides stable power to connected equipment, enabling shutdown of your PC or other equipment safely during a

power failure. It’s a perfect soluon for any home or small oce environment.

Front view

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 4

Uninterrupble Power Supply

Rear view

Installaon & Inial Startup

Note: Before installaon, inspect the unit and packaging to make sure that nothing inside has been damaged.

Placement & Storage

Install the UPS in a protected area that is free of excessive dust and has adequate air ow. Place the UPS away

from other units at least 7.8 in (20 cm) to avoid interference. DO NOT operate the UPS where the temperature and

humidity is outside the specied limits. (See Specicaons for details).

7.8 in

Connect UPS to Ulity and Charging

Before the inial use of the UPS, plug the UPS input cord into a wall outlet and turn the UPS on by depressing the

Power switch on the front of the UPS. For best results, the baeries in the UPS should be charged for at least 8

hours before use. The UPS charges its baery while it is connected to AC ulity power and powered on.

CAUTION: NEVER connect a laser printer or scanner to the UPS. This may cause damage to the unit.

Connecng the Loads

Plug the loads to be supported by the UPS into the output receptacles on the rear of the UPS. Simply turn the

power switch on the UPS on and the devices connected to the UPS will be protected by the UPS unit.

Turn UPS ON / OFF

To turn the UPS unit on, press the Power switch on the front of the UPS. To turn the UPS unit o, press the Power

switch on the front of the unit again.

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 5

Uninterrupble Power Supply

Connecng Local Monitoring Soware (oponal)

If it is desired to use the Local Monitoring Soware, and if your UPS is equipped with USB communicaons, con-

nect a USB cable from your computer to the UPS, and install the soware from the CD.

Indicators & Alarm Condions

Condion Visual Indicator Alarm

AC mode Blue LED illuminated No Audible Alarm

Baery mode Blue LED ashes every 10 seconds Audible Alarm sounds every 10

seconds

Low baery mode Blue LED ashes every 1 second

and Red LED is illuminated

Audible Alarm sounds every 1

second

Fault Red LED is illuminated Audible Alarm is connuous

Alarm for over temperature protec-

on Red LED ashes every 0.5 seconds No Audible Alarm

IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS)

CAUTION! (UPS having Internal Baeries): Risk of electrical shock – Hazardous live parts inside this unit are ener-

gized from the baery supply even when the input AC power is disconnected.

CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover. No user serviceable parts

inside. Refer servicing to qualied service personnel.

CAUTION! (Non-isolated Baery supply): Risk of electric shock, baery circuit is not isolated from AC input, haz-

ardous voltage may exist between baery terminals and ground. Test before touching.

WARNING! Unit intended for installaon in a controlled environment.

CAUTION! Do not dispose of baeries in a re, the baery may explode.

CAUTION! Do not open or mulate the baery, released electrolyte is harmful to the skin and eyes.

CAUTION! A baery can present a risk of electric shock and high short circuit current. The following precauon

should be observed when working on baeries:

• Remove watches, rings or other metal objects.

• Use tools with insulated handles.

To reduce the risk of electric shock, disconnect the UPS from the main supply before installing a computer inter-

face signal cable. Reconnect the power cord only aer signaling interconnecons have been made.

Servicing of baeries should be performed or supervised by personnel with knowledge of baeries and the re-

quired precauons. Keep unauthorized personnel away from baeries.

The instrucons contained within this safety manual are deemed important and should be closely followed at all

mes during installaon and follow-up maintenance of the UPS and baeries.

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 6

Uninterrupble Power Supply

CAUTION: The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s outlets may

have a dangerous amount of voltage even when not plugged into the wall outlet because the baery may

connue to supply power. Care should be taken to undertake installaon indoors, free from electrically-

conducve parcles which are under temperature and humidity control, in order to reduce the risk of

electric shock. It is best to disconnect the device using the power supply cord. Ensure that the equipment

is placed in a posion near the outlet where easily accessible. All servicing on this equipment must be

carried out by qualied service personnel. Before conducng any maintenance, repair, or shipment, rst

ensure that everything is turned o completely and disconnected.

Troubleshoong

Condion Visual Indicator Alarm

No LED display on the front UPS

panel

Low baery Charge the UPS at least 8 hours

Baery fault Replace the baery with the same

type of baery

The UPS is not turned on Press the Power Switch on the front

of the UPS

Alarm connuously sounds when

the AC input is normal

The UPS is overloaded Remove some of the load from the

output of the UPS

UPS fault Return the unit for service

Alarm sounds every 2 seconds

when the AC input is normal

Baery defect Replace the baery with the same

type of baery

Charging circuit is damaged Return the unit for service

When power fails, backup me is

shorter than expected

The UPS is overloaded Remove some of the load from the

output of the UPS

Baery voltage is too low Charge the UPS at least 8 hours

Baery defect Replace the baery with the same

type of baery

The AC input is normal but the blue

LED is ashing Power cord is loose Reconnect the input power cord

properly

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 7

Uninterrupble Power Supply

Specicaons

Model XSTi-400 XSTi-600 XSTi-800

Capacity 400VA/240W 600VA/360W 800VA/480W

Input

Voltage 230 VAC

Range 180 - 270 VAC

Frequency 50 Hz

Output

Voltage (AC mode) 230 VAC

Voltage (bat mode) 230 VAC ± 10%

Transfer Time 2 - 6 ms (typical)

Waveform Simulated Sine Wave

Baery

Type & Qty (1) 12V/4.5AH (1) 12V/7AH (1) 12V/9AH

Runme Up to 38 min Up to 68 min Up to 87 min

Charging Time 8 hours to 90% capacity

Protecon Overcharge, discharge, short circuit, and thermal

Physical

Dimensions (W x D x H) 82.5 x 228 x 207 mm (3.2 x 8.9 x 8.1 in) in vercal stand posion

Weight 2.2 kg (4.8 lbs) 2.7 kg (5.9 lbs) 3.1 kg (6.8 lbs)

Input Cord IEC 1.5m with Schuko Plug

Environmental

Humidity 0 - 90%

Temperature 0 - 40°C (32 - 104°F)

Altude 3500m (11,500 ) above sea level

Xtreme Power Conversion Corporaon

XSTi User’s Manual

Page 8

Uninterrupble Power Supply

Obtaining Service

If the UPS requires Service:

1. Use the TROUBLESHOOTING secon in this manual to eliminate obvious causes.

2. Verify there are no circuit breakers tripped.

3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem, call Xtreme

Power Conversion Corp Technical Support at 800.582.4524. Technical support inquiries can also be made at

[email protected]. Please have the following informaon available BEFORE calling the Technical Support

Department:

• Your name and address.

• The serial number of the unit.

• Where and when the unit was purchased.

• All of the model informaon about your UPS.

• Any informaon on the failure, including LED’s that may or may not be illuminated.

• A descripon of the protected equipment, including model numbers if possible.

• A technician will ask you for the above informaon and, if possible, help solve your problem over the

phone. In the event that the unit requires factory service, the technician will issue you a Return Mate-

rial Authorizaon number (RMA).

If you are returning the UPS to Xtreme Power for service, please follow these procedures:

1. Pack the UPS in its original packaging. If the original packaging is no longer available, ask the Technical Sup-

port Technician about obtaining a replacement set of packaging material. It is important to pack the UPS

properly in order to avoid damage in transit. Never use Styrofoam beads for a packing material.

2. Include a leer with your name, address, dayme phone number, RMA number, a copy of your original

sales receipt, and a brief descripon of the problem.

3. Mark the RMA number on the outside of all packages. Xtreme Power cannot accept any package without

the RMA number marked on the outside of the boxes.

4. Return the UPS by insured, prepaid carrier to the address provided by the Technician.

5. Refer to the Warranty statements in this manual for addional details on what is covered.
